Model:
MPPT30HV
Page 1 of 8
This revolutionary maximum power point tracker solar charger was designed
using the technology that won GSL Electronics the prestigious "2008 EDN
Innovation award". A simple, compact and low cost alternative. Ideal for
charging batteries with the new low cost and high efficiency grid type panels.
The MPPT is designed to charge sealed and vented lead acid batteries from photovoltaic pannels.
Silicon based panels such as monocrystalline, polycrystalline and amorphous are suitable.
Efficiency typical
Input voltage
Output voltage
Output power
Quiescent current
Thermal protection
Dimensions (mm)
Indications
1800W Solar Battery Charger
Maximum Power Point Tracker
Please read these instructions before use
PATENT APPLIED FOR - 2010901565
MPPT30HV Specifications
Absorption - Vented LA batteries 14.5V / 29V / 58V
Unit 2, 110 Station Road, Seven Hills ,NSW, 2147, Australia
Operating Instructions
97%
16V to 180V
Float - 13.5V / 27V / 54V
Sealed LA batteries 14.2V / 28.4V / 56.8V
Calcium Batteries 15V / 30V / 60V
1800W / 30A MAX
0.05A
Automatic output derating to 70°C
306 X 177 X 70mm
LED display – OUTPUT STATUS
MPPT30HV Unit
MPPT30HV-R5
Advertisement
Related Manuals for GSL MPPT30HV
Summary of Contents for GSL MPPT30HV
- Page 1 Please read these instructions before use This revolutionary maximum power point tracker solar charger was designed using the technology that won GSL Electronics the prestigious “2008 EDN Innovation award”. A simple, compact and low cost alternative. Ideal for charging batteries with the new low cost and high efficiency grid type panels.
-
Page 2: Setting Procedure
• This MPPT is designed to auto detect 12V, 24V or 48V battery systems. • The MPPT30HV is shipped in a sealed battery setting. But if your batteries are vented or calcium then, BEFORE wiring the MPPT in, follow the CHANGING BATTERY TYPE SETTING PROCEDURE. - Page 3 Model: 1800W Solar Battery Charger MPPT30HV Maximum Power Point Tracker Page 3 of 8 Operating Instructions Please read these instructions before use All power sources, including panels and batteries, must be disconnected or de-energised before installing or opening this product.
- Page 4 Model: 1800W Solar Battery Charger MPPT30HV Maximum Power Point Tracker Page 4 of 8 Operating Instructions Please read these instructions before use Load Wiring Instructions: Panel + All power sources, including panels and batteries, must Panel - be disconnected or...
- Page 5 Model: 1800W Solar Battery Charger MPPT30HV Maximum Power Point Tracker Page 5 of 8 Operating Instructions Please read these instructions before use Changing Battery Type Setting Procedure 1.Ensure all the MPPT wires are disconnected. 2.Remove 7 front panel screws and the front panel and slide out cover – see Figure 1.
- Page 6 Model: 1800W Solar Battery Charger MPPT30HV Maximum Power Point Tracker Page 6 of 8 Operating Instructions Please read these instructions before use Figure 2 (Above): Vented Battery Setting Figure 3 (Above): Calcium Battery Setting Figure 4 (Above): Sealed Battery Setting...
- Page 7 30A, so you can expect about 100AH per day which means a 100W load for about 10 hours daily. 2. Following the same reasoning with a 24V 800W panel the MPPT30HV will supply a daily load of 200W for about 10 hours.
- Page 8 GSL Electronics (GSL) warrants that its products will, under normal use and service, be free of defects in material and workmanship for a period of two (2) years from the date of the original purchase by the customer as marked on the customer’s original invoice.
