D-Link DSL-526B User Manual

Hide thumbs Also See for DSL-526B:
Table of Contents

Advertisement

Quick Links

Download this manual
:
§ R ° £
<sp>
1

Advertisement

Table of Contents
loading

Related Manuals for D-Link DSL-526B

Summary of Contents for D-Link DSL-526B

  • Page 1 § R ° £ <sp>...

  • Page 2: Table Of Contents

    ....................... 51 TATISTICS ......................53 OUTE ARP ........................ 53 DHCP......................54 ADVANCED SETUP ................... 55 WAN........................ 55 LAN ......................... 57 NAT ......................... 58 ..................60 UALITY OF ERVICE Queue Config ..................... 60 QoS Classification ..................61 D-Link DSL-526B User Manual...

  • Page 3: Package Contents

    • One USB cable • One Quick Installation Guide Note: Using a power supply with a different voltage rating other than the one included with the DSL-526B may cause damage and void the warranty for this product. System Requirements • ADSL Internet service •...

  • Page 4: Features

    This eliminates the need to reconfigure every host whenever changes in the network topology occur. • Network Address Translation (NAT) – For small office environments, the DSL-526B allows multiple users on the LAN to access the Internet concurrently through a single Internet account. This provides Internet access to everyone in the office for the price of a single user.

  • Page 5: Hardware Overview

    Use the Ethernet port to connect the Push in to power-on the Router. Push Use the adapter shipped with the Router Router to a computer or an Ethernet to connect to power source again to power-off the Router D-Link DSL-526B User Manual...

  • Page 6: Leds

    PPP negotiation has been successfully completed. If green or dark light. passing through the Ethernet port. the indicator blinks green, this means the Router is active. If the Router is powered off, this remains dark. D-Link DSL-526B User Manual...

  • Page 7: Installation

    Before You Begin Please read and make sure you understand all the prerequisites for proper installation of your new Router. Have all the necessary information and equipment on hand before beginning the installation. D-Link DSL-526B User Manual...

  • Page 8: Installation Notes

    Operating Systems The DSL-526B uses an HTML-based web interface for setup and management. The web configuration manager may be accessed using any operating system capable of running web browser software, including Windows 98 SE, Windows ME, Windows 2000, Windows XP, and Windows Vista.
  • Page 9 Your network service provider will give you instructions about any additional connection software or NIC configuration that may be required. If you plan to use the DSL-526B’s USB port to connect to your computer, do not connect the USB cable to the Router until you...

  • Page 10: Information You Will Need From Your Adsl Service Provider

    VPI and VCI as instructed by your ADSL service provider for the additional connections. This setting can be changed in the WAN Settings window of the web management interface. D-Link DSL-526B User Manual...
  • Page 11 ADSL service provider’s network and your computer. If you are setting up the Router for multiple virtual connections, you will need to configure the VPI and VCI as instructed by your ADSL service provider for the additional connections. This setting can be changed in the WAN Setup window of the web management interface. D-Link DSL-526B User Manual...

  • Page 12: Information You Will Need About Your Dsl-526B Adsl Router

    IP address used for DHCP service on the LAN when DHCP is enabled. LAN Subnet Mask for the DSL-526B This is the subnet mask used by the DSL-526B and will be used throughout your LAN. The default subnet mask is 255.255.255.0. This can be changed later.

  • Page 13: Information You Will Need About Your Lan Or Computer

    Ethernet NIC If your computer has an Ethernet NIC, you can connect the DSL-526B to the Ethernet port using an Ethernet cable. You can also use the Ethernet ports on the DSL-526B to connect to other computers or Ethernet devices.

  • Page 14: Installing The Usb Driver

    IMPORTANT: Do not connect the USB cable to your PC before completing the steps below! The CD-ROM shipped with the Router contains the USB driver software. Insert the DSL-526B CD-ROM into the CD drive. Within a few seconds you should see a window that offers the following options: Install DSL-526B, Quick Install Guide, View Manual, Install Acrobat Reader, and Exit. If you do not see this auto-run pop-up window, explore the CD-ROM and double-click the setup application file autorun.exe or find the file Setup.exe in...
  • Page 15 2. Insert the other end of the USB cable into a spare USB port on your PC. 3. Connect the power adapter to the power input in the back panel of the DSL-526B and then plug the other end of the power adapter to a wall outlet or power strip.

  • Page 16: Device Installation

    Device Installation The DSL-526B has three separate physical interfaces, an ADSL (WAN), an Ethernet (LAN) interface and a USB Interface. The Router can be connected to your PC via the USB port or the Ethernet port. Place the Router in a location where it can be connected to the various devices as well as to a power source.

  • Page 17: Factory Reset Button

    Remember that this will wipe out any settings stored in flash memory including user account information and LAN IP settings. The device settings will be restored to the factory default IP address 192.168.1.1 and the subnet mask 255.255.255.0, the default management Username is “admin” and the default Password is “tot”. D-Link DSL-526B User Manual...

  • Page 18: Network Connections

    You can either connect the Router’s Ethernet interface directly to a 10/100BASE-TX Ethernet adapter card (NIC) installed in a PC using the Ethernet cable provided or connect the Router to a spare USB port using the Router’s USB interface. D-Link DSL-526B User Manual...

  • Page 19: Configuration

    Section 3 – Configuration Configuration This section will show you how to configure your new D-Link Router using the web-based configuration utility. Web-based Configuration Utility Connect to the Router To configure the WAN connection used by the Router it is first necessary to communicate with the Router through its management interface, which is HTML-based and can be accessed using a web browser.

  • Page 20: Quick Setup

    QUICK SETUP The following window appears to indicate that the router is restarting. QUICK SETUP Once the router has restarted you will be presented with the Quick Setup screen. This completes the Quick Setup of your router D-Link DSL-526B User Manual...

  • Page 21: Wizard

    PPP over ATM (PPPoA), PPP over Ethernet (PPPoE), MAC Encapsulation Routing (MER), IP over ATM (IPoA), and Bridging (default). This window also allows you to use the drop-down menu to select the desired Encapsulation Mode. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 22 Click the Next button to continue. WIZARD– BRIDGING This window allows you to configure the Router IP address and subnet mask for your LAN. Once you have entered an IP address and subnet mask, click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 23 Section 3 – Configuration WIZARD – BRIDGING This summary window allows you to confirm the bridging settings you have just made. Click the Save/Reboot button to save your new bridging settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 24 This window allows you to set the username and the password for your PPP connection. This information is obtained from your ISP. Additional settings on this window will also depend on your ISP. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 25 To enable the DHCP server, enter a starting IP address, an ending IP address, and a subnet mask. You may also choose to change the default value of the leased time. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 26 Section 3 – Configuration WIZARD – PPPoA This summary window allows you to confirm the settings you have just made. Click the Save/Reboot button to save your new PPP over ATM settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 27 This window allows you to set the username and the password for your PPP connection. This information is obtained from your ISP. Additional settings on this window will also depend on your ISP. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 28 To enable the DHCP server, enter a starting IP address, an ending IP address, and a subnet mask. You may also choose to change the default value of the leased time. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 29 Section 3 – Configuration WIZARD – PPPoE This summary window allows you to confirm the settings you have just made. Click the Save/Reboot button to save your new PPP over Ethernet settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 30 This window also allows you to use the drop-down menu to select the desired Encapsulation Mode. Click the Next button to continue. WIZARD – MER This window allows you to configure the WAN IP settings. This information is obtained from your ISP. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 31 To enable the DHCP server, enter a starting IP address, an ending IP address, and a subnet mask. You may also choose to change the default value of the leased time. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 32 Section 3 – Configuration WIZARD – MER This summary window allows you to confirm the settings you have just made. Click the Save/Reboot button to save your new MAC Encapsulation Routing settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 33 Encapsulation Mode. Click the Next button to continue. WIZARD – IPoA This window allows you to configure the WAN IP settings. This information is obtained from your ISP. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 34 WIZARD – IPoA This window allows you to enable or disable Network Address Translation and a firewall for your Router. In addition, you can enable or disable IGMP multicasting and WAN service. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 35 To enable the DHCP server, enter a starting IP address, an ending IP address, and a subnet mask. You may also choose to change the default value of the leased time. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 36 Section 3 – Configuration WIZARD – IPoA This summary window allows you to confirm the settings you have just made. Click the Save/Reboot button to save your new IP over ATM settings and restart the Router. D-Link DSL-526B User Manual...

  • Page 37: Advanced Setup

    Router including how to change IP settings and DHCP server setup. ADVANCED SETUP Click the Advanced Setup link on the left panel of the opening page to launch a series of setup windows. D-Link DSL-526B User Manual...
  • Page 38 Service Category that your ISP uses from the Service Category drop down menu. This window also allows you to enable QoS by ticking the Enable Quality of Service check box. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 39 This window also allows you to use the drop-down menu to select the desired Encapsulation Mode. Click the Next button to continue. ADVANCED SETUP – BRIDGING To enable bridging, tick the Enable Bridge Service check box and enter a Service Name. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 40 Section 3 – Configuration ADVANCED SETUP – BRIDGING This summary window allows you to confirm the bridging settings you have just made. Click the Save button to save your new bridging settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 41 ADVANCED SETUP – PPPoA Click the PPP over ATM (PPPoA) radio button on this window. This window also allows you to use the drop-down menu to select the desired Encapsulation Mode. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 42 MTU value at the default setting unless your ISP advises you to change it. Click the Next button to continue. ADVANCED SETUP – PPPoA This window allows you to enable IGMP multicasting and the WAN service. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 43 ADVANCED SETUP – PPPoE Click the PPP over Ethernet (PPPoE) radio button on this window. This window also allows you to use the drop-down menu to select the desired Encapsulation Mode. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 44 MTU value at the default setting unless your ISP advises you to change it. Click the Next button to continue. ADVANCED SETUP – PPPoE This window allows you to enable IGMP multicasting and the WAN service. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 45 Section 3 – Configuration ADVANCED SETUP – PPPoE This summary window allows you to confirm the settings you have just made. Click the Save button to save your new PPP over Ethernet settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 46 Click the Next button to continue. ADVANCED SETUP – MER This window allows you to configure the WAN IP settings. This information is obtained from your ISP. When you have finished configuring the IP settings, click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 47 Service Name field. Click the Next button to continue. ADVANCED SETUP – MER This summary window allows you to confirm the settings you have just made. Click the Save button to save your new MAC Encapsulation Routing settings and restart the Router. D-Link DSL-526B User Manual...
  • Page 48 ADVANCED SETUP – IPOA This window allows you to configure the WAN IP settings. This information is obtained from your ISP. When you have finished configuring the IP settings, click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 49 Service Name field. Click the Next button to continue. ADVANCED SETUP – IPOA This summary window allows you to confirm the settings you have just made. Click the Save button to save your new IP over ATM (IPoA) settings and restart the Router. D-Link DSL-526B User Manual...

  • Page 50: Device Info

    Section 3 – Configuration Device Info To access the Device Info window, click either the Device Info link. The following page opens: This window displays different information about the Router, including Summary, WAN, Statistics, Route, ARP and DHCP information. D-Link DSL-526B User Manual...

  • Page 51: Summary

    This window displays the current status of your DSL connection, including the software version, LAN IP address and DNS server address. To access the WAN Info window, click the WAN link in the Device Info directory. This window displays the current status of your WAN connection. D-Link DSL-526B User Manual...

  • Page 52: Statistics

    This window displays the Router’s WAN statistics. Click the Reset Statistics button to refresh these statistics. To access ATM Statistics, click the ATM link in the Statistics directory. This window displays the Router’s ATM statistics. Click the Reset button to refresh these statistics. D-Link DSL-526B User Manual...
  • Page 53 To access ADSL Statistics, click the ADSL link in the Statistics directory. This window displays the Router’s ADSL statistics. Click the Reset Statistics button to refresh these statistics. Click the ADSL BER Test button to access the ADSL Bit Error Rate Test window displayed below: D-Link DSL-526B User Manual...

  • Page 54: Route

    To access the Device Info – Route window, click the Route link in the Device Info directory. This read-only window displays routing info. To access the Device Info – ARP window, click the ARP link in the Device Info directory. This read-only window displays Address Resolution Protocol info. D-Link DSL-526B User Manual...

  • Page 55: Dhcp

    Section 3 – Configuration DHCP To access the Device Info – DHCP window, click the DHCP link in the Device Info directory. This read-only window displays the current DHCP leases on the Router. D-Link DSL-526B User Manual...

  • Page 56: Advanced Setup

    Identifier in the VPI field and Virtual Channel Identifier in the VCI field. The VPI and VCI values should be provided by your ISP. This window also allows you to enable QoS by ticking the Enable Quality of Service check box. Click the Next button to continue. D-Link DSL-526B User Manual...
  • Page 57 Encapsulation Mode. Click the Next button to continue. For further information about each of the five connection types available on the Router, please go to the Quick Setup section earlier in this manual as all of the windows are identical. D-Link DSL-526B User Manual...

  • Page 58: Lan

    Configure the second IP Address and Subnet Mask for LAN interface check box and typing in the second IP Address and Subnet Mask in the appropriate boxes. When you are finished, click either the Save or Save/Reboot button. D-Link DSL-526B User Manual...

  • Page 59: Nat

    You can also configure the External Port Start, External Port End, Protocol, Internal Port Start, Internal Port End and Remote IP settings for the service you want to setup on your Router. When you have finished configuring the virtual server click the Save/Apply button. D-Link DSL-526B User Manual...
  • Page 60 Click the DMZ Host link in the NAT directory to add a new DMZ host entry in your Router. Enter the IP address of the host you want to put in the DMZ in the DMZ Host IP Address textbox. Press the Save/Apply button when you have finished. D-Link DSL-526B User Manual...

  • Page 61: Quality Of Service

    Click the Add button to add a new QoS Queue Configuration table entry. This window allows you to configure a QoS queue entry and assign it a specific network interface. Click the Save/Apply button to save and activate the filter. D-Link DSL-526B User Manual...

  • Page 62: Qos Classification

    Please remember that all of the specified conditions on this window must be met for the rule to take effect. Click the Save/Apply button to save and activate this rule. D-Link DSL-526B User Manual...

  • Page 63: Routing

    Enter the static routing information for an entry to the routing table. Click the Save/Apply button when you are finished. To activate the RIP protocol on the Router click on the RIP link in the Routing directory. D-Link DSL-526B User Manual...
  • Page 64 Configure the interfaces you want to enable RIP on and choose the Version and Operation modes from the appropriate drop-down menus. Tick the Enabled checkbox to enable RIP on the interface. Click the Save/Apply button when you are finished. D-Link DSL-526B User Manual...

  • Page 65: Dns

    The DSL-526B router supports Dynamic DNS from two providers, DynDNS.org and TZO. This feature allows you to alias a dynamic IP address to a static hostname, allowing your DSL router to be more easily accessed from various locations on the Internet. To configure Dynamic DNS click the Dynamic DNS link in the DNS directory.
  • Page 66 Select the Interface you want to enable DDNS from the Interface drop-down menu. If your Dynamic DNS service provider is DynDNS.org type in your DynDNS.org Username and Password in the appropriate boxes. Press the Save/Apply button when you have finished. D-Link DSL-526B User Manual...
  • Page 67 If your Dynamic DNS service provider is TZO type in the e-mail address you have registered with TZO in the Email textbox. Type in the Key you have registered with TZO in the Key textbox. Press the Save/Apply button when you have finished. D-Link DSL-526B User Manual...

  • Page 68: Dsl

    Choose the Inner pair or Outer pair option by clicking the appropriate radio button. Tick the text boxes of the capability options you want to enable. Click the Save/Apply button when you are finished. Click the Advanced Settings button to select a DSL test mode. D-Link DSL-526B User Manual...
  • Page 69 Select the desired DSL test mode and then click the Apply button. Click the Tone Selection button to modify the upstream and downstream tones. Select the appropriate upstream and downstream tones for your ADSL connection. Click the Apply button to let your settings take effect. D-Link DSL-526B User Manual...

  • Page 70: Diagnostics

    This window is used to test connectivity of the Router. The results of the test display immediately. Click the Rerun Diagnostic Tests button to rerun the tests to both your local network connection and your DSL service provider. D-Link DSL-526B User Manual...

  • Page 71: Management

    Settings windows, click the Settings link in the Management directory. To backup the router settings click the Backup link. This window allows you to backup your DSL Router configuration Click the Backup Settings button to save your Router configuration to a file on your computer. D-Link DSL-526B User Manual...
  • Page 72 To restore the router configuration to default settings click the Restore Default link. This window allows you to restore your DSL Router configuration to factory default settings. Click the Restore Default Settings button to restore your Router to factory default settings. D-Link DSL-526B User Manual...

  • Page 73: System Log

    System Log server. Click the Enable radio button. Select the Log Level, Display Level and Mode from the appropriate drop-down menus. When you have finished configuring the system log, click the Save/Apply button. D-Link DSL-526B User Manual...

  • Page 74: Tr-069 Client

    Type in the Password you want the Auto Configuration Server to login with in the Connection Request Password field. Click the GetRPCMethods button to populate the TR-069 settings automatically from the tot ISP. When you have finished configuring the TR-069 settings, click the Save/Apply button. D-Link DSL-526B User Manual...

  • Page 75: Internet Time

    Select a secondary time server from the Second NTP time server drop-down menu. Select the time zone you are in from the Time Zone offset drop-down menu. When you have finished configuring the Time Settings click the Save/Apply button. D-Link DSL-526B User Manual...

  • Page 76: Access Control

    Mode. To add an IP address management station, click the Add button. Enter the IP address of the management station permitted to access the local management services in the IP Address field. When you are finished, click the Save/Apply button. D-Link DSL-526B User Manual...

  • Page 77: Update Software

    This window allows you to update the Router’s software. Click the Browse button to navigate to the location where the updated software file is located. Once you have located the file click the Update Software button to update the software on the Router. D-Link DSL-526B User Manual...

  • Page 78: Save/Reboot

    Section 3 – Configuration Save/Reboot To access this window, click the Save/Reboot link in the Management directory. To save your settings and reboot the system, click the Save/Reboot button. D-Link DSL-526B User Manual...

  • Page 79: Troubleshooting

    (The examples below are illustrated in Windows® XP. If you have a different operating system, the screenshots on your computer will look similar to the following examples.) 1. How do I configure my DSL-526B Router without the CD-ROM? ® æ ¦ ¡ ¤ Æ : ¶...
  • Page 80 There is a potential security issue if the firewall is disabled on your PC. Please remember to turn it back on once you have finished the whole installation procedure. This will enable you to surf the Internet without any problems. D-Link DSL-526B User Manual...

  • Page 81: Networking Basics

    Check Your IP Address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 82: Statically Assigning An Ip Address

    Set the Primary DNS to be the same as the LAN IP address of your router (192.168.1.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Step 5 Click on the OK button twice to save your settings. D-Link DSL-526B User Manual...

  • Page 83: Technical Specifications

    • RFC1058 RIP v1 • RFC2131 DHCP Client / • RFC1213 SNMP v1 & v2c • RFC1334 PAP DHCP Server • RFC2364 PPP over ATM • RFC1389 RIP v2 • RFC2516 PPP over • RFC1577 Classical IP over Ethernet D-Link DSL-526B User Manual...
