NORDICTRACK
®
T6.3 Treadmill •• Model No. 831.24996 •• Revised 09/19/13
For detailed instructions, see the User’'s Manual. Note: The underside of the walking belt is coated with an oily
substance. If there is an oily substance on top of the walking belt, simply wipe it off with a soft cloth and a mild,
non-abrasive cleaner.
5/16" Star
3/8" Star
#8 x 1/2" Silver
#8 x 3/4" Screw
Screw (10)––1
Washer (11)––2
Washer (13)––10
(2)––12
1/4" x 1"
5/16" x 1"
Screw (4)––4
Screw (5)––2
3/8" x 3 1/2" Screw (28)––4
3/8" x 4" Screw (7)––6
1/4" x 4 1/2" Screw (6)––2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T6.3 831.24996 and is the answer not in the manual?

Questions and answers

Summary of Contents for NordicTrack T6.3 831.24996

  • Page 1 UICK SSEMBLY UIDE NORDICTRACK ® T6.3 Treadmill •• Model No. 831.24996 •• Revised 09/19/13 For detailed instructions, see the User’’s Manual. Note: The underside of the walking belt is coated with an oily substance. If there is an oily substance on top of the walking belt, simply wipe it off with a soft cloth and a mild, non-abrasive cleaner.
  • Page 2 1. Press a Base Cap (74) into each side of the 3. Attach the Right Upright (90) and the Left Base (94). Tie the wire tie around the Upright Upright (not shown). Wire (81). Pull the Upright Wire through the Right Upright (90).
  • Page 3 5. Route the Upright Wire (81) through the Right 7. Connect the Upright Wire (81). Remove the wire Handrail (85). Attach the Handrails (only one tie. side is shown). Wire Console Wire Wire 6. Insert the Console Frame (18) into the Handrails 8.
  • Page 4 11. Attach the Latch Housing (62). Knob 10. Attach the Trays (27, 36). 12. Slide the Base Covers (82, 83) into place. NordicTrack is a registered trademark of ICON IP, Inc. Part No. 354787 R0913A Printed in USA © 2013 ICON IP, Inc.
