RS409 Ring Scanner
Quick Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS409 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Symbol RS409

Summary of Contents for Symbol RS409

  • Page 1 RS409 Ring Scanner Quick Reference Guide...

  • Page 2: Warranty

    Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
  • Page 3 Quick Reference Guide Introduction The RS409 ring scanner is a modular, wearable laser scanner that allows the operator hands-free bar code scanning capability. The scanner is used with the WT4070/90 wearable terminal. The RS409 is worn on the operator’s index finger, and utilizes a thumb-operated trigger.

  • Page 4: Changing Trigger Position

    RS409 Ring Scanner Changing Trigger Position The trigger assembly of the RS409 rotates to provide left-hand or right-hand use. Determine whether the RS409 is used on the right or left hand. CAUTION The trigger assembly only rotates 180° around the back of the scan assembly.

  • Page 5: Installation

    If connecting to a wrist mounted wearable terminal, connect to the interface connector closest to the wrist. Scanner Cable Connector Interface Connector Slide the RS409 onto the index finger with the scan trigger next to the thumb. Tighten the finger strap.

  • Page 6: Using The Scanner

    Turn on the wearable terminal. Launch a scanning application. Press the scan trigger and aim the RS409 at a bar code. The scan LED lights red to indicate the RS409 is on. Adjust the aim so that the thin, red laser beam covers the entire length of the bar code.

  • Page 7: Scanning Tips

    Scanning Tips • For larger bar codes, hold the RS409 farther away from the bar code. • For bar codes with bars that are closer together, hold the RS409 closer to the bar code. • The optimal scanning distance varies with bar code density, but 10 to 25 cm (4 to 10 inches) generally works.

  • Page 8: Replacing The Trigger Assembly

    RS409 Ring Scanner Replacing the Trigger Assembly To replace the trigger assembly: Remove the finger strap assembly. Turn the RS409 upside-down. Remove the set screw with screwdriver. Turn the trigger assembly counter-clockwise until the exit window and scan trigger align.

  • Page 9: Troubleshooting

    Quick Reference Guide Cleaning Wipe the exit window periodically with a lens tissue or other material suitable for cleaning optical material such as eyeglasses. CAUTION Do not pour, spray, or spill any liquid on the RS409. Troubleshooting Symptom Probable Cause...

  • Page 10: Ergonomic Recommendations

    • Provide a suitable working environment • Improve work procedures. Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Regulatory Information is available in French, Italian, German, Spanish (Spain), Portuguese, Japanese, Korean, Russian and Simplified Chinese.

  • Page 11: Laser Devices

    Quick Reference Guide Laser Devices Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated July 26, 2001, and with EN60825-1:1994+ A1:2002 +A2:2001 and IEC60825-1:1993+A1:1997+A2:2001. The laser classification is marked on one of the labels on the device. Class 1 Laser devices are not considered to be hazardous when used for their intended purpose.

  • Page 12: Radio Frequency Interference Requirements - Fcc

    Canada. Marking and European Economic Area (EEA) Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC. Declaration of Conformities may be...

  • Page 13: Waste Electrical And Electronic Equipment (Weee)

    English: For EU Customers: All products at the end of their life must be returned to Symbol for recycling. For information on how to return product, please go to: http://www.symbol.com/environmental_compliance. Dansk: Til kunder i EU: Alle produkter skal returneres til Symbol til recirkulering, når de er udtjent. Læs oplysningerne om returnering af produkter på: http://www.symbol.com/environmental_compliance.
  • Page 14 Português: Para clientes da UE: todos os produtos no fim de vida devem ser devolvidos à Symbol para reciclagem. Para obter informações sobre como devolver o produto, visite: http://www.symbol.com/environmental_compliance. Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske dobe vrniti podjetju Symbol za reciklažo.
  • Page 15 Quick Reference Guide...
  • Page 16 If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there is a problem with the equipment, they will contact the Symbol Customer Interactive Center at: http://www.symbol.com/contactsupport. For the latest version of this guide go to: http://www.symbol.com/manuals. 72-86010-01 Revision A - August 2006 Symbol Technologies, Inc.
