  • Page 1 If you have questions or comments, contact us. Pour toute question ou tout commentaire, nous contacter. Si tiene dudas o comentarios, contáctenos. 1-800-4-D WALT • www.dewalt.com INSTRUCTION MANUAL INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE GUIDE D’UTILISATION...

  • Page 2: Save All Warnings And Instructions For Future Reference

    SAVE ALL WARNINGS AND INSTRUCTIONS Defi nitions: Safety Guidelines FOR FUTURE REFERENCE The defi nitions below describe the level of severity for each The term “power tool” in the warnings refers to your mains-operated signal word. Please read the manual and pay attention to (corded) power tool or battery-operated (cordless) power tool.

  • Page 3: Personal Safety

    f) If operating a power tool in a damp location is unavoidable, 4) POWER TOOL USE AND CARE use a ground fault circuit interrupter (GFCI) protected a) Do not force the power tool. Use the correct power tool supply. Use of a GFCI reduces the risk of electric shock. for your application.
  • Page 4 pack may create a risk of fi re when used with another battery • Only use the grease recommended in this manual. Refer to pack. the Technical Information chart under Using the Grease Gun. b) Use power tools only with specifi cally designated battery •...

  • Page 5: Important Safety Instructions For All Battery Packs

    • crystalline silica from bricks and cement and other masonry ....Class I Construction or AC/DC ... alternating products, and ..... (grounded) ......or direct • arsenic and chromium from chemically-treated lumber....Class II Construction current Your risk from these exposures varies, depending on how often you do n o ....
  • Page 6 as battery pack may rupture causing serious personal injury. battery terminals are protected and well insulated from materials that Consult the chart at the end of this manual for compatibility of could contact them and cause a short circuit. batteries and chargers. SPECIFIC SAFETY INSTRUCTIONS FOR NICKEL CADMIUM •...

  • Page 7: Important Safety Instructions For All Battery Chargers

    WARNING: Burn hazard. Battery liquid may be fl ammable if DANGER: Electrocution hazard. 120 volts are present at charging exposed to spark or fl ame. terminals. Do not probe with conductive objects. Electric shock or electrocution may result. The RBRC Seal WARNING: Shock hazard.
  • Page 8 • When operating a power tool outdoors, use an extension in a position away from any heat source. The charger is ventilated cord suitable for outdoor use. Use of a cord suitable for outdoor through slots in the top and the bottom of the housing. use reduces the risk of electric shock.
  • Page 9 continues up to 8 hours or until the individual cells in the battery Indicator Light Operation pack are equalized. The battery pack is ready for use and can be removed at any time during the Automatic Tune-Up™ mode. 4. Once the Automatic Tune-Up™ mode is complete, the charger will begin a maintenance charge;...

  • Page 10: Important Charging Notes

    operation, fl ashing the red light with two fast blinks followed by b. Check to see if receptacle is connected to a light switch which a pause. This indicates the power source is out of limits. turns power off when you turn out the lights; c.

  • Page 11: Intended Use

    FIG. 2 NOTE: Battery packs should not be stored completely depleted of charge. The battery pack will need to be recharged before use. SAVE THESE INSTRUCTIONS FOR FUTURE USE COMPONENTS (Fig. 2, 5) WARNING: Never modify the power tool or any part of it. Damage or personal injury could result.
  • Page 12 To unlock the trigger switch, press the FIG. 4 LED Worklight (Fig. 2, 3) lock-off button as shown in Figure 4. There is an LED worklight (D) located on the top cap (F). The worklight Squeeze the trigger switch to turn the is activated when the trigger switch is depressed and when the LED motor ON.

  • Page 13: Assembly And Adjustments

    ASSEMBLY AND ADJUSTMENTS Removing Empty Grease Cartridge WARNING: To reduce the risk of serious personal injury, (Fig. 2) turn tool off, push the lock-off button to the OFF position, and 1. Pull the grease tube handle (L) out as far as it will go, then secure remove the battery pack before making any adjustments or the grease tube rod (M) into the retaining slot (O) by moving the removing/installing attachments or accessories.
  • Page 14 NOTE: The seal resembles a cup, which should open toward the top FIG. 9 CAUTION: The fi ll pump loader must cap (F, Fig. 2) when prepared for suction and fi ller pump fi lling. connect correctly with the grease gun’s 4.

  • Page 15: Operation

    NOTE: Do not lock the rod into the retaining slot (O). OPERATION 2. Connect the low pressure fi tting on the grease gun to the WARNING: To reduce the risk of serious personal injury, appropriate low pressure fi tting on the fi ller pump. These fi ttings turn tool off and remove the battery pack before making any DO NOT lock together.

  • Page 16: Technical Information

    Once the correct amount of grease has been dispensed, release the WARNING: Never use solvents or other harsh chemicals for cleaning trigger and remove the coupler from the grease fi tting. If the coupler the non-metallic parts of the tool. These chemicals may weaken the does not release, there may still be residual pressure in the line.
  • Page 17 fi lter (V). Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286, call NOTE: If there is still grease in the tube, 1-800-4-D WALT (1-800-433-9258) or visit our website: www.dewalt. open the purge valve prior to pulling the com. tube handle.
  • Page 18 9258) for a free replacement. For further detail of warranty coverage and warranty repair information, visit www.dewalt.com or call 1-800-4-D WALT (1-800-433-9258). This warranty does not apply to accessories or damage caused where repairs have been made or attempted by others.

  • Page 19: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Possible Solution Unable to pull back rod Vacuum build up Unscrew the purge valve to release vacuum. Unable to push rod forward Pressure build up Unscrew the purge valve to release pressure. Rod is still connected to plunger Rotate grease tube handle 90 degrees to disengage it.
  • Page 20 El tiempo de duración de carga es aproximado; la duración de carga real puede variar. Lea el manual de instrucciones para obtener información más precisa. WALT Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286 (DEC13) Part No. N330280 DCGG570 Copyright © 2013 D WALT The following are trademarks for one or more D WALT power tools: the yellow and black color scheme;...
