Maruson TAC-HV1K User Manual

Maruson tacoma hv series 1k-3kva on-line ups

Advertisement

Quick Links

TACOMA HV SERIES
1K ~ 3KVA
On-Line UPS

USER MANUAL

Maruson Technology Corporation
P.O. Box 1986, Walnut, CA 91788 USA
Toll Free: 1-888-MARUSON
Website: www.MarusonUSA.com
|
E-Mail: Info@MarusonUSA.com
*Copyright © 2012 All Rights Reserved. Maruson® is a registered trademark of Maruson Technology
(U.S. Trademark Reg. No. 3,150,957). All other trademarks are the property of their respective owners.
Product specifications are subject to change without notice. Battery backup time is based on half load
and varies with equipment, configuration, battery age, temperature, etc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAC-HV1K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Maruson TAC-HV1K

  • Page 1: User Manual

    Website: www.MarusonUSA.com E-Mail: Info@MarusonUSA.com *Copyright © 2012 All Rights Reserved. Maruson® is a registered trademark of Maruson Technology (U.S. Trademark Reg. No. 3,150,957). All other trademarks are the property of their respective owners. Product specifications are subject to change without notice. Battery backup time is based on half load...
  • Page 2: Table Of Contents

    CONTENT ............. 1 1. Safety and EMC Instructions 1.1 Installation..................1 1.2 Operation..................2 1.3 Maintenance, servicing and faults ............3 1.4 Transport...................4 1.5 Storage ..................... 4 1.6 Standards..................5 ........6 2. Description of Commonly Used Symbols ................7 3. Introduction ..............
  • Page 3 6.6 ECO mode (Economy mode) ............22 6.7 Converter mode................23 6.8 Abnormal mode ................23 ............24 7. Setting by LCD Module ..............27 8. Trouble Shooting ................31 9. Maintenance 9.1 Operation..................31 9.2 Storage ................... 31 9.3 Battery Replace ................31 ..............
  • Page 4: Safety And Emc Instructions

    1. Safety and EMC Instructions Please read carefully the following user manual and the safety instructions before installing the unit or using the unit! 1.1 Installation See installation instructions before connecting to the supply. Condensation may occur if the UPS is moved directly from a cold to a warm environment.
  • Page 5: Operation

    Intelligent Slot Battery connector Cooling Fan Output Socket Fuse Breaker(16A) Output Terminal Input Socket(16A) UPS has provided earthed terminal, in the final installed system configuration, equipotential earth bonding to the external UPS battery cabinets. Back View of 3K An appropriate disconnect device as short-circuit backup protection should be provided in the building wiring installation.
  • Page 6: Maintenance, Servicing And Faults

    Appendix: Rear panel Do not remove the enclosure. This system is to be serviced by qualified service personnel only. Remove the protective panel only after disconnecting the terminal connections. Use No. 12 AWG (for 2-3K/KL input wire) , 90¡C copper wire and Intelligent Slot 4.4 lb-in Torque force when connecting to terminal block.
  • Page 7: Transport

    12. Software use only tools with insulated grips and handles. When changing batteries, replace with the same quantity and the Free Software Download – WinPower same type of batteries. WinPower is a brand new UPS monitoring software, which provides Do not attempt to dispose of batteries by burning them. It could user-friendly interface to monitor and control your UPS.
  • Page 8: Standards

    1.6 Standards 11. Communication Port The communication port is for the monitoring software. A USB port * Safety and an intelligent slot are provided. IEC/EN 62040-1 11.1 USB * EMI The USB port is compliance with USB 1.1 protocol. Conducted Emission.........:IEC/EN 62040-2 Category C1 Radiated Emission........:IEC/EN 62040-2 Category C1...
  • Page 9: Description Of Commonly Used Symbols

    10.3 Typical backup time (Typical values at 25°C in minutes:) 2. Description of Commonly Used Symbols Model No. 100 % Load 50 % Load Some or all of the following symbols may be used in this manual. It is advisable to familiarize yourself with them and understand their meaning: 10.4 Dimensions and weights Model No.
  • Page 10: Introduction

    3. Introduction 10. Technical Data This On-Line-Series is an uninterruptible power supply incorporating 10.1 Electrical specifications double-converter technology. It provides perfect protection specifically for Novell, Windows NT and UNIX servers. INPUT TAC- TAC- TAC- TAC- TAC- TAC- The double-converter principle eliminates all mains power disturbances. Model No.
  • Page 11: Panel Description

    9. Maintenance 4. Panel Description 9.1 Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case please contact your dealer. 9.2 Storage If the batteries are stored in temperate climatic zones, they should be charged every three months for 1~2 hours.
  • Page 12 Please have the following information at hand before calling the After-Sales Service Department: 1. Model number, serial number 2. Date on which the problem occurred 3. LCD display status, Buzzer alarm status 4. Utility power condition, load type and capacity, environment temperature, ventilation condition 5.
  • Page 13 Inverter temperature Inside temperature Check the ventilation of the Indicates the UPS output state, it would always be high of the UPS is too UPS, check the ambient displayed high temperature. Ambient temperature The ambient Check the environment Indicates the UPS output is shut off only if it is high temperature is too ventilation.
  • Page 14 If the UPS system does not operate correctly, please attempt to solve the Indicates the UPS is working in bypass mode, the load is directly supplied by the input power problem using the table below. through bypass Problem Possible cause Remedy Indicates the UPS is working in no output mode No input voltage...
  • Page 15: Trouble Shooting

    8. Trouble Shooting 5. Connection and Operation If the UPS system does not operate correctly, check the operating status on The system may be installed and wired only by qualified the LCD display. electricians in accordance with applicable safety regulations! Normal operating mode Code No output mode...
  • Page 16 UPS INPUT NFB Model No. VOLTAGE CURRENT 1K(L) 300Vac 2K(L) 300Vac 3K(L) 300Vac (2) UPS Output Connection The output of the UPS is US-type sockets. Simply plug the load power cord to the output sockets to complete connection. Use one cord for every 10A load.
  • Page 17: Battery Charge

    Here is a example for changing the output voltage from 220Vac to (3) EPO Connection: 230Vac through the LCD panel. User can select the polarity of EPO, EPO is Normally Close for the UPS Normally the EPO connector is open on the rear panel. Once the connector is closed with a wire, the UPS would stop the output until the EPO status is disabled.
  • Page 18: Test Function

    UPS, the UPS will get into the inverter mode, the LCD screen will 7. Setting by LCD Module indicate the state of the UPS. The output voltage and frequency, and bypass state, and ECO mode, and (2) Without utility power connecting: Converter mode could be set directly through LCD module.
  • Page 19: Audible Alarm Mute Function

    5.7 Audible alarm mute function: 2) It is attention that the transfer time of UPS output from ECO mode to battery mode is less than 10ms. But it is still too long for some If the alarm is too annoying in battery mode, you may press “I” button sensitive load.
  • Page 20 black wire is connected to the "-" terminal of the battery. (Note: the green/yellow wire is grounded for protection purpose.) (7) Make sure the wires are fasten, install the terminal block cover on the rear panel of the UPS. (8) Connect the UPS to the load. Then, turn on the mains switch or connect the power cord of the UPS to utility power supply, the battery would start to be charged.
  • Page 21: Operating Mode For All Models

    6. Operating Mode for All Models battery mode code of the UPS is “3”, and the battery test mode code is “4”. The different codes could be displayed on the LCD screen 6.3 Bypass mode corresponding to their own operating modes, and they are illustrated as the following table.
  • Page 22: Battery Mode

    and the load could be displayed. The block of “BATTERY” indicates the inverter of the UPS is working. 1) When the UPS is running in battery mode, the buzzer beeps once every 4 seconds. If the “ON” button on the front panel is pressed for more than 1 second again, the buzzer will stop beeping (in silence mode).

This manual is also suitable for:

Tac-hv1klTac-hv2kTac-hv2klTac-hv3kTac-hv3kl
