Thank you for choosing a Skeeter boat. This Owner's/
Operator's Manual contains information you will need
for proper operation, maintenance, and care. A
thorough understanding of these simple instructions
will help you to obtain maximum enjoyment from your
new boat. If you have any questions about the
operation or maintenance of your boat, please consult
a Skeeter Dealer.
Because Skeeter has a policy of continuing product
improvement, this product may not be exactly as
described in this Owner's/Operator's Manual.
Specifications are subject to change without notice.
This manual should be considered a permanent part of
this boat and should remain with it even if the boat is
subsequently sold.
This document contains many of Yamaha's valuable
trademarks. It may also contain trademarks belonging
to other companies. Any references to other companies
or their products are for identification purposes only,
and are not intended to be an endorsement.
INTRODUCTION
RECORD IMPORTANT INFORMATION!
In addition to this manual, your Skeeter boat is
supplied with component manufacturer information
such as instructions, warranties, or other important
information. Read these materials carefully.
Safeguard information about your Skeeter boat by
recording the Hull Identification Number (HIN) and the
model of your boat, and the model and serial numbers
of your outboard motor, trailer, and accessories.
Your HIN is located on the top right side of the
transom, above the water line. The U.S. Coast Guard
requires that your HIN be permanently affixed and
remain on the top right side of the transom.
