Echo HCR-1500 Service Data

Hedge trimmer
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

12-21A-00
SERVICE DATA

HEDGE TRIMMER

INTRODUCTION
We are constantly working on technical
improvement of our products. For this reason,
technical data, equipment and design are subject to
change without notice. All specifications,
illustrations and directions in this SERVICE DATA
are based on the latest products information
available at the time of publication.
For further information to service this model, please
refer to ECHO SERVICE MANUAL Ord. No. 402-
19.
INDEX
HCR-1500
HCR-1500
CONTENTS
1 SERVICE INFORMATION ............................ 2
1-1 Specifications ............................................ 2
1-2 Technical data .......................................... 3
1-3 Torque limits ............................................... 4
1-4 Special repairing materials ....................... 4
1-5 Service limits ............................................. 5
1-6 Special tools ............................................. 6
2 SERVICE HINT ............................................. 7
2-2 Rotating rear handle function .................... 8
Reference No.
I S S U E D :
1
1
page
12-21A-00
1 9 9 8 0 7

Advertisement

Table of Contents
loading

Related Manuals for Echo HCR-1500

Summary of Contents for Echo HCR-1500

  • Page 1: Table Of Contents

    For further information to service this model, please 2 SERVICE HINT ..........7 refer to ECHO SERVICE MANUAL Ord. No. 402- 2-1 Rotating rear handle construction ..... 7 2-2 Rotating rear handle function ....8 12-21A-00 Reference No.

  • Page 2: Service Information

    SERVICE INFORMATION HCR-1500 1 SERVICE INFORMATION 1-1 Specifications Dimensions Length mm(in) 1022 (40.2) Width mm(in) 237 ( 9.3) Height mm(in) 197 ( 7.8) Dry weight kg(lb) 5.0 (11.0) Engine Type KIORITZ, air-cooled, two-stroke, single cylinder Rotation Counterclockwise as viewed from the output end Displacement 21.2 (1.294)

  • Page 3: Technical Data

    SERVICE INFORMATION HCR-1500 1-2 Technical data Engine Idling speed 3000 - 3400 Maximum speed 10000 - 10500 Clutch-in speed 3500 - 4100 Compression pressure, standard kgf/cm (psi) 8.5 (121) Carburetor ZAMA C1U-K51 Type Diaphragm horizontal-draught Venturi Size mm(in) 8.5 (0.335)

  • Page 4: Torque Limits

    SERVICE INFORMATION HCR-1500 1-3 Torque limits Descriptions Size kgf•cm in•lbf Starter Pawl carrier 160 - 200 140 - 175 system Starter case M 4 * 14 - 28 12 - 24 Ignition Ignition coil (CDI module) 35 - 50 30 - 45...

  • Page 5: Service Limits

    SERVICE INFORMATION HCR-1500 1-5 Service limits 5K193 5K228 5K229 5K230 5K231 5K016 5K042 5K194 5K171 Description mm (in) Cylinder bore When plating is worn and aluminum can be seen Piston outer diameter Min. 32.10 (1.264) Piston pin bore Max. 8.030 (0.3161) Piston ring groove Max.

  • Page 6: Special Tools

    SERVICE INFORMATION HCR-1500 1-6 Special tools 3 : a = 4 mm 4 : a = 3 mm Key Part Number Description Used for: Tachometer Measuring engine speed 433019-12330 Flange nut Removing magneto rotor (flywheel) 895610-79920 L-hex wrench (4 mm) Removing and installing hex. socket bolts (M5) 895612-79920 L-hex wrench (3 mm) Removing and installing hex.

  • Page 7: Service Hint

    SERVICE HINT HCR-1500 2 SERVICE HINT 2-1 Rotating rear handle construction Cut view A Rear handle Throttle trigger Latch Handle fixture Handle stopper Rear handle Throttle lockout Stopper spring Latch Handle stopper Handle fixture Throttle trigger Throttle spring Throttle cable...

  • Page 8: Rotating Rear Handle Function

    SERVICE HINT HCR-1500 2-2 Rotating rear handle function 2. When the Rear handle is rotated 45 or 90 degrees clockwise or counterclockwise, the Knock button (G) engages with the dent (H) of Rear handle and makes click noise. Throttle trigger (K) is pulled in this position, Throttle stopper (C) is pushed to the front by part (L) of Throttle trigger.
