Harman EASY Touch Control Owner's Manual page 10

Diagnostic information on page 2 of 6 displays temperature sensors
point for the stove to achieve if the wireless sensor loses signal. You will see
"Using Back Up Sensor" on your home screen.
Wireless Sensor: Displays whether or not the optional wireless sensor is
disabled or enabled.
Outside Air Temperature: Displays outside temperature when the optional
Outside Air Kit is installed.
Diagnostic information on Page 3 of 6 displays Limits and Fuel Usage.
Fuel Used in 24 Hours: Displays the amount of pounds burned in the past
24 hours.
Fuel Used Since Cleaning: Displays how many pounds of fuel was used
since last total clean.
Fuel Remaining: Displays amount of fuel in hopper. To enhance accuracy,
fuel calibration should be completed, see Menu 2.
10
Diagnostics - Pages 2 & 3
Harman EASY Touch Control Owners Manual
ESP Temperature: Displays the
current temperature of the Exhaust
Sensing Probe
Room Temperature: Displays
room temperature sensed from
the on-board or Wireless Remote
Sensor(optional).
Return Air Temperature:
Displays the room air temperature
returning to the unit. This
temperature becomes the set
Ignition Charge Time (min):
This can only be altered by an
Authorized Harman Dealer.
Displays amount of time the auger
feeds fuel during the ignition cycle.
Feed Rate Limit (%): Displays the
maximum allowed percentage as set
in the "Feed Limit" screen.
ESP Temperature Limit: Displays
the maximum temperature of the
ESP allowed by the control, based
on current settings.
