GENERAL NOTES This guide has been edited for the CONSUMER according to directive CE897392 and its ensuing amendments. Carefully read the notes contained in this guide since they provide important directions regarding the safety of assembling, use and maintenance. Each machine, in accordance with directive CE897392 and its ensuing amendments, is identified by a specific plate positioned on the frame and containing the following information.
CONDITION OF USE CONSENTED USES The 24” Battery Vacuum Sweeper is built for cleaning the ground in the following conditions of employment: a - Environments: *Both closed and opened. b - Working surfaces: *Level surfaces enough compact and not much irregular as: - Ceramics - Wood - Marble...
UNPACKING AND SETUP OF THE MACHINE 1- Remove the packing and make sure of the machine integrity. 2- Before using the machine proceed in this way: 2.1 Take from the Waste Hopper Table B-1 the Side Broom – Table A-20 2.2 Unscrew the screw and washers Table A-24 from the Gearmotor Table A-15.
Page 5
Main broom Operating the switch (Figure 1-2) the main broom Table C- 14 starts to work reaching immediately the running speed. The lighting of a green LED signals the regular operation. With the main broom working it is possible to operate: Side broom Operating the switch (Figure 1-3) the side broom will start working.
ORDINARY MAINTENANCE Maintenance and replacement of the main broom: a- Cleaning: Check periodically, according to the use of the machine, the wear conditions of the main broom Table C-14. To carry out this operation, the following tools are needed: - Heavy-duty gloves. - Breathing mask.
Page 7
Maintenance and replacement of the filter: To carry out this procedure the following tools are needed: - Heavy duty gloves. - Breathing mask. a- Cleaning / Replacement: - Withdraw the split pin Table B- 11 from the hole of the Pin Table B -11 that hold the filter- support (Table B- 10) at the machine frame.
Page 8
Maintenance and replacement of the electronic circuit board: In case of non-operation of some electrical components, check out the integrity of the fuses: Figure 2 - F2 In case of a non good operation of the function of battery charging, check out the integrity of the fuses: Figure 2 - F1 Figure 3 - FUN...
Page 11
TABLE A-SPARE PARTS POS. CODE DESCRIPTION P 030 33110 COVER 3 017 E400B WIRED COMMANDS CONSOLE (SWITCHES BOX) 4 100 33201 HANDLE K 999 00001 HANDLE ADJUSTING KIT K 999 00002 HANDLE PIVOT KIT 4 350 33200 BATTERY STRAP 8 600 33030 GEL SEALED BATTERY 12V 42AH 3 015 A400B VACUUM FAN UNIT...
Page 12
TABLE B - SPARE PARTS - POS. CODE DESCRIPTION 4 018 A400B ELECTRONICS CONTROL BOARD E FUS 01003 FUSE 1.5 A 4 018 33011 TRANSFORMER S CAV 01010 COILED CABLE K 999 00007 REAR WHEEL KIT 4 310 33140 GASKET 8 119 33100 CLAMP LEVER E FUS 02002...
Page 13
TABLE C - SPARE PARTS - POS. CODE DESCRIPTION 4 202 04444 SIDE BROOM ADJUSTMENT LABEL K 999 00009 LEFT CAM KIT 4 320 33201 SIDE FLAP RUBBER 4 240 33250 MAIN BROOM SHORT SPACER 4 260 33170 MAIN BROOM PULLEY HUB 4 270 33151 MAIN BROOM SHAFT 4 340 33151...
Warranty Policy Limited Warranty Eagle Power Products (EPP) warrants new cleaning equipment against defects in material and workmanship under normal use and service to the original purchaser as detailed below. 10 Years Subject to the conditions stated below, EPP warrants polyethylene tanks and housings to be free from defects in materials and workmanship for a period of ten years.
