Using the Optional Audio Module (AM2)

Audio is connected to the AM2 using the Audio Break Out cable provided with the AM2:
1
Balanced (XLR) Input Left
2
Balanced (XLR) Input Right
3
Unbalanced Input Left
4
Unbalanced Input Right
5
Audio Out Left
6
Audio Out Right
