ATW
Wireless Remote Controller
PAR-WT40R-E
Operation Manual
For safe and correct use, please read this operation manual thoroughly before operating the PAR-WT40R-E
wireless remote controller.
Bedienungsanleitung
Lesen Sie sich zur sicheren und korrekten Verwendung diese Bedienungsanleitung bitte sorgfältig durch,
bevor Sie die drahtlose Fernbedienung PAR-WT40R-E verwenden.
Mode d'emploi
Pour garantir une utilisation sûre et appropriée, lisez attentivement le présent mode d'emploi avant d'utiliser la
télécommande sans fil PAR-WT40R-E.
Handleiding
Voor een veilig en juist gebruik moet u deze handleiding goed doorlezen alvorens de PAR-WT40R-E
draadloze afstandsbediening in gebruik te nemen.
Manual de instrucciones
Para un uso correcto y seguro del control remoto inalámbrico PAR-WT40R-E, lea este manual de
instrucciones antes de su utilización.
Manuale di funzionamento
Per un uso corretto e sicuro del dispositivo, leggere attentamente il presente manuale di funzionamento prima
di utilizzare il comando remoto senza fili PAR-WT40R-E.
Manual de Funcionamento
Para uma utilização segura e correcta, é favor ler cuidadosamente este manual de funcionamento antes de
trabalhar com o controlador remoto sem fios PAR-WT40R-E.
Brugsvejledning
Læs venligst denne brugsvejledning grundigt inden betjening af den trådløse fjernbetjening PAR-WT40R-E af
hensyn til sikker og korrekt brug.
Användarmanual
För säker och korrekt användning, var god läs denna användarmanual noggrant innan du använder PAR-
WT40R-E-fjärrkontrollen.
Bruksanvisning
Les denne bruksanvisningen nøye før du bruker PAR-WT40R-E-fjernkontrollen i bruk, for å sikre trygg og riktig
bruk.
Käyttöopas
Turvallisen ja asianmukaisen käytön varmistamiseksi lue tämä käyttöopas huolellisesti ennen langattoman
PAR-WT40R-E-kaukosäätimen käyttöä.
FOR USER
FÜR NUTZER
POUR LES UTILISATEURS
VOOR DE GEBRUIKER
PARA EL USUARIO
PER L'UTENTE
PARA O UTILIZADOR
TIL BRUGER
FÖR ANVÄNDAREN
FOR BRUKEREN
KÄYTTÄJÄLLE
English
Deutsch
Français
Nederlands
Español
Italiano
Português
Dansk
Svenska
Norsk
Suomi

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric ATW PAR-WT40R-E

Summary of Contents for Mitsubishi Electric ATW PAR-WT40R-E

  • Page 1 Wireless Remote Controller PAR-WT40R-E Operation Manual FOR USER English For safe and correct use, please read this operation manual thoroughly before operating the PAR-WT40R-E wireless remote controller. Bedienungsanleitung FÜR NUTZER Deutsch Lesen Sie sich zur sicheren und korrekten Verwendung diese Bedienungsanleitung bitte sorgfältig durch, bevor Sie die drahtlose Fernbedienung PAR-WT40R-E verwenden.

  • Page 2: Table Of Contents

    English Contents 1. Safety Precautions ...... 5. Basic Functions ........7 5.1.Changing Set Temperature .....7 2. Summary of Product Characteristics . ..3 3. Names of Parts and Functions ....4 5.2.Setting Forced DHW .......9 4. Before Operation .........5 5.3.Setting Holiday Mode ......9 6. Specifications ........0 7. Q & A ..........0 Safety Precautions Read thoroughly the following Safety Precautions before use. ● The following hazardous classification shows the likelihood and severity of hazards if a per- son does not follow the instructions contained on the following signs. Indicates a hazardous situation which, if a person does not follow the instruc- Warning tions, could result in death or serious injury.
  • Page 3 Caution Do not drop the device. This could break the case or affect the device enough to make it inoperable. Do not wipe the device with Discoloration and damage to the device could result. benzine, thinner, and a chemical If the dirt is hard to remove, wipe it with a well wrung-out cloth impregnated cloth or the like. with diluted mild detergent, and dry moisture with a dry cloth. Do not put hazardous materials Avoid installing the device in the place where flammable gas around the device. may leak. Should leaked gas build up around the device, fire or explosion could result. Do not disassemble the device. Direct contact with the control board inside is hazardous and also could result in fire, breakdown, and reduction in operating performance. Do not use the device in particu- Do not use the device in particular environments where the lar environments. following substances are present in large amounts: oil, vapour, organic solvent, corrosive gas (such as ammonia, sulphuric compounds, and acid or the like) , or where acid or alkali solu- tion, or particular sprays are used frequently. This could affect operating performance, or cause corrosion which could result...

  • Page 4: Summary Of Product Characteristics

    Summary of Product Characteristics This device is a wireless remote controller system that wirelessly transmits to the indoor unit* at a frequency of 868 MHz. The wireless remote controller allows the following settings without ever leaving your room: room temperature setting, forced DHW mode, and holiday mode. Following are the features of the wireless remote controller: ● Control on individual room temperatures by reference to the temperature monitored in the specified room. ● Up to 8 wireless remote controllers connectable. ● Holiday mode settings for up to 72 hours on hourly basis. ● Large switch and LCD screen that facilitate usability and legibility. ● Floor-to-floor wireless transmission, such as from the 1st basement to 1st floor level. * Each wireless remote controller requires pairing to avoid improper transmission with the un- related wireless devices. If the wireless remote controller does not go through a pairing proc- ess, wireless transmission between the wireless remote controller and the wireless receiver does not work. For more details about pairing, contact the technician or installer. ■ Included parts The following items are included in the box. Part name Wireless remote controller Stand Bracket Flat head screw 4.1 × 16 Size AA alkaline battery Instruction manual...

  • Page 5: Names Of Parts And Functions

    Names of Parts and Functions ■ Wireless remote controller buttons/displays The following explains each button and operation. *All the items are shown above for the purpose of explanation. Number Name Operation Forced DHW button Sets the indoor unit to enter the forced DHW mode. Holiday button Sets the indoor unit to enter the holiday mode. Makes adjustments of the room temperatures and Up / Down button sets duration time in the holiday mode. Holiday indicator Indicates that the indoor unit enters the holiday mode. Indicates that the indoor unit enters the forced DHW DHW indicator mode. Set temp. display Displays the set room temperature. Battery replacement indi- Indicates when to replace batteries. cator Indicates a failure or error on the indoor unit, such as Error indicator a communication error.

  • Page 6: Before Operation

    Before Operation Remove the battery case cover before plac- ing the wireless remote controller, and place two size AA alkaline batteries properly. * When the wireless remote controller is not paired, it has to go through a pairing process. For details about pairing, contact the technician or installer.
  • Page 7 <<Using a stand >> Place the wireless remote controller on the stand. Place the stand at the following locations. ■ Locations to place the wireless remote controllers Observe the following when determining the installing locations. Do not place any other electric or electronic appliances within 1 m of the wireless remote controller.

  • Page 8: Basic Functions

    Basic Functions The following explains the basic functions operable using the wireless remote controller. <Main system ON> <Main system OFF> (1) Communication error When the error indicator blinks during operation of the wireless remote con- troller, this indicates a communication error. Please repeat the same proce- dure. (2) Failure or error on the indoor unit, the outdoor unit, or the wireless system When the indicator lights all the time, this represents a failure (or error) on the indoor unit, the outdoor unit, or the wireless system. Contact the techni- cian or installer.
  • Page 9 * When the indoor unit enters an operating mode that disables temperature setting, the set temp. display shows “ ”. In that case, the buttons are not active, so the set temperature can not be changed. When the indicator lights, this indicates that the wireless remote controller is set as that of a target room. <<What’s target room?>> ● The indoor unit controls the temperatures, by reference to the temperature in a target room. ● The target room can be fixed or changed according to time, using a schedule function. ● The number of rooms that can be set to as a target room is always limited to one. When setting a target room, use the main controller. Indoor Unit Kitchen Bed room...

  • Page 10: Setting Forced Dhw

    5.2. Setting Forced DHW Holding down the button for 3 seconds or more to set the indoor unit to enter the forced DHW mode. When the forced DHW mode ends, the indicator goes out. Note) When the indicator blinks after the button is held down for 3 seconds or more, this indi- cates that the indoor unit that you use does not support this function. 5.3. Setting Holiday Mode The holiday mode sets the indoor unit to en- ter the holiday mode. ● The holiday mode sets duration operation for up to 72 hours or no-time-limit opera- tion (displayed as “...
  • Page 11 Please be sure to put the contact address/telephone number on this manual before handing it to the customer. HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN Authorized representative in EU: MITSUBISHI ELECTRIC EUROPE B.V. HARMAN HOUSE, 1 GEORGE STREET, UXBRIDGE, MIDDLESEX UB8 1QQ, U.K. BH79R517H02...
