Merlin Compliances And Certifications; Declaration Of Conformity - Tieline Merlin User Manual

Tech Note: You can test your internet connection speed by connecting a PC to the
internet and using
then something is wrong. Get it fixed before going live!
7. Use a dedicated DSL/ADSL line for your codecs. Do not share a link with PCs or company
networks. The only exception to this rule is if an organisation has network equipment and
engineers that can implement and manage quality of service (QoS) on its network.
8. Use UDP as the preferred audio transport protocol. TCP generally results in lower bit rates
and random drop-outs of audio over the internet. Only use TCP if UDP is blocked by firewalls
and you are unable to connect.
9. When using UDP ensure the total bit rate (audio bit rate plus header bit rate) is no more than
80% of the ISP connection rate. IP headers require around 20 kbps in addition to the audio
bit rate. For example, with a 64 kbps connection the audio bit rate should be (64-20) x 0.8 =
31.2 kbps or lower. For TCP we suggest a limit of 50% or less.
10. Wireless IP connections can easily become congested and result in packet loss and audio
drop-outs. It is very difficult to guarantee connection quality when there is no way of knowing
how many people are sharing the same wireless connection.
Important Note: Be careful when using cell-phone connections at special events where
thousands of people have mobile phones. This can result in poor quality connections
and audio drop-outs if cell-phone base stations are overloaded.
IP Connection Checklist
Complete the following check list and aim for a score of at least 8 out of 10 before going live.
Number
1
2
3
4
5
6
7
8
9
10
16.3

Merlin Compliances and Certifications

Declaration of Conformity

This Merlin codec meets the requirements of directives for CE and C-Tick certifications. Technical
documentation required by the conformity assessment procedure is kept at the head office of Tieline
Technology; 1/25 Irvine Drive, Malaga, Western Australia 6090.
© Tieline Pty. Ltd. 2012
http://www.speedtest.net/index.php
Check
Using a reputable Tier1 ISP that's part of internet backbone.
The same ISP is being used for both codec connections.
The ISP Plan is a Business Plan or equivalent.
The ISP connection speed is adequate.
Equipment is high quality and suitable for media streaming.
The ISP connection speed has been tested and is suitable.
The ISP connection is not shared with other PCs or devices.
UDP is being used as the audio transport protocol.
No more than 80% of ISP connection bandwidth is being used.
There are no wireless connections being used.
Reference
. If the bandwidth detected is low
Result
91
