- Page 1 OPERATION AND MAINTENANCE MANUAL LVMP spray gun Art. A901A TRANSLATION OF THE ORIGINAL INSTRUCTIONS...
-
Page 2: Operator Qualifications
Manual on the date of issue, listed on this page; however, the product may be subject to potentially major technical changes in the future, without the Manual being updated. Therefore, contact FERVI for information about modifications that may have been implemented. REV. 2... -
Page 3: General Safety Instructions
HARDWARE 1 GENERAL SAFETY INSTR GENERAL SAFETY INSTRUCTIONS 1.1 Commissioning Before using this spray gun, some simple assembly is required. Before using this spray gun, some simple assembly is required. To properly assemble the spray gun, proceed as follows: To properly assemble the spray gun, proceed as follows: 1. -
Page 4: Risk Of Fire Or Explosion
HARDWARE To begin painting, simply aim the spray gun at the element to be painted, keeping it at a distance of 150 – 200 mm from the surface and press the trigger. While painting, move the spray gun from side to side to distribute the paint as evenly as possible. Do not point the spray at people or animals. -
Page 5: Description And Intended Use
HARDWARE 2 DESCRIPTION AND INTENDED USE The spray gun Art. A901A is a tool that uses compressed air to spray various types of paints. It is used for precision work, producing very thin lines, creating smooth surfaces with uniform colour, and blended tones. - Page 6 HARDWARE 3 IDENTIFICATION The following identification plate is located on the spray gun, Art. A901A: Figure 6 – Nameplate PLATE IN ITALIAN PLATE IN ENGLISH Art. A901A Art. A901A Aerografo LVMP LVMP spray gun Pressione di esercizio 2-3 bar Operating pressure: 2-3 bar Capacità...
-
Page 7: Improper Uses And Precautions
Contact the Dealer's Customer Service Centre where you purchased the items to order spare parts. 5.1 Disposal The spray gun Art. A901A is made of aluminium and the paint tank is made of plastic. Divide the materials for recycling. Respect the Environment! - Page 8 HARDWARE 6 EXPLODED VIEW AND SP EXPLODED VIEW AND SPARE PARTS Page 8 of 9...
- Page 9 HARDWARE Ref. Description Ref. Description A901A/01 Gun body A901A/25 Knob A901A/02 Nozzle locking spring A901A/26 Screw M4 x 8 A901A/03 Spring seal A901A/27 Nail A901A/04 Rubber sleeve A901A/28 Sealing ring A901A/05 Sealing screw A901A/29 Valve body A901A/06 Air flow ring...
