Icom IC-M400BB Service Manual page 12

July 2013
[VCO UNIT]
REF PARTS
DESCRIPTION
NO. NO.
Q2 1590004070 S.TRA LDTC144EET1G <SLVJ>
Q3 1530002921 S.TRA 2SC4226-T1 Y25 (R25)
Q4 1530002921 S.TRA 2SC4226-T1 Y25 (R25)
Q5 1530003950 S.TRA KTC4080 Y-RTK/P
Q6 1530003950 S.TRA KTC4080 Y-RTK/P
Q7 1530003950 S.TRA KTC4080 Y-RTK/P
Q8 1590004050 S.TRA LDTA144EET1G <SLVJ>
D1 1750001790 S.DIO 1SS390
D2 1750001790 S.DIO 1SS390
D3 1750001780 S.VAR HVB350BYPTL-E
L1 6200003711 S.COI NLV25T-2R7J
L2 6200011410 S.COI C2520C-82NG-A
L3 6200013750 S.COI MLK1005SR10JT
L4 6200013750 S.COI MLK1005SR10JT
L5 6200013750 S.COI MLK1005SR10JT
R6 7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
R7 7030005120 S.RES ERJ2GEJ 102 X (1K)
R8 7030005240 S.RES ERJ2GEJ 473 X (47K)
R9 7030005120 S.RES ERJ2GEJ 102 X (1K)
R11 7030005000 S.RES ERJ2GEJ 471 X (470)
R12 7030005090 S.RES ERJ2GEJ 104 X (100K)
R13 7030007340 S.RES ERJ2GEJ 153 X (15K)
R14 7030005090 S.RES ERJ2GEJ 104 X (100K)
R15 7030005090 S.RES ERJ2GEJ 104 X (100K)
R16 7030005050 S.RES ERJ2GEJ 103 X (10K)
R21 7030005050 S.RES ERJ2GEJ 103 X (10K)
R22 7030005050 S.RES ERJ2GEJ 103 X (10K)
R23 7030009160 S.RES ERJ2GEJ 181 X (180)
R25 7030008370 S.RES ERJ2GEJ 561 X (560)
R26 7030005010 S.RES ERJ2GEJ 681 X (680)
R27 7030005070 S.RES ERJ2GEJ 683 X (68K)
R31 7030005000 S.RES ERJ2GEJ 471 X (470)
R32 7030005070 S.RES ERJ2GEJ 683 X (68K)
R33 7030007270 S.RES ERJ2GEJ 151 X (150)
R34 7030009200 S.RES ERJ2GEJ 390 X (39)
R41 7030005000 S.RES ERJ2GEJ 471 X (470)
R42 7030007350 S.RES ERJ2GEJ 393 X (39K)
R43 7030003860 S.RES ERJ3GE JPW V
C4 4030017460 S.CER C1005 JB 1H 102K-T
C6 4030016790 S.CER C1005 JB 1E 103K-T
C8 4030017460 S.CER C1005 JB 1H 102K-T
C9 4030017460 S.CER C1005 JB 1H 102K-T
C11 4030017460 S.CER C1005 JB 1H 102K-T
C12 4030017460 S.CER C1005 JB 1H 102K-T
C13 4030018860 S.CER C1005 JB 0J 105K-T
C14 4030017460 S.CER C1005 JB 1H 102K-T
C15 4030017460 S.CER C1005 JB 1H 102K-T
C16 4030011810 S.CER C1608 JB 1A 224K-T
C21 4030018010 S.CER C1005 CH 1H 360J-T
C22 4030017670 S.CER C1005 CH 1H 390J-T
C24 4030017760 S.CER C1005 JB 1H 222K-T
C31 4030017350 S.CER C1005 CH 1H 020B-T
C32 4030017550 S.CER C1005 CH 1H 1R5B-T
C33 4030017440 S.CER C1005 CH 1H 221J-T
C34 4030017460 S.CER C1005 JB 1H 102K-T
C35 4030006860 S.CER C1608 JB 1H 102K-T
C36 4030017340 S.CER C1005 CH 1H 010B-T
C37 4030017460 S.CER C1005 JB 1H 102K-T
C41 4030017380 S.CER C1005 CH 1H 050B-T
C42 4030017460 S.CER C1005 JB 1H 102K-T
C43 4030017400 S.CER C1005 CH 1H 220J-T
C46 4030017630 S.CER C1005 CH 1H 120J-T
C47 4030017460 S.CER C1005 JB 1H 102K-T
C48 4030017460 S.CER C1005 JB 1H 102K-T
C49 4030017650 S.CER C1005 CH 1H 270J-T
J1 6910003831 CON IMSA-9230B-1-04Z003-PT1
J2 6910003831 CON IMSA-9230B-1-04Z003-PT1
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
(Additional page)
H/V
M.
LOCATION
T 13.4/9.3
T 11.9/2.8
T 18.6/2.3
T 7.1/6.9
T 4.9/2.6
T 5.4/11.3
T 11.4/12.5
T 11.5/10.0
T 13.3/7.7
T 14.4/5.6
T 18.2/9.2
T 17.9/5.9
T 5.7/8.3
T 3.5/4.0
T 4.0/12.7
T 7.5/10.8
T 16.4/11.0
T 16.2/9.8
T 16.2/8.9
T 10.0/12.0
T 18.5/13.7
T 15.5/13.3
T 18.5/12.8
T 13.4/12.8
T 9.4/13.2
T 9.9/1.4
T 20.7/1.7
T 15.6/2.2
T 9.9/3.2
T 6.9/9.6
T 7.6/5.1
T 4.3/5.6
T 6.8/1.7
T 2.9/5.3
T 1.8/4.4
T 3.5/9.5
T 5.1/9.5
T 16.1/3.7
T 18.3/11.3
T 3.5/7.5
T 15.2/10.8
T 15.0/9.5
T 12.8/10.8
T 14.0/11.3
T 13.4/13.7
T 14.6/13.3
T 17.3/13.3
T 10.3/9.9
T 16.2/8.0
T 15.0/7.6
T 11.6/7.0
T 12.2/4.7
T 20.4/3.3
T 15.6/1.3
T 9.9/4.1
T 14.1/2.7
T 9.9/2.3
T 7.0/8.7
T 6.8/3.3
T 4.8/4.4
T 2.5/3.1
T 4.8/8.3
T 3.5/8.4
T 5.4/13.1
T 3.3/11.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
11
S.=Surface mount
