Icom IC-M400BB Service Manual page 11

July 2013
[LOGIC UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C5 4030016930 S.CER C1005 JB 1A 104K-T
C6 4030016930 S.CER C1005 JB 1A 104K-T
C7 4030016930 S.CER C1005 JB 1A 104K-T
C8 4030016930 S.CER C1005 JB 1A 104K-T
C9 4030016930 S.CER C1005 JB 1A 104K-T
C10 4030016930 S.CER C1005 JB 1A 104K-T
C11 4030016930 S.CER C1005 JB 1A 104K-T
C12 4030016930 S.CER C1005 JB 1A 104K-T
C13 4030017460 S.CER C1005 JB 1H 102K-T
C14 4030017460 S.CER C1005 JB 1H 102K-T
C15 4030017460 S.CER C1005 JB 1H 102K-T
C16 4030017460 S.CER C1005 JB 1H 102K-T
C17 4030016790 S.CER C1005 JB 1E 103K-T
C18 4030016790 S.CER C1005 JB 1E 103K-T
C19 4030016790 S.CER C1005 JB 1E 103K-T
C20 4030016790 S.CER C1005 JB 1E 103K-T
C24 4030017460 S.CER C1005 JB 1H 102K-T
C25 4030016930 S.CER C1005 JB 1A 104K-T
C26 4030020300 S.CER GRM21BB31C475KA87L
C27 4030016790 S.CER C1005 JB 1E 103K-T
C31 4030016950 S.CER C1005 JB 1A 473K-T
C32 4030016950 S.CER C1005 JB 1A 473K-T
C33 4030016950 S.CER C1005 JB 1A 473K-T
C35 4030016950 S.CER C1005 JB 1A 473K-T
C36 4030016950 S.CER C1005 JB 1A 473K-T
C37 4030016950 S.CER C1005 JB 1A 473K-T
C38 4030016950 S.CER C1005 JB 1A 473K-T
C43 4030017410 S.CER C1005 CH 1H 240J-T
C44 4030017410 S.CER C1005 CH 1H 240J-T
C57 4030016930 S.CER C1005 JB 1A 104K-T
C61 4030016790 S.CER C1005 JB 1E 103K-T
C62 4030017760 S.CER C1005 JB 1H 222K-T
C63 4030019990 S.CER C1005 JB 1C 104K-T
C64 4030016790 S.CER C1005 JB 1E 103K-T
C65 4030018890 S.CER C1005 JB 0J 224K-T
C66 4030017760 S.CER C1005 JB 1H 222K-T
C67 4030016930 S.CER C1005 JB 1A 104K-T
C68 4030016790 S.CER C1005 JB 1E 103K-T
C69 4340000310 S.MYL ECHU 1C 333JX5
C71 4030017920 S.CER C1005 JB 1A 683K-T
C72 4030017480 S.CER C1608 JB 1A 474K-T
C74 4030017460 S.CER C1005 JB 1H 102K-T
C81 4030016930 S.CER C1005 JB 1A 104K-T
C82 4030017460 S.CER C1005 JB 1H 102K-T
C83 4030019990 S.CER C1005 JB 1C 104K-T
C84 4030017460 S.CER C1005 JB 1H 102K-T
C85 4030020300 S.CER GRM21BB31C475KA87L
C86 4030017460 S.CER C1005 JB 1H 102K-T
C87 4030016790 S.CER C1005 JB 1E 103K-T
C88 4030020240 S.CER GRM31CR11C475KA01L
C89 4030017460 S.CER C1005 JB 1H 102K-T
C91 4030016930 S.CER C1005 JB 1A 104K-T
C92 4030017460 S.CER C1005 JB 1H 102K-T
C95 4030016790 S.CER C1005 JB 1E 103K-T
C96 4030016930 S.CER C1005 JB 1A 104K-T
C101 4030017460 S.CER C1005 JB 1H 102K-T
C102 4030016930 S.CER C1005 JB 1A 104K-T
C103 4030016790 S.CER C1005 JB 1E 103K-T
C104 4030017920 S.CER C1005 JB 1A 683K-T
C105 4030017460 S.CER C1005 JB 1H 102K-T
C106 4030017460 S.CER C1005 JB 1H 102K-T
C107 4030016930 S.CER C1005 JB 1A 104K-T
C108 4030017460 S.CER C1005 JB 1H 102K-T
C111 4030016790 S.CER C1005 JB 1E 103K-T
C112 4030020310 S.CER GRM31CB31C106KA88L
C113 4030016790 S.CER C1005 JB 1E 103K-T
C114 4030017460 S.CER C1005 JB 1H 102K-T
C115 4030017460 S.CER C1005 JB 1H 102K-T
C116 4030017460 S.CER C1005 JB 1H 102K-T
C155 4030016790 S.CER C1005 JB 1E 103K-T
C162 4030016930 S.CER C1005 JB 1A 104K-T
C165 4030017460 S.CER C1005 JB 1H 102K-T
C166 4030017460 S.CER C1005 JB 1H 102K-T
J1 6510022472 S.CON 40FLT-SM2-TB(LF)(SN)(M)
J4 6510018971 S.CON B4B-PH-SM4-TB(LF)(SN)
EP11 6910016330 S.BEA MMZ1005S 601CT-S
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
(Additional page)
[CONNECT UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
B 92.3/31.0 C1 4030016790 S.CER C1005 JB 1E 103K-T
B 80.5/15.0
B 75.5/16.7
B 65.7/26.5 J1 6510022440 CON
B 65.3/32.0 J2 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M)
B 76.0/43.3
B 81.0/43.3
B 92.3/36.0 EP2 6910019100 S.BEA
B 70.5/15.7
B 64.8/38.5
B 87.7/44.3
B 88.7/15.7
B 93.3/31.0
B 80.5/14.0
B 64.7/26.5
B 76.0/44.3
B 67.0/45.2
B 63.8/45.2
B 92.8/20.9
B 94.2/20.4
B 85.5/15.3
B 84.5/16.3
B 85.1/13.9
B 92.8/23.2
B 92.8/24.2
B 92.8/25.2
B 92.8/26.2
B 94.3/28.5
B 94.3/26.7
B 87.3/48.5
B 106.8/27.1
B 39.3/41.3
B 40.3/41.3
B 37.0/40.4
B 35.3/40.8
B 30.5/50.8
B 29.1/50.4
B 32.8/51.8
B 38.2/50.7
B 43.0/13.3
B 41.4/11.2
B 44.0/9.1
B 37.6/33.6
B 39.2/30.0
B 34.0/33.1
B 33.6/34.1
B 38.8/8.8
B 40.3/8.9
B 38.4/11.6
B 36.8/10.5
B 41.5/33.8
B 56.4/13.8
B 57.1/20.0
B 49.5/40.8
B 55.5/34.8
B 120.2/36.9
B 121.2/36.9
B 122.2/36.9
B 131.4/32.0
B 131.4/30.0
B 128.2/30.6
B 136.9/34.6
B 134.5/27.9
B 45.8/26.5
B 44.6/29.6
B 26.3/19.4
B 27.3/19.4
B 24.1/26.2
B 23.2/22.1
B 27.7/26.9
B 7.2/16.3
B 16.2/15.3
B 16.2/16.3
B 35.0/23.0
B 127.0/22.5
B 129.6/31.0
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
