Land Pride RCC5615 Parts Manual

Land Pride RCC5615 Parts Manual

Rotary cutters
Hide thumbs
Table of Contents

Advertisement

Quick Links

Rotary Cutters
RCC5615 & RCCM5615
26666
Table of Contents
Part Number Index
Read the Operator's manual entirely. When
you see this symbol, the subsequent
instructions and warnings are serious - follow
without exception. Your life and the lives of
others depend on it!
© Copyright 2011 Printed 03/16/12
Cover photo may show optional equipment not
supplied with standard unit.
330-402P
Parts Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCC5615 and is the answer not in the manual?

Questions and answers

Related Manuals for Land Pride RCC5615

Summary of Contents for Land Pride RCC5615

  • Page 1 Table of Contents Rotary Cutters RCC5615 & RCCM5615 26666 Part Number Index Parts Manual Read the Operator's manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! ©...

  • Page 2: Table Of Contents

    © Copyright 2011. All rights reserved. Land Pride provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been taken in the preparation of this manual, Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit.
  • Page 3 Hydraulic Cylinder (810-644C) Midway...142 Hydraulic Independent Wing Control Accessory...144 Hydraulic Valve Selector Assessory...146 Hydraulic Valve Spool Control Accessory...148 Label Placement...150 Leveling Rod & Wing Turnbuckle...28 Shredder/Baffle Components Center Deck...152 Shredder/Baffle Components LH Deck...154 Shredder/Baffle Components RH Deck...156 RCC5615 & RCCM5615 Rotary Cutters 330-402P...

  • Page 4: Section 1: Introduction

    Table of Contents Part Number Index RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...

  • Page 5: Hardware Legend

    Table of Contents Part Number Index 03/16/12 RCC5615 & RCCM5615 Rotary Cutters 330-402P...

  • Page 6: Section 2: Decks & Hitches

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Blade Carrier S/N 509781+ Applies to RCC5615, RCCM5615 24645 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 7 03/16/12 Part Number Index Comments Revision As Required As Required As Required As Required Left Wing Section Right Wing Section Center Section Left Wing Section Center Section Right Wing Section With Manual RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 8: Deck Center Section (Rc56)

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Deck Center Section (RC56) Applies to RCC5615, RCCM5615 26555 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 9 RCM5615 RCCM5615 S/N 654277- RCM5615 RCCM5615 RCM5615 RCCM5615 S/N ______+ RCM5615 RCCM5615 S/N ______- 540 RPM & 1000 RPM CAT 5 540 RPM CAT 4 1000 RPM CAT 4 RC5615 RCC5615 RCM5615 RCCM5615 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...
  • Page 10 HHCS 5/8-11X5 GR5 804-029C WASHER FLAT 1 SAE 805-104C PIN COTTER 3/16 X 1 1/2 PLT 805-131C PIN CLEVIS 1 X 4 11/16 USABLE RCC5615 & RCCM5615 Rotary Cutters 330-402P Part Number Index Comments Revision ITG BOX OMNI BOX ITG BOX...
  • Page 11 Table of Contents Part Number Index Section 2: Decks & Hitches Land Pride Deck Center Section (RC56) (continued) Applies to RCC5615, RCCM5615 This Page Intentionally Left Blank 03/16/12 RCC5615 & RCCM5615 Rotary Cutters 330-402P...

  • Page 12: Deck Wing Section (Rc56)

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Deck Wing Section (RC56) Applies to RCC5615, RCCM5615 26554 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 13 With Deck Rings Not Available on RCC(M)5615 With Deck Rings Not Available on RCC(M)5615 Order 330-219S Per Color Option Order 330-220S Per Color Option Beige & Yellow Unit Beige & Yellow Unit RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...
  • Page 14 GBOX RC50 1:1.46 CW 826-319C GBOX RCM50 1.75-20 1:1.21 CW 826-486C COMER U0.125.7003.00 OIL PLUG 840-273C PLUG LP 3" ID RUBBER RCC5615 & RCCM5615 Rotary Cutters 330-402P Part Number Index Comments Revision RC5615, RCM5615, RCC5615 & RCCM5615 Cat 4 RC5615, RCM5615, RCC5615 &...
  • Page 15 Table of Contents Part Number Index Section 2: Decks & Hitches Land Pride Deck Wing Section (RC56) (continued) Applies to RCC5615, RCCM5615 This Page Intentionally Left Blank 03/16/12 RCC5615 & RCCM5615 Rotary Cutters 330-402P...

  • Page 16: Hitch Ball Coupler

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Hitch Ball Coupler Applies to RCC5615, RCCM5615 26568 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 17 HHCS 5/8-11X1 3/4 GR5 802-082C HHCS 1/2-13X1 3/4 GR5 803-304C NUT HEX WHIZ 5/8-11 PLT 803-037C NUT HEX WHIZ 1/2-13 PLT 03/16/12 Part Number Index Comments Revision S/N 615584+ S/N 615583- S/N 615584+ S/N 615583- RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 18: Hitch Bar Tite

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Hitch Bar Tite Applies to RCC5615, RCCM5615 26569 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 19 WASHER FLAT 3/4 SAE PLT 804-171C WASHER FLAT 1 3/8HARD ASTMF436 805-105C PIN COTTER 1/4 X 2 1/2 PLT 890-862C BUSHING 1.50ODX1.00IDX1.25 03/16/12 Part Number Index Comments Revision S/N 615584+ S/N 615583- S/N 615584+ S/N 615583- RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 20: Hitch Main Frame

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Hitch Main Frame Applies to RCC5615, RCCM5615 26556 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 21 WASHER FLAT 1 USS PLT 805-292C PIN 1 X 5 1/2 HRD PLT 890-182C SAFETY CHAIN 10000 LB 890-786C SIDEWIND JACK 7000 LB 890-970C BUSHING 1.25ODX1.00IDX2.87 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 22: Hitch Pintel

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Hitch Pintel Applies to RCC5615, RCCM5615 26570 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 23 PIN COTTER 5/32 X 1 1/4 LG 805-083C PIN CLEVIS 3/4 X 1 1/2 890-806C PINTLE HOOK SQ.BASE BDB1250-15 03/16/12 Part Number Index Comments Revision S/N 615584+ S/N 615583- S/N 615584+ S/N 615583- RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 24: Hitch Standard Pivoting Clevis

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Hitch Standard Pivoting Clevis Applies to RCC5615, RCCM5615 26557 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 25 WASHER FLAT 3/4 SAE PLT 805-045C PIN COTTER 5/32 X 1 1/4 LG 805-083C PIN CLEVIS 3/4 X 1 1/2 03/16/12 Part Number Index Comments Revision S/N 615584+ S/N 615583- S/N 615584+ S/N 615583- RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 26: Hitch Swivel

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Hitch Swivel Applies to RCC5615, RCCM5615 26571 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 27 BUSHING CYL 1 1/4 X 1 X 1 890-850C BUSHING 1 1/4X1X5/8 330-648S ASSY SWIVEL CLEVIS 03/16/12 Part Number Index Comments Revision Replaced By 330-648S S/N 615584+ S/N 615583- S/N 615584+ S/N 615583- RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 28: Leveling Rod & Wing Turnbuckle

    Table of Contents Part Number Index Land Pride Section 2: Decks & Hitches Leveling Rod & Wing Turnbuckle Applies to RCC5615, RCCM5615 26550 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 29 WASHER LOCK 1 1/4 SPRING PLT 805-104C PIN COTTER 3/16 X 1 1/2 PLT 805-374C PIN CLEVIS 1 X 2 1/16 USABLE 890-974C TRNBCKL, 1BORE W/SWIVEL 9.5 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 30: Section 3: Axles

    Table of Contents Part Number Index Land Pride Section 3: Axles Axle Center Row Crop Applies to RCC5615, RCCM5615 26642 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 31 822-033C BRG CUP LM-48510 822-034C BRG CONE LM-48548 890-970C BUSHING 1.25ODX1.00IDX2.87 891-177C BHG 1.50ODX1.25X1.38 814-265C TIRE & WHL LAM. 6X9X21(5-BOLT) 815-244C HUB 5-BOLT COMPLETE 03/16/12 Part Number Index Comments Revision Foam Filled RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 32: Axle Wing Row Crop

    Table of Contents Part Number Index Land Pride Section 3: Axles Axle Wing Row Crop Applies to RCC5615, RCCM5615 26643 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 33 814-378C TIRE, 24" 18 PLY, 5 BOLT 814-379C TIRE, 24" 18 PLY RECAP, 5-BOLT 814-265C TIRE & WHL LAM. 6X9X21(5-BOLT) 815-244C HUB 5-BOLT COMPLETE 03/16/12 Part Number Index Comments Revision Foam Filled RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 34: Section 4: Guards

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Chain Double Row Front Applies to RCC5615, RCCM5615 26545 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 35 NUT HEX WHIZ 1/2-13 PLT 890-175C CHAIN 5/16 PROOF X 6 LINKS PLT 890-341C CHAIN WELD 5/16 PROOF X 5 LINK 890-400C CHAIN WELD 5/16 PROOF X 4 LINK 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 36: Guards Chain Double Row Rear

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Chain Double Row Rear Applies to RCC5615, RCCM5615 26547 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 37 RHSNB 1/2-13X1 1/4 GR5 803-037C NUT HEX WHIZ 1/2-13 PLT 890-341C CHAIN WELD 5/16 PROOF X 5 LINK 890-400C CHAIN WELD 5/16 PROOF X 4 LINK 03/16/12 Part Number Index Comments Revision Shown Shown RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 38: Guards Chain Single Row Front

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Chain Single Row Front Applies to RCC5615, RCCM5615 26543 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 39 RHSNB 1/2-13X1 1/4 GR5 803-037C NUT HEX WHIZ 1/2-13 PLT 890-175C CHAIN 5/16 PROOF X 6 LINKS PLT 890-341C CHAIN WELD 5/16 PROOF X 5 LINK 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 40: Guards Chain Single Row Rear

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Chain Single Row Rear Applies to RCC5615, RCCM5615 26544 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 41 RHSNB 1/2-13X1 1/4 GR5 803-037C NUT HEX WHIZ 1/2-13 PLT 890-341C CHAIN WELD 5/16 PROOF X 5 LINK 890-400C CHAIN WELD 5/16 PROOF X 4 LINK 03/16/12 Part Number Index Comments Revision Shown Shown RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 42: Guards Chain W/ Cable Front

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Chain W/ Cable Front Applies to RCC5615, RCCM5615 26548 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 43 AIRCRAFT CBL.3/16 7X7 GALV. 990-208R AIRCRAFT CBL.3/16 7X7 GALV. 891-236C SWAGE CLAMP, 3/16 CABLE 03/16/12 Part Number Index Comments Revision S/N 670327- 5' Required 6' Required 2' Required S/N 670328+ Or Use 890-672C RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 44: Guards Chain W/ Cable Rear

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Chain W/ Cable Rear Applies to RCC5615, RCCM5615 26549 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 45 AIRCRAFT CBL.3/16 7X7 GALV. 990-208R AIRCRAFT CBL.3/16 7X7 GALV. 891-236C SWAGE CLAMP, 3/16 CABLE 03/16/12 Part Number Index Comments Revision Shown Shown S/N 670327- 9' Required 6' Required S/N 670328+ Or Use 890-672C RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 46: Guards Rubber Front

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Rubber Front Applies to RCC5615, RCCM5615 26541 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 47 RHSNB 1/2-13X1 1/4 GR5 803-037C NUT HEX WHIZ 1/2-13 PLT 816-456C FRONT WING RUBBER GUARD 816-606C RUBBER GUARD FRT CNTR 816-607C RUBBER GUARD FRT CNTR OUT 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 48: Guards Rubber Rear

    Table of Contents Part Number Index Land Pride Section 4: Guards Guards Rubber Rear Applies to RCC5615, RCCM5615 26542 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 49 RHSNB 3/8-16X1 GR5 802-214C RHSNB 1/2-13X1 1/4 GR5 803-037C NUT HEX WHIZ 1/2-13 PLT 803-198C NUT HEX WHIZ 3/8-16 PLT 816-246C RUBBER GUARD REAR 816-608C RUBBERGUARD REAR WING 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 50: Section 5: Drivelines (1000 Rpm)

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Center (826-478C) Comer Applies to RCCM5615 23952 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 51 COMER SHAFT, SPLINED 190.000.016 COMER ROLL PIN, INNER TUBE 151.016.031.1 COMER INNER YOKE 146.264.024.1 COMER CLUTCH, COMPLETE ASSY 165.000.589 COMER TAPERED PIN SET 1 3/4 03/16/12 Part Number Index Comments Revision Cat. 5 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 52: Driveline Center 1000 Rpm (826-184C) Eurocardan

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Center 1000 RPM (826-184C) Eurocardan Applies to RCCM5615 15497 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 53 EC CLUTCH FD2/6 1 3/4 20 SPL 6141280 EC.BOLT 6412112 EC SPRING WASHER 6410112 EC NUT 6560508 EC GREASE ZERK 8X1 45 DEG. 03/16/12 Part Number Index Comments Revision Includes items 7, 8 & 9 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 54: Driveline Conv. 1000 Rpm (826-247C) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Conv. 1000 RPM (826-247C) Walterscheid Applies to RCCM5615 18549 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 55 355155 WS SUPPORT BEARING 702352 WS HEX BOLT M16 X 90 GR 8.8 304011 WS LOCK NUT M16 826-603C SHIELD KIT, 826-247C 359474 WS REINFORCING COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 56: Driveline Cv 1000 Rpm (826-477C) 1 3/8-21 Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline CV 1000 RPM (826-477C) 1 3/8-21 Comer Applies to RCCM5615 23948 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 57 COMER TUBE W/YOKE/LUBE/MALE 1422831442821 COMER HALF FEMALE GRD W/LABEL 1422871642821 COMER HALF MALE GUARDING 180.018.393 COMER CAP OUTER TUBE, PLASTIC 165.000.628 COMER COLLER KIT 3/8 YOKE 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 58: Driveline Cv 1000 Rpm (826-499C) 1 3/4-20 Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline CV 1000 RPM (826-499C) 1 3/4-20 Comer Applies to RCCM5615 23960 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 59 122.580.501.1 COMER TUBE W/YOKE/LUBE/MALE 1422831442821 COMER HALF FEMALE GRD W/LABEL 1422871642821 COMER HALF MALE GUARDING 180.018.393 COMER CAP OUTER TUBE, PLASTIC 165.000.629 COMER YOKE KIT COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 60: Driveline Cv 1000 Rpm (826-644C) Weasler

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline CV 1000 RPM (826-644C) Weasler Applies to RCCM5615 30187 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 61 WE BOLT .625-11 X 3.00L GR8 93-25023 WE JOINT&SHFT HALF ASM W/GUARD 92-24406 WE JOINT&TUBE HALF ASM W/GUARD 91-25023 WE GUARD SET 11-80005 WE CHAIN KIT 03/16/12 Part Number Index Comments Revision S/N 712190+ S/N 712189- RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 62: Driveline Cv 1000 Rpm (826-645C)

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline CV 1000 RPM (826-645C) Applies to RCCM5615 30189 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 63 WE BOLT .625-11 X 3.00L GR8 93-25075 WE JOINT&SHFT HALF ASM W/GUARD 92-25075 WE JOINT&TUBE HALF ASM W/GUARD 11-80005 WE CHAIN KIT 03/16/12 Part Number Index Comments Revision S/N 712190+ S/N 712190- S/N 712190+ RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 64: Driveline Slip Clutch (146.264.024.1) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Slip Clutch (146.264.024.1) Comer Applies to RCCM5615 23957 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 65 COMER CLUTCH SUPPORT 180.019.014 COMER INNER PLATE 180.019.115 COMER INTERMEDIATE PLATE 180.019.116.1 COMER PRESSURE PLATE 165.000.548 COMER BOLT WITH NUT M10X100 165.000.589 COMER TAPERED PIN SET 1 3/4 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 66: Driveline Slip Clutch (146.284.020.1) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Slip Clutch (146.284.020.1) Comer Applies to RCCM5615 23958 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 67 COMER CLUTCH SUPPORT 180.019.014 COMER INNER PLATE 180.019.115 COMER INTERMEDIATE PLATE 180.019.116.1 COMER PRESSURE PLATE 165.000.548 COMER BOLT WITH NUT M10X100 165.000.589 COMER TAPERED PIN SET 1 3/4 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 68: Driveline Slip Clutch (229829X0) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Slip Clutch (229829X0) Walterscheid Applies to RCCM5615 25962 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 69 WS THRUST PLATE 391351 WS BELLEVILLE SPRING 020452 WS HEX BOLT M10X50 803-280C NUT HEX NYLOCK M10X1.5 PLT 301.005 COSMO NUT HEX 020467 WS HEX BOLT M12X65 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 70: Driveline Slip Clutch (395980) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Slip Clutch (395980) Walterscheid Applies to RCCM5615 25961 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 71 WS FRICTION DISK 393916 335603 DRIVE PLATE 393173 DRIVE PLATE 125545 WS BELLEVILLE SPRING 802-486C HHCS M12X1.75X80 GR8.8 PLT 301.005 COSMO NUT HEX 107542 CC LOCK ASSY 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 72: Driveline Slip Clutch 1000 Rpm (1406016) Eurocardan

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Slip Clutch 1000 RPM (1406016) Eurocardan Applies to RCCM5615 15523 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 73 CONICAL DOG KIT 1138008 EC INNER DISK 1138007 EC PRESSURE DISK 6691080 EC COMPLETE BOLT 330-297A EC CLUTCH FD2/6 1 3/4 20 SPL 03/16/12 Part Number Index Comments Revision Contains 8 Springs RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 74: Driveline Slip Clutch 540/1000 Rpm (1446016) Ec

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Slip Clutch 540/1000 RPM (1446016) EC Applies to RCCM5615 15521 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 75 1138007 EC PRESSURE DISK 6691010 EC BOLT & SCREW NUT KIT REPL. 330-297A SV KIT, EC SLIP CLUTCH SPRING 03/16/12 Part Number Index Comments Revision Includes nut and washer Contains 8 Springs RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 76: Driveline Wing (826-185C) Ec New Shielding

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Wing (826-185C) EC New Shielding Applies to RCCM5615 23996 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 77 EC GREASE ZERK M6X1 STRAIGHT 1106025 EC YOKE 6761480 EC BOLT 6410114 EC SCREW NUT (M14) 6412114 EC WASHER (d14) 826-581C SHIELD KIT, 826-185C 03/16/12 Part Number Index Comments Revision Includes 27,28 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 78: Driveline Wing (826-185C) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Wing (826-185C) Walterscheid Applies to RCCM5615 25920 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 79 DRIVELINE SHIELD SAFETY CHAIN 365305 WS SCREW 355155 WS SUPPORT BRG 020466 WS BOLT M12 X 60 - 8.8 301.005 COSMO NUT HEX 359471 WS REINFORCING COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 80: Driveline Wing (826-481C) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Wing (826-481C) Comer Applies to RCCM5615 23953 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 81 COMER TAPERED PIN SET 1 3/4 122.580.023.1 COMER TUBE W/YOKE/LUBE/FEMALE 122.580.511.1 COMER TUBE W/YOKE/LUBE/MALE 1422831949821 COMER HALF FEMALE GRD W/LABEL 1422871029821 COMER HALF MALE GUARDING 180.018.393 COMER CAP OUTER TUBE, PLASTIC 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 82: Driveline Wing (826-481C) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (1000 RPM) Driveline Wing (826-481C) Walterscheid Applies to RCCM5615 25919 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 83 WS SUPPORT BEARING 377436 WS SHIELD CONE - 6 RIB 702352 WS HEX BOLT M16 X 90 GR 8.8 304011 WS LOCK NUT M16 359474 WS REINFORCING COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 84: Section 5: Drivelines (540 Rpm)

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Center (826-478C) Comer Applies to RCC5615 23952 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 85 COMER SHAFT, SPLINED 190.000.016 COMER ROLL PIN, INNER TUBE 151.016.031.1 COMER INNER YOKE 146.264.024.1 COMER CLUTCH, COMPLETE ASSY 165.000.589 COMER TAPERED PIN SET 1 3/4 03/16/12 Part Number Index Comments Revision Cat. 5 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 86: Driveline Center 540 Rpm (826-183C) Eurocardan

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Center 540 RPM (826-183C) Eurocardan Applies to RCC5615 15570 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 87 TORQUE LIMITER 4 FRICTION DISC 6141280 EC.BOLT 6412112 EC SPRING WASHER 6410112 EC NUT 084099 WS ZERK M8 X 1 03/16/12 Part Number Index Comments Revision Includes items 7, 8 & 9 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 88: Driveline Conv. 540 Rpm (826-112C) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Conv. 540 RPM (826-112C) Walterscheid Applies to RCC5615 18548 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 89 WS HEX BOLT M16 X 90 GR 8.8 304011 WS LOCK NUT M16 377442 WS SHIELD CONE - 12 RIB 826-587C SHIELD KIT, 826-112C 359474 WS REINFORCING COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 90: Driveline Cv 540 Rpm (826-476C) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline CV 540 RPM (826-476C) Comer Applies to RCC5615 23947 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 91 COMER TUBE W/YOKE/LUBE /MALE 1422831412821 COMER HLF FEMALE GRD W/LABEL 1422871632821 COMER HALF MALE GUARDING 180.018.393 COMER CAP OUTER TUBE, PLASTIC 165.000.628 COMER COLLER KIT 3/8 YOKE 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 92: Driveline Cv 540 Rpm (826-643C) Weasler

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline CV 540 RPM (826-643C) Weasler Applies to RCC5615 30185 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 93 WE BOLT .625-11 X 3.00L GR8 93-24406 WE JOINT&SHFT HALF ASM W/GUARD 92-24406 WE JOINT&TUBE HALF ASM W/GUARD 91-24406 WE GUARD SET 11-80005 WE CHAIN KIT 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 94: Driveline Slip Clutch (146.264.024.1) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Slip Clutch (146.264.024.1) Comer Applies to RCC5615 23957 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 95 COMER CLUTCH SUPPORT 180.019.014 COMER INNER PLATE 180.019.115 COMER INTERMEDIATE PLATE 180.019.116.1 COMER PRESSURE PLATE 165.000.548 COMER BOLT WITH NUT M10X100 165.000.589 COMER TAPERED PIN SET 1 3/4 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 96: Driveline Slip Clutch (146.284.020.1) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Slip Clutch (146.284.020.1) Comer Applies to RCC5615 23958 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 97 COMER CLUTCH SUPPORT 180.019.014 COMER INNER PLATE 180.019.115 COMER INTERMEDIATE PLATE 180.019.116.1 COMER PRESSURE PLATE 165.000.548 COMER BOLT WITH NUT M10X100 165.000.589 COMER TAPERED PIN SET 1 3/4 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 98: Driveline Slip Clutch (229829X0) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Slip Clutch (229829X0) Walterscheid Applies to RCC5615 25962 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 99 WS THRUST PLATE 391351 WS BELLEVILLE SPRING 020452 WS HEX BOLT M10X50 803-280C NUT HEX NYLOCK M10X1.5 PLT 301.005 COSMO NUT HEX 020467 WS HEX BOLT M12X65 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 100: Driveline Slip Clutch (395980) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Slip Clutch (395980) Walterscheid Applies to RCC5615 25961 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 101 WS FRICTION DISK 393916 335603 DRIVE PLATE 393173 DRIVE PLATE 125545 WS BELLEVILLE SPRING 802-486C HHCS M12X1.75X80 GR8.8 PLT 301.005 COSMO NUT HEX 107542 CC LOCK ASSY 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 102: Driveline Slip Clutch 540/1000 Rpm (1446016) Ec

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Slip Clutch 540/1000 RPM (1446016) EC Applies to RCC5615 15521 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 103 1138007 EC PRESSURE DISK 6691010 EC BOLT & SCREW NUT KIT REPL. 330-297A SV KIT, EC SLIP CLUTCH SPRING 03/16/12 Part Number Index Comments Revision Includes nut and washer Contains 8 Springs RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 104: Driveline Wing (826-185C) Ec New Shielding

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Wing (826-185C) EC New Shielding Applies to RCC5615 23996 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 105 EC GREASE ZERK M6X1 STRAIGHT 1106025 EC YOKE 6761480 EC BOLT 6410114 EC SCREW NUT (M14) 6412114 EC WASHER (d14) 826-581C SHIELD KIT, 826-185C 03/16/12 Part Number Index Comments Revision Includes 27,28 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 106: Driveline Wing (826-185C) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Wing (826-185C) Walterscheid Applies to RCC5615 25920 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 107 DRIVELINE SHIELD SAFETY CHAIN 365305 WS SCREW 355155 WS SUPPORT BRG 020466 WS BOLT M12 X 60 - 8.8 301.005 COSMO NUT HEX 359471 WS REINFORCING COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 108: Driveline Wing (826-481C) Comer

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Wing (826-481C) Comer Applies to RCC5615 23953 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 109 COMER TAPERED PIN SET 1 3/4 122.580.023.1 COMER TUBE W/YOKE/LUBE/FEMALE 122.580.511.1 COMER TUBE W/YOKE/LUBE/MALE 1422831949821 COMER HALF FEMALE GRD W/LABEL 1422871029821 COMER HALF MALE GUARDING 180.018.393 COMER CAP OUTER TUBE, PLASTIC 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 110: Driveline Wing (826-481C) Walterscheid

    Table of Contents Part Number Index Land Pride Section 5: Drivelines (540 RPM) Driveline Wing (826-481C) Walterscheid Applies to RCC5615 25919 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 111 WS SUPPORT BEARING 377436 WS SHIELD CONE - 6 RIB 702352 WS HEX BOLT M16 X 90 GR 8.8 304011 WS LOCK NUT M16 359474 WS REINFORCING COLLAR 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 112: Section 6: Gearboxes (1000 Rpm)

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (1000 RPM) Gearbox 1000 RPM (826-317C) Applies to RCCM5615 21167 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 113 CO COTTER PIN B6X70 SLD-SPRTLY 8.2.2.00560 CO CASTLE NUT M36X3 U0.125.6003.00 CO CROWN GEAR Z18 M7.8 Notes: Oil Type 80-90W Capacity 10 Pints 03/16/12 Part Number Index Comments Revision L. H. Deck RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 114: Gearbox 1000 Rpm (826-318C)

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (1000 RPM) Gearbox 1000 RPM (826-318C) Applies to RCCM5615 21167 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 115 8.4.7.01045 CO COTTER PIN B6X70 SLD-SPRTLY 8.2.2.00560 CO CASTLE NUT M36X3 U0.125.5003.00 CO CROWN GEAR Z22 M7.8 Notes: Oil Type 80-90W Capacity 10 Pints 03/16/12 Part Number Index Comments Revision Center Deck RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 116: Gearbox 1000 Rpm (826-319C)

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (1000 RPM) Gearbox 1000 RPM (826-319C) Applies to RCCM5615 21171 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 117 COMER U0.125.7003.00 OIL PLUG 8.6.5.00006 CO OIL PLUG 3/8 8.4.7.01045 CO COTTER PIN B6X70 SLD-SPRTLY 8.2.2.00560 CO CASTLE NUT M36X3 U0.125.6003.00 CO CROWN GEAR Z18 M7.8 03/16/12 Part Number Index Comments Revision R. H. Deck RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 118: Gearbox Divider 1000 Rpm (826-521C) Comer

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (1000 RPM) Gearbox Divider 1000 RPM (826-521C) Comer Applies to RCCM5615 26960 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 119 CO SHAFT 1" 3/4 Z20 0.305.6000.00 CO GEAR M6.5 Z20 8.6.6.00201 CO PLUG 3/8 GAS 8.6.7.00269 CO 1/2" GAS BREATHER PLUG Notes: Oil Type 80-90W Capacity 5.5 Pints 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 120: Gearbox Divider 1000 Rpm (826-521C) Itg

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (1000 RPM) Gearbox Divider 1000 RPM (826-521C) ITG Applies to RCCM5615 25682 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 121 12-008 ITG COTTER PIN 07-022 ITG SEALING WASHER 09-013 ITG DRAIN PLUG 09-011 ITG M18 X 1.5P PLUG VENTED Notes: Oil Type 80-90W Capacity 5.5 Pints 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 122: Gearbox Divider 1000 Rpm (826-521C) Omni

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (1000 RPM) Gearbox Divider 1000 RPM (826-521C) Omni Applies to RCCM5615 26707 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 123 OMNI LOCKNUT, TN-06 130030 OMNI LOCKWASHER, TW-06 130021 OMNI FLAT WASHER 140046 OMNI LEVEL PLUG 1/2-14NPT,PRW 200003 OMNI RETAINING RING Notes: Oil Type 80-90W Capacity 5.5 Pints 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 124: Section 6: Gearboxes (540 Rpm)

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (540 RPM) Gearbox 540 RPM (826-315C) Applies to RCC5615 21167 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 125 CO COTTER PIN B6X70 SLD-SPRTLY 8.2.2.00560 CO CASTLE NUT M36X3 U0.125.6004.00 CO CROWN GEAR Z15 M8 Notes: Oil Type 80-90W Capacity 10 Pints 03/16/12 Part Number Index Comments Revision Center & L. H. Deck RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 126: Gearbox 540 Rpm (826-316C)

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (540 RPM) Gearbox 540 RPM (826-316C) Applies to RCC5615 21171 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 127 CO COTTER PIN B6X70 SLD-SPRTLY 8.2.2.00560 CO CASTLE NUT M36X3 U0.125.6004.00 CO CROWN GEAR Z15 M8 Notes: Oil Type 80-90W Capacity 10 Pints 03/16/12 Part Number Index Comments Revision R. H. Deck RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 128: Gearbox Divider 540 Rpm (826-520C) Comer

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (540 RPM) Gearbox Divider 540 RPM (826-520C) Comer Applies to RCC5615 26959 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 129 CO SHAFT 1" 3/4 Z20 0.305.5001.00 CO GEAR M6.5 Z24 8.6.6.00201 CO PLUG 3/8 GAS 826-497C COMER VENT #8.6.7.00269 Notes: Oil Type 80-90W Capacity 5.5 Pints 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 130: Gearbox Divider 540 Rpm (826-520C) Itg

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (540 RPM) Gearbox Divider 540 RPM (826-520C) ITG Applies to RCC5615 25681 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 131 12-008 ITG COTTER PIN 07-022 ITG SEALING WASHER 09-013 ITG DRAIN PLUG 09-011 ITG M18 X 1.5P PLUG VENTED Notes: Oil Type 80-90W Capacity 5.5 Pints 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 132: Gearbox Divider 540 Rpm (826-520C) Omni

    Table of Contents Part Number Index Land Pride Section 6: Gearboxes (540 RPM) Gearbox Divider 540 RPM (826-520C) Omni Applies to RCC5615 26706 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 133 OMNI LOCKNUT, TN-06 130030 OMNI LOCKWASHER, TW-06 130021 OMNI FLAT WASHER 140046 OMNI LEVEL PLUG 1/2-14NPT,PRW 200003 OMNI RETAINING RING Notes: Oil Type 80-90W Capacity 5.5 Pints 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 134: Section 7: Hydraulics

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Lift Components Applies to RCC5615, RCCM5615 26644 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 135 TE 9/16MJIC BH 9/16MJIC 9/16MJ 811-394C CP 3/4FORB MALE QD POPPET TYPE 811-619C HH3/8R1 168 3/4MORB 3/4FJIC 811-633C HH3/8R1 162 3/4MORB 9/16 FJIC 841-283C HH1/4R1 028 9/16FJIC 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 136: Hydraulic Cylinder (810-162C) Cross

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Cylinder (810-162C) Cross Applies to RCC5615, RCCM5615 11421 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 137 Comments Revision Only available in Seal Kit (#19) Only available in Seal Kit (#19) Only available in Seal Kit (#19) Only available in Seal Kit (#19) Only available in Seal Kit (#19) RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 138: Hydraulic Cylinder (810-162C) Midway

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Cylinder (810-162C) Midway Applies to RCC5615, RCCM5615 11421 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 139 Comments Revision Only available in Seal Kit (#19) Only available in Seal Kit (#19) Only available in Seal Kit (#19) Only available in Seal Kit (#19) Only available in Seal Kit (#19) RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 140: Hydraulic Cylinder (810-162C) Red Lion

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Cylinder (810-162C) Red Lion Applies to RCC5615, RCCM5615 25900 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 141 Comments Revision Only Found in Kit #20 Only Found in Kit #20 Only Found in Kit #20 Only Found in Kit #20 Only Found in Kit #20 Only Found in Kit #20 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 142: Hydraulic Cylinder (810-644C) Midway

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Cylinder (810-644C) Midway Applies to RCC5615, RCCM5615 26663 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 143 Comments Revision Only available in item #21 Only available in item #21 Only available in item #21 Only available in item #21 Only available in item #21 Only available in item #21 RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 144: Hydraulic Independent Wing Control Accessory

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Independent Wing Control Accessory Applies to RCC5615, RCCM5615 25519 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 145 Part Description dwg25519 Drawing Image Number 318-316A HYDRAULIC WING CONTROL ASSY. 811-315C AD 9/16MJIC 811-394C CP 3/4FORB MALE QD POPPET TYPE 811-633C HH3/8R1 162 3/4MORB 9/16 FJIC 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 146: Hydraulic Valve Selector Assessory

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Valve Selector Assessory Applies to RCC5615, RCCM5615 19893 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 147 2-WAY SELECTOR VLV KIT 811-358C HH1/4R1 265 1/2MNPT 9/16FJIC 811-021C AD 1/2FNPTS 3/4MORB 810-152C SELECTOR VALVE 3-WAY 2 POS 811-088C AD 3/4MORB 3/4MJIC 811-360C HH3/8R2 60 1/2MNPT 3/4FJIC 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 148: Hydraulic Valve Spool Control Accessory

    Table of Contents Part Number Index Land Pride Section 7: Hydraulics Hydraulic Valve Spool Control Accessory Applies to RCC5615, RCCM5615 11196 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...

  • Page 149: Part Number Index

    HH1/4R1 265 1/2MNPT 9/16FJIC 811-290C AD 3/4MJIC 1/2FNPT 811-359C EL 3/4MJIC X 3/4MNPT 811-008C EL 1/2MNPT 1/2FNPTS 811-360C HH3/8R2 60 1/2MNPT 3/4FJIC 810-402C CROSS SEAL KIT 2V0010 03/16/12 Part Number Index Comments Revision RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 150: Section 8: Labels

    Table of Contents Part Number Index Land Pride Section 8: Labels Label Placement Applies to RCC5615, RCCM5615 26713 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 151 Beige & Green Unit Red Unit Orange Unit Beige & Green Unit Red Unit Orange Unit Beige Unit Green Unit & Red Unit Orange Unit Beige Unit Green Unit & Red Unit Orange Unit RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 152: Section 9: Options & Accessories

    Table of Contents Part Number Index Land Pride Section 9: Options & Accessories Shredder/Baffle Components Center Deck Applies to RCC5615, RCCM5615 26674 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 153 WASHER FLAT 1/2 USS PLT 820-169C CUTTER BLADE 1/2X4X23 CCW 820-373C CUTTER BLADE 1/2X4X10.25CW/CCW 820-377C CUTTER BLADE 1/2X4X23.5 FLAT 03/16/12 Part Number Index Comments Revision As Required As Required As Required As Required RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 154: Shredder/Baffle Components Lh Deck

    Table of Contents Part Number Index Land Pride Section 9: Options & Accessories Shredder/Baffle Components LH Deck Applies to RCC5615, RCCM5615 26673 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 155 WASHER FLAT 1/2 USS PLT 820-169C CUTTER BLADE 1/2X4X23 CCW 820-373C CUTTER BLADE 1/2X4X10.25CW/CCW 820-377C CUTTER BLADE 1/2X4X23.5 FLAT 03/16/12 Part Number Index Comments Revision As Required As Required As Required As Required RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 156: Shredder/Baffle Components Rh Deck

    Table of Contents Part Number Index Land Pride Section 9: Options & Accessories Shredder/Baffle Components RH Deck Applies to RCC5615, RCCM5615 26672 RCC5615 & RCCM5615 Rotary Cutters 330-402P 03/16/12...
  • Page 157 WASHER FLAT 1/2 USS PLT 820-170C CUTTER BLADE 1/2X4X23 CW 820-373C CUTTER BLADE 1/2X4X10.25CW/CCW 820-377C CUTTER BLADE 1/2X4X23.5 FLAT 03/16/12 Part Number Index Comments Revision As Required As Required As Required As Required RCC5615 & RCCM5615 Rotary Cutters 330-402P Land Pride...

  • Page 158: Part Number Index

    097133 ... 55, 83, 89, 111 155.150.724 ... 097140 ... 55, 83, 89, 111 158.018.470 ... 165.000.548 ... RCC5615 & RCCM5615 Rotary Cutters 330-402P Part Number Index Page Part Number Page 113, 115, 117, 165.000.589 ... 51, 57, 59, 65,...
  • Page 159 125, 127 8.1.1.00109 ... 119, 129 55, 79, 83, 89, 8.1.1.00501 ... 113, 115, 117, 107, 111 125, 127 RCC5615 & RCCM5615 Rotary Cutters 330-402P (continued) Part Number Page 8.2.2.00555 ... 9, 13 8.2.2.00560 ... 113, 115, 117, 125, 127 8.4.7.01045 ...
  • Page 160 818-900C ... 805-292C ... 21, 31, 33 820-168C ... 805-309C ... 820-169C ... 805-374C ... 29, 31 820-170C ... RCC5615 & RCCM5615 Rotary Cutters 330-402P Part Number Index (continued) Page Part Number 820-373C ... 820-377C ... 10, 135 822-020C ...
  • Page 161 125, 127 U0.125.5003.00 ... 113, 115, 117 U0.125.5005.00 ... 125, 127 U0.125.6003.00 ... 113, 115, 117 U0.125.6004.00 ... 125, 127 U0.125.7100.00 ... 113, 115, 117, 125, 127 03/16/12 Part Number Index Part Number Index RCC5615 & RCCM5615 Rotary Cutters 330-402P (continued)
  • Page 162 Great Plains Manufacturing, Inc. Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...

This manual is also suitable for:

Rccm5615

Table of Contents
