WESTON LODGE DELUXE – F25529
INSTALLATION AND OPERATING INSTRUCTIONS
31'-4"
19'-4"
TUBE SLIDE
2-4 Hrs
TWO PERSON
ASSEMBLY
3405529
WARNING
and give them to any future owner of this play system. Manufacturer contact information provided below.
OBSTACLE FREE SAFETY ZONE - 31'4" x 29'4" area requires Protective Surfacing. See page 3.
MAXIMUM VERTICAL FALL HEIGHT - 7'1"
14'-5"
CAPACITY - 12 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
29'-4"
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as schools, churches, nurseries, day cares or parks.
Cedar Summit
c/o ©Solowave Design L.P.
Mount Forest, ON Canada
N0G 2L0
www.cedarsummitplay.com
support@cedarsummitplay.com
Customer Service
1-877-817-5682 (toll free)
1-519-323-2258
To reduce the risk of serious injury or death, you must read and
follow these instructions. Keep and refer to these instructions often

Table of Contents

Warnings And Safe Play Instructions . . . . . . . . . . pg. 2
Protective Surfacing Guidelines . . . . . . . . . . . . . . pg. 3
Instructions For Proper Maintenance . . . . . . . . . pg. 4
About Our Wood – Limited Warranty . . . . . . . . . pg. 5
Keys To Assembly Success . . . . . . . . . . . . . . . . . . . pg. 6
Iso Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg. 8,9
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 10
Installation of I.D./Warning Plaque . . . . . . . Final Step
FORT
10-14 Hrs
TWO PERSON
ASSEMBLY
Rev 12/23/2014
