5 Pt. Harness Car Seat WITH harness is certified
for use in Motor Vehicles and Aircraft.
•
Booster Car Seat WITHOUT harness is certified for
use in Motor Vehicles, NOT for Aircraft.
•
Meets or exceeds all applicable requirements of
Federal Motor Vehicle Safety Standard 213
Failure to follow the warnings
•
on booster seat labels and in the
instruction manual can result in death
or serious injury to your child.
Para instrucciones en Espanol llamar al: 866-947-3287
FOR CHILDREN WHOSE:
22-100 lbs.
WARNING!
Weight is:
10-45 kg
COMBINATION
HARNESS TO
BOOSTER CAR
SEAT
Instruction
Manual
Height is:
29-57 in.
74-145 cm
1 1
Advertisement
Table of Contents
Related Manuals for Kids Embrace COMBINATION HARNESS TO BOOSTER CAR SEAT
Summary of Contents for Kids Embrace COMBINATION HARNESS TO BOOSTER CAR SEAT
-
Page 1: Booster Car Seat
FOR CHILDREN WHOSE: Weight is: Height is: 22-100 lbs. 29-57 in. 10-45 kg 74-145 cm COMBINATION HARNESS TO BOOSTER CAR SEAT Instruction Manual • 5 Pt. Harness Car Seat WITH harness is certified for use in Motor Vehicles and Aircraft. •... -
Page 2: Table Of Contents
Table of Contents Table of Contents (continued) Table Of Contents ............2-3 Additional Information ............. 44 Warnings ...............4-5 Certification ............. 44 Car Seat Features ............6-7 Aircraft Use .............. 44 Use Recommendations ..........8-9 Warm Weather Use ..........44 Toddler Car Seat Use Vehicle Seat Protection ........... -
Page 3: Warnings
WARNING! WARNING! DEATH or SERIOUS INJURY can occur DEATH or SERIOUS INJURY can occur • Failure to follow these instructions and car • Discontinue use of this car seat when the seat labels can result in injury or death to a top of your child’s ears are above the top of child from striking the vehicles interior during the headrest. -
Page 4: Product View
Car Seat Features Car Seat Features Back Bottom Adjustable Headrest Harness Adjustment Strap Top Tether Strap Instruction Manual Vehicle Shoulder Shoulder Harness Belt Guides Slots Energy Absorbing Headrest Harness Pads Harness Retainer Shoulder Harness Adjustment Button Straps Metal Splitter Recline Foot Plate Armrests Harness Strap... -
Page 5: Use Recommendations
Use Recommendations Use Recommendations This car seat is designed for use by children who are at least 1 year old, can sit upright alone and BOOSTER CAR SEAT USE: weigh between 22 and 100 pounds (10 and 45 kg) MUST use vehicle lap and shoulder belt, car and whose height is between 29 and 57 inches seat harness system MUST be removed. -
Page 6: Securing Child With Harness
Toddler Seat Installation and Use Toddler Seat Installation and Use Securing Child with Harness Child MUST be at least 1 year old, weigh between 22 and 65 pounds (10 and 30 kg), and WARNING! able to sit upright unassisted. WARNING! Snugly adjust harness provided •... - Page 7 Toddler Seat Installation and Use Toddler Seat Installation and Use Buckle harness. Close and position Insert buckle harness retainer. tongues into buckle -Snap the harness until you hear a “click” retainer together (Fig. 4). (Fig. 6). Pull up on buckle -Position the harness Harness tongues to be sure...
-
Page 8: Selecting A Vehicle Seating Location
Toddler Seat Installation and Use Toddler Seat Installation and Use Selecting a Vehicle Seating Location Selecting a Vehicle Seating Location - Toddler Use - (continued) WARNING! DO NOT use Booster Seat in seat locations with: • Never put a booster seat in a vehicle front seating location unless recommended by vehicle owners manual. -
Page 9: Installation - Latch Or Vehicle Seat Belt
Toddler Seat Installation and Use Toddler Seat Installation and Use Check that Harness System is routed properly for Installation - LATCH Or Vehicle Seat Belt your child’s size before installing car seat. - (continued) 1. Top Tether Information: Installation - LATCH Or Vehicle Seat Belt This car seat can be secured to a vehicle using the new If a top tether anchor is not available in your vehicle, LATCH System or a vehicle seat belt. -
Page 10: Latch Anchorage System
Toddler Seat Installation and Use Toddler Seat Installation and Use Installation With LATCH Anchorage System LATCH Anchorage System LATCH System On This WARNING! Car Seat: The LATCH system on the LATCH belt MUST stay tightly • KidsEmbrace car seat can adjusted around car seat at all times. - Page 11 Toddler Seat Installation and Use Toddler Seat Installation and Use Routing LATCH belts: Installation In Vehicle Using LATCH System: Your car seat is shipped with the LATCH belt routed through the belt path. If LATCH belt is NOT currently Place car seat through the belt path, route the LATCH belt as described forward- facing below:...
- Page 12 Toddler Seat Installation and Use Toddler Seat Installation and Use To Remove Car Seat: Tighten LATCH belt 1. Loosen top tether and (Fig. 3). remove tether hook from -Place knee in seat top tether anchor, see and push down firmly “Top Tether Use”...
-
Page 13: Installation With Vehicle Seat Belt
Toddler Seat Installation and Use Toddler Seat Installation and Use Installation With Vehicle Seat belt: Installation With Vehicle Seat belt: - (continued) 5. Tighten the lap belt WARNING! (Fig. 4). -Place knee in seat and • Vehicle seat belt MUST stay tightly push down firmly while adjusted around car seat at all times. -
Page 14: To Remove Car Seat
Toddler Seat Installation and Use Booster Seat Installation and Use To Remove Car Seat: Child MUST be at least 3 years old and weigh between 30 and 100 pounds (14 and 45 kg). 1. Loosen top tether and remove tether hook from WARNING! top tether anchor, see “Top Tether Use”... -
Page 15: Selecting A Vehicle Seating Location
Booster Seat Installation and Use Booster Seat Installation and Use Selecting a Vehicle Seating Location Selecting a Vehicle Seating Location -Booster Seat: -Booster Seat: (continued) WARNING! WARNING! • Never put a booster seat in a • Only use Booster Seat in seating vehicle front seating location unless location with lap and shoulder belt. - Page 16 Booster Seat Installation and Use Booster Seat Installation and Use Securing Booster With LATCH Selecting a Vehicle Seating Location The LATCH attachment system can be used to secure - (continued) the booster seat into the vehicle if available. Use of the LATCH attachment system keeps the booster seat secured at all times and assists a child when getting into the booster seat.
-
Page 17: Securing Child With Lap And Shoulder Belt
Booster Seat Installation and Use Booster Seat Installation and Use WARNING! Securing Child with Lap and Shoulder Belt - (continued) • Use vehicle lap and shoulder belt only 5. Place vehicle with vehicle lap belt under armrests. shoulder belt in vehicle shoulder belt Securing Child with Lap and Shoulder Belt guide (Fig. -
Page 18: Operation And Adjustment
Booster Seat Installation and Use Operation and Adjustment Securing Child with Lap and Shoulder Belt Shoulder Harness Adjustment: - (continued) To Tighten: 9. Check fit of vehicle belts Pull front adjuster strap (Fig. 7). (Fig. 1). -The lap belt must be low and snugly adjusted on hips, contacting the... -
Page 19: Changing Shoulder Harness Position
Operation and Adjustment Operation and Adjustment Changing Shoulder Harness Position Removing Harness: - (continued) To Change Shoulder Harness Slots: To remove shoulder harness straps: 1. From back of seat, remove 1. From back of seat, Metal Splitter Metal Splitter sewn loops at ends of Plate unfasten shoulder harness Plate... -
Page 20: Changing Crotch Belt Position
Operation and Adjustment Operation and Adjustment Changing Crotch Belt Position Reclining the Combination Toddler/ Booster Car Seat Crotch strap MUST be in opening closest to but not This car seat is equipped with a recline foot to provide under child. Raise seat pad from seat surface, pulling additional comfort for your child. -
Page 21: Installing Harness
Operation and Adjustment Operation and Adjustment Installing Harness: Installing Harness: - (continued) To install shoulder harness straps: 1. Feed sewn loop at end of 5. Pull metal splitter plate out. each shoulder harness strap up through one lap 6. Thread loops on shoulder belt slot (Fig. -
Page 22: Top Tether Use
Operation and Adjustment Operation and Adjustment Installing Harness: - (continued) Top Tether Use: Most vehicles made after 9/1/99 already have the top To Secure Crotch Strap in tether anchorage hardware for a tether. Refer to your Forward Crotch Belt Slot. vehicle owners manual. -
Page 23: Additional Information
Additional Information Vehicle Seat Belts Certification This car seat meets or exceeds all applicable Not all vehicle seat belts will work with this booster seat. requirements of Federal Motor Vehicle Safety You must determine if your vehicle seat belts are com- Standard 213 for use in motor vehicles and patible with this booster seat. -
Page 24: Vehicle Seat Belts
Vehicle Seat Belts Vehicle Seat Belts 5 Pt. Harness Car Seat System Toddler Car Seat WITH Harness System 22 to 65 lbs. (10 to 30 kg). 22 to 65 lbs. (10 to 30 kg). - (continued) - (continued) Belts in center of the door or side panel or middle Manual Belts - (continued) of the vehicle seat bottom cushion... -
Page 25: Booster Car Seat Without Harness
Vehicle Seat Belts Locking Clip Booster Car Seat WITHOUT Harness Locking Clip Use: System A locking clip is designed for use with vehicle lap and shoulder belts with free sliding latch plates to lock the 30 to 100 lbs. (14 to 45 kg). lap belt in position. -
Page 26: Care And Cleaning
Care and Cleaning Care and Cleaning continued Harness Removal Cleaning: See “Removing Harness:” section Seat Pad: Machine wash separately in cold water - delicate cycle. No bleach. Drip dry. Note: Secure fabric hook and loop fasteners on armrests and sides of pad together before washing and Seat Pad Removal: drying pad. -
Page 27: Warranty
Warranty Information Warranty Information continued LIMITATIONS OF WARRANTIES AND Embrace™ warrants its products to the original retail purchaser as follows: OTHER WARRANTY TERMS AND STATE LAWS LIMITED ONE-YEAR WARRANTY Any implied warranties, including implied This product is warranted against defective warranties of merchantability and fitness for a materials or workmanship for one year from the particular purpose, shall be limited to the duration... - Page 28 Notes Notes...
- Page 29 Keep this instruction manual for future use. Store in pocket under side of seat pad. A Division of Inspired Products Group Company, LLC 4830 Rusina Rd. STE B Colorado Springs, CO 80907-9929 www.KidsEmbrace.com Questions or comments? Call: 1-866-947-3287 12362.1...
