FULL DEPTH RADIANT GAS FIRE
FOR USE WITH
CHLOE - JULIET - NEW WAVE - HEAT WAVE - MEDIA - CHURCHILL
ANNABELLE - ZARA - CARMEN - CARMEN HIW
INSTALLATION AND USER INSTRUCTIONS
All instructions must be handed to user for safekeeping
Revision C - 11/09
Country(s) of destination - GB/IE
Pure Glow Limited • Stourvale Road • Lye • Stourbridge • West Midlands • DY9 8PP
Tel: +44 1384 893060 • Fax: +44 1384 897728 • e-mail:info@pureglowltd.co.uk
Advertisement
Table of Contents
Related Manuals for PUREGLOW CHLOE
Summary of Contents for PUREGLOW CHLOE
- Page 1 FULL DEPTH RADIANT GAS FIRE FOR USE WITH CHLOE - JULIET - NEW WAVE - HEAT WAVE - MEDIA - CHURCHILL ANNABELLE - ZARA - CARMEN - CARMEN HIW INSTALLATION AND USER INSTRUCTIONS All instructions must be handed to user for safekeeping...
- Page 2 Chloe Juliet Churchill Annabelle Zara Carmen Preliminary Notes Before Installation This appliance is an Inset Live Fuel Effect appliance that provides radiant warmth utilising the latest type burn- er technology. The fire is designed to fit various types of fireplaces and natural...
-
Page 3: Table Of Contents
I N S T A L L A T I O N I N S T R U C T I O N S Section Contents Page No. Section Contents Page No. Important Notes 11.2 Fitting the Burner Tray Appliance Data 12.0 Fuel Bed Layout Installation Requirements... -
Page 4: Appliance Data
APPLIANCE DATA Manual Control Version Slide Control Version Gas Group G20 Natural Gas CAT I2H G20 Natural Gas CAT I2H Inlet Pressure 20 mbar (+/- 2.0mbar) 20 mbar (+/- 2.0mbar) Max Energy Input (gross) 6.8 kW 6.8 kW Min Energy Input (gross) 3.5 kW 3.5 kW Pilot Energy Input (gross) -
Page 5: Site Requirements
SITE REQUIREMENTS The fireplace opening should be inspected and repairs made where necessary. Any chair brick or fireback may be left in situ, providing that the dimensional requirements for debris collection space and spigot clearances are met. See diagram below.. The opening WIDTH and HEIGHT dimensions should be between 375mm and 450mm wide, and 540mm (see note below) to 575mm high. -
Page 6: Debris Collection Space
DEBRIS COLLECTION SPACE The mounting depth of this appliance is 180mm. In accordance with BS 5871 part 2, minimum debris collection volumes are required behind the installed appliance. These are shown in the table below and as dimension X on the fireplace diagram shown previously. CLAY/CEMENT LINES OR BLOCK FLUE WHICH IS NEW, UNUSED, OR PREVIOUSLY ONLY USED WITH A GAS FIRE. -
Page 7: Component Checklist
DESCRIPTION Firebox and burner tray assembly Decorative cast frame with cast ash pan cover (Chloe, Juliet, Annabelle, Zara, Carmen, Carmen HIW and Churchill models) Three piece decorative trim (New wave, Heat wave and Media models) Cast firefront (New wave, Heat wave and Media models) -
Page 8: Fitting The Decorative Frame
The firefront shown in these instruc- tions may differ from the one supplied with the appliance. Chloe, Juliet, Annabelle, Zara, Carmen, Carmen HIW and Churchill models; The decorative frames must be fitted later - refer to section 13 of these instructions. -
Page 9: Fitting The Firebox
10.0 GAS SUPPLY ROUTING (continued) The gas pipe must be suitably protected where it passes through fireplace openings. Any sleeving should be sealed to the pipe at its ends. This appliance is fitted with an inlet restrictor elbow. The open end of the supply pipe should be sealed temporarily during the installation of the firebox to prevent the ingress of dirt and dust. FITTING THE FIREBOX 11.0 The firebox may be fitted to the opening by using screw fixing or by the cable kit as described in the relevant section. -
Page 10: Fuel Bed Layout
1 x ‘PP3’ (9 volt) battery. 13.1 FITTING THE DECORATIVE FRAME / FIREFRONT Chloe, Juliet, Annabelle, Zara, Carmen, Carmen HIW and Churchill models; Remove the decorative frame from it’s protective packaging. The frame is supplied with pre attached magnets. Simply place the frame onto the front of the firebox and slide the ashpan door into place. -
Page 11: Flue Spillage Monitoring System
14.4 SETTING PRESSURE (continued) solder flashing across a joint. (NOTE: you will not get an accurate reading of the inlet pressure with a pressure gauge on the end of the sup- ply pipe - this is the static pressure in the system. You must use a T piece and measure the supply pressure with the fire on High - the dynam- ic pressure). -
Page 12: Dismantling The Burner Tray
16.0 SERVICING (continued) 12. Clean out the injector, pilot assembly and burner tube. DO NOT remove the pilot injector. 13. Re-assemble and re-fit the burner tray. 14. Turn on the gas supply, and leak test. 15. Refit the decorative casting and ceramics. 16. -
Page 13: Troubleshooting Guide
17.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. Pilot lights but then goes out Severe restriction in gas supply, clear obstruction. - Page 14 U S E R I N S T R U C T I O N S Section Contents Page No. Important Notes Firefront Clearances to Combustibles Ventilation Fuel Bed Layout (coal versions) Fuel Bed Layout (pebble versions) Servicing Operating Instructions (Manual Control Versions) Operating Instructions (Slide Control Versions) Flue Spillage Monitoring System Cleaning...
-
Page 15: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. A non-combustible shelf may be fitted to within 10mm of the top edge of the fireframe. Combustible materials, such as wood, may be fitted to within 100mm (4in) of either side of the frame of the appliance, providing the forward projection does not exceed 100mm (4in). - Page 16 FUEL BED LAYOUT (continued) 3. Open the bag of 16 moulded coals. All of the coals are the same. Take five coals and place them as shown. Care should be taken to ensure that the coals bridge the gap between the front coal and the four coal supports at the front of the matrix.
- Page 17 FUEL BED LAYOUT (continued) 2. Open the bag of 16 ceramic pebbles. All of these pebbles are the same size. Take five pebbles and place them as shown. Care should be taken to ensure that the pebbles bridge the gap between the front strip and the four supports at the front of the matrix.
-
Page 18: List Of Spares
OPERATING THE APPLIANCE (manual versions) The pilot is visible through the left hand side of the matrix. Rotate the coals or pebbles for good viewing. Push in and turn the control knob to the SPARK position, and hold there for a few seconds. Continue turning anti-clockwise through the spark click to the PILOT light position, ensuring the pilot has lit.
