LC-60E77UN/LC-65E77UM/LC-C6077UN/LC-C6577UM
CHAPTER 4.
LC60E77UN
REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS (LC-60E77UN/LC-C6077UN)
1. Removing of Stand Unit and Rear Cabinet Ass'y.
1. Remove the 4 lock screws
2. Remove the 3 lock screws
5
4
and detach the Stand Unit
, 1 lock screw
, 18 lock screws
3
1
Service Manual
.
and detach the Rear Cabinet Ass'y.
4 – 1
Rear Cabinet Ass'y
2
Stand Unit
