Land Pride RCR3515 Features And Benefits

Features and Benefits
Rotary Cutters, Folding Deck

Features

Surpassed rugged
industry standards
Mostly factory assembled
5 Year gearbox warranty
Gearbox seal protection
160 HP splitter gearbox
110 HP center & wing gearboxes
540 or 1000 RPM PTO speed
4 Gearboxes vs. 3
Low tongue weight
Narrow tongue construction
Round back design
Input Driveline: Cat. 5 CV
Wing driveline:
Cat. 4 with slip-clutch
Slip-clutch drivelines
High Blade tip speed
(See Specifications for actual FPM)
6" Blade overlap
Left wing rotates clockwise
2" to 14" Cutting Height
3/16" Round stump jumper
1/4" Sidewall thickness
Replaceable skid shoes
Self-leveling hitch
Hinged wing sections
1" Solid hinge rods
Wing transport locks
Enclosed front to rear dual leveling
rods
5-Bolt hubs
4 or 6 Wheels
Spring cushioned center-axle
Replaceable wheel spindles
Designs, specifications, features and information are subject to change without notice.
6/28/11
RCR3515 & RCRM3515 Models
Rotary Cutters
All Land Pride
voluntary testing procedures specified by ANSI.
Arrives for quick and easy set-up. Minimal time is wasted setting or prepping the unit.
Shows confidence in gearbox integrity.
Gearbox bottom seal protection for longer bearing life.
High gearbox rating for handling jobs suited for this Rotary Cutter.
High gearbox rating for 2" cutting capacity.
Fits wide variety of tractors in the 50 to 160 HP range.
Spreads overall weight out and evenly disburses horsepower to each spindle.
Ideal for smaller HP tractors by reducing the amount of weight on the drawbar.
Allows for a tighter turning radius.
Allows for more efficient handling and dispersing of material.
Driveline is matched just right for capacity of tractor. Constant velocity (CV) U-joint
allows for 80 degree turns without doing damage to the driveline.
Driveline is sized right for the intended cutting capacity. Slip-clutch will slip under load
instead of twisting the driveline. (Optional Cat. 5 driveline is available.)
Slip-clutches are designed to slip to minimize twist damage to the driveline profiles.
Allows clean cutting of material.
Eliminates skipping during turns.
Better discharge of material. Picks up tractor tracks.
Cover a wide range of cutting conditions.
Standard thick stump jumper material keeps damage to a minimum.
Increased thickness reduces damage from objects being thrown into deck sidewalls.
Skid shoes protect deck in uneven terrain. Can be easily replaced if damaged or worn
out.
Reduces drawbar wear by keeping hitch level while going through ditches.
cutter
Allows to follow terrain. Ideal for rough ground where hillsides, ditches and
hollows can cause uneven cutting.
Larger diameter hinge rod gives greater strength to the
the hinge area itself.
Wing transport locks securely hold the wings in the folded position in case of hydraulic
failure.
Dual leveling rods enable the
rough terrain.
5-Bolt hubs makes the wheel assembly more durable and longer lasting.
Choice of laminated tires for eliminating flats, used aircraft tires for cushioning during
field and road use or bare rims for suppling your own automotive tires.
Protects unit from bumps and ground shock.
Wheel spindles can be replaced when damaged without replacing the entire axle
assembly.

Benefits

have been designed and tested and meet rigorous
cutter
cutter
to pull equally on the rear axle during travel over
318-301F continue on next page
from front to rear, and in
74
