Flail Mowers
Features and Benefits
Flail Mowers
Features
60" & 72" Cutting widths
25-55 HP gearbox rating
3-Point hitch can be centered
or offset 6 1/4" to the right
One year gearbox warranty
3/4" – 4" Cutting height
1" Cutting capacity
3 Fine cut knives per hanger
4 1/4" Rotor diameter
Reverse rotor rotation
High knife tip speed
Cat. 4 driveline with
over-running clutch
3 - "B" Section belts
Baffles on the top inside of the
deck
Height adjusting roller
Standard scrapers on rear
height adjusting roller
Adjustable rear panel
Designs, specifications, features and information are subject to change without notice.
6/24/10
FM20
Good cutting widths for applications in this HP range.
Fits a large array of consumer, municipality and landscape of tractors.
The two position hitch allows the mower to be centered behind the tractor or offset 6 1/4" to
the left for a closer cut alongside buildings, fences and roadsides.
The gearbox is designed tough to withstand the rigors of flail mowing.
Variable cutting heights for many uses.
Lowest cutting height allows for scalping in grasses such as Bermuda prior to overseeding.
Can cut small saplings.
Heavy enough to cut 1" material and cuts fine enough to groom a yard.
Large rotor diameter protects against obstructions.
Brings the cut material up and over which allows it to be dispersed more evenly.
Knife tip speed of 8,705 fpm provides for a clean cut.
Upon disengaging the PTO, the over-running clutch allows the driveline to quit turning, while
the clutch yoke, gearbox and rotor shaft slow down under their own inertia.
"B" Section belts fit snug in the sheaves, and the multiple belts ensure positive transfer of
power.
Keeps the cut material from clumping together, ensuring an even distribution of clippings.
Rear height adjusting roller with greaseable bearings and tapered ends to prevent gouging
during turns.
Keeps the roller clean for consistent cutting height.
Adjusts to allow strong discharge of material and aids in cleaning underside of deck.
Benefits
30
309-100F
