Hardware Overview

Front view

Headphone out
port
Microphone in
port
LCD panel
USB 2.0 port
Escape mode
button
CPU Level Up
OC button
LCD panel power
button
Selection knob
Supports headphones and speakers.
Connects to a microphone.
Displays the system time, CPU speed,
temperature of motherboard and CPU, system
fan duty cycles, audio EQ modes, and the
current mode or status of the device.
Charges your smart device when in soft-off
mode. Functions as a normal USB 2.0 port
when system is on.
Hides the current screen, mute the sound, and
display the desktop.
Performs overclocking.
Turns the LCD panel display of the ROG Front
Base on/off.
Rotates to go to the desired item or adjust the
values. Confirms changes or selection when
pressed.
5
