Infinity ENTRA SUB TWO Service Manual page 23

Entra Sub Two
Part Number
026-500495-252 VR 5KA
Capacitors
031-100244-100 Ceramic
031-100343-100 SMD Capacitor
031-100344-100 SMD Capacitor
031-100384-100R SMD Capacitor
031-220344-100 SMD Capacitor
031-330444-300 SMD Capacitor
031-470244-102 SMD Capacitor
031-560243-100 SMD Capacitor
031-560343-102 SMD Capacitor
032-100484-200 END PP Capacitor
032-270343-301 MP Capacitor
033-200645-300 NP Capacitor
033-470464-270 NPE Capacitor
033-680464-270 NPE Capacitor
034-100525-300 Electrolytic Capacitor
034-100625-300 Electrolytic Capacitor
034-220525-301 Electrolytic Capacitor
034-220615-301 Electrolytic Capacitor
034-330515-000 Electrolytic Capacitor
034-330525-300 Electrolytic Capacitor
034-330615-300 Electrolytic Capacitor
034-330780-300 Electrolytic Capacitor
034-470415-301 Electrolytic Capacitor
034-470615-301 Electrolytic Capacitor
035-180354-300 PE Capacitor
035-330293-300 ESK Capacitor
035-470244-100 PE Capacitor
035-470353-301 ESKCapacitor
035-680253-300 PE Capacitor
038-100363-300 MPE Capacitor
038-330393-300 MPE Capacitor
039-100390-100 UL Safety Capacitor
Semiconductors
051-000600-100 NPN Transistor
051-003100-000 Transistor
051-005600-100 NPN Transistor
051-222200-100 NPN Transistor
051-290700-100 PNP Transistor
051-540101-000 PNP Transistor
051-555100-000 NPN Transistor
051-640001-000 MOSFET N-Channel
052-400080-000 Rectifier
053-211100-000 IC;DIP,DRIVER
054-000100-100 SMD DIODE
054-001002-100 SMD ZENER DIODE
054-001501-100 SMD ZENER DIODE
054-007200-100 SMD IC
054-007400-100 SMD IC;(OP-Amp)
054-033904-100 SMD Transistor
054-033906-100 SMD Transistor
054-045580-100 SMD IC;(OP-Amp)
054-050601-100 SMD ZENER DIODE
054-211400-100 SMD Transistor (NPN)
054-414803-100 SMD DIODE
054-540100-100 SMD Transistor (PNP)
Description
PN:RK163111R52B-5KA (EJ)
0u01/50V K 0805 X7R TAPING
100pF/50V J 0805 NPO TAPING
0u1/50V K 0805 X7R TAPING
0u1/250V K 1206 X7R TAPING
220pF/50V J 0805 NPO TAPING
3300pF/50V K 0805 X7R TAPING
0u047/50V K 0805 X7R TAPING
56pF/50V J 0805 NPO TAPING
560pF/50V J 0805 NPO TAPING
1uF/250V K P:15mm
0u27/63V J P:5 TAPING
200u/50V M (R)1321 P:5
4u7/100V K10 (R)1015 GNE
6u8/100V K10 (R)1020 GNE
10uF/25V M (R)0511 P:5 TAPING
100uF/25V M (R)6.3x11 P:5
22uF/25V M (R)5x11 P:5 TAPING
220uF/16V M (R)0611 P:5
33uF/16V M (R)0511 P:5 TAPING
33uF/25V M (R)0511 P:5
330uF/16V M (R)0812 P:5
3300uF/80V M (R) 22*48 SNAPIN
4u7/50V M (R)0511 P:5 TAPING
470uF/16V M (R)0812 P:5 TAPING
0u18/63V J P=5 P/N:ESK063P18JA
0u033/63V J P:5 TAPING
0u047/63V K P:5m/m TAPING
0u47/63V J P:5m/m TAPING
0u068/63V J P:5m/m TAPING
0u1/100V J TAPING
0u33/63V J TAPING
0u1/275V PN:XG275M104VSL7
MPSW06RLRA TO-92 TAPING
TIP 31C TO-220
MPSW56RLRA MPQ TO-92 TAPING
PN:MPS2222ARLRA TO-92 TAPING
PN:P2N2907A TO-92 TAPING
PN:2N5401 TO-92 TAPING
PN:2N5551 TO-92 TAPING
PN:IRF640N TO-220 (IR)
400V,8A,PN:RS804
PN:IR2111 8PIN (IR)
PN:ES1D 200V 1A TAPING
PN:BZX84C10 10V SOT-23 TAPING
PN:BZX84C15 15V SOT-23 TAPING
PN:TL072CDR SO-8 TAPING (TI)
PN:TL074CDR TAPING (TI)
PN:MMBT3904LT1 SOT23 TAPING
PN:MMBT3906LT1 SOT23 TAPING
PN:NJM4558M-TE3 DMP-8 TAPING
PN:BZX84C5V6 5.6V SOT-23 TAPIN
PN:DTC114EK SMT3 TAPING (ROHM 1
PN:LL4148 TAPING (Wishay)
PN:MMBT5401 LT1 SOT-23 TAPING 3
22
Q'ty Reference Designator
1 VR1
7 C33,45,51,66,67,5,10
3 C16,36,58
12 C11,42-44,46-49,52,54,55,60
2 C3,7
5 C14,15,20,21,19
2 C40,34
2 C62,59
2 C57,61
1 C56
2 C70,C70B
1 C29
2 C17,18
1 C73
1 C72
1 C35
1 C64
5 C4,9,41,50,53
1 C37
1 C39
1 C1
2 C12,78
2 C6,8
1 C2
1 C65
1 C1A
1 C28
1 C30
2 C25,26
2 C2A,C27
2 C68,69
1 C31
1 CXAC1
2 Q2,Q16
1 Q4
1 Q3
1 Q21
2 Q19,23
1 Q1
1 Q17
2 Q18,22
1 BR1
1 U7
5 D5,26,29,33,38
1 D35
3 D6,7,9
3 U5,6,1
2 U2,3
7 Q11,14,13,5,8,25,9
4 Q6,10,12,15
1 U4
3 D24,36,37
Q7
12 D1-4,8,27,28,30-32,34,39,
Q20,24,26
