OPERATORS' GUIDE
REL-CS16
HYDRAULIC
CHAINSAW
For cutting and trimming of limbs
and branches from the ground or
an aerial bucket.
RELIABLE EQUIPMENT & SERVICE CO., INC.
92 Steamwhistle Drive • Ivyland, PA 18974 • USA
Phone: 215-357-3500 • Fax: 215-357-9193
MODEL: REL-CS16
MAX. PRESSURE: 2,000 PSI
SERIAL NO.: ____________
YEAR: ___________
to read and understand these warnings
and safe handling instructions could result
in severe personal injury and or death.
DISTRIBUTED BY
1
CS Manual 10-08
WARNING
All information found in this guide
must be read and understood before
use or testing of this tool. Failure
Advertisement
Table of Contents
Related Manuals for Reliable Equipment REL-CS16
Summary of Contents for Reliable Equipment REL-CS16
- Page 1 For cutting and trimming of limbs and branches from the ground or an aerial bucket. WARNING RELIABLE EQUIPMENT & SERVICE CO., INC. 92 Steamwhistle Drive • Ivyland, PA 18974 • USA All information found in this guide Phone: 215-357-3500 • Fax: 215-357-9193...
-
Page 2: Table Of Contents
Troubleshooting ......14 DESCRIPTION The REL-CS16 hydraulic chainsaw is intended for safe pruning, trimming and felling of trees from the ground or aerial bucket. The powerful hydraulic drive motor provides continuous cutting from any Open-Center or Closed-Center hydraulic system with an operating pressure between 1,000 to 2,000 psi at 4-8 gpm. -
Page 3: Safety Instructions
BEFORE USING THIS CHAINSAW, READ THE WARNINGS and the recommended practices described in this manual. Failure by the operator to read and fully understand these warnings will leave this person unqualified to use and operate this tool. Property damage, severe personal injury, WARNING and/or death could result by not following these warnings. - Page 4 Safety DO NOT attempt to make any changes to any of the component parts or accessories when connected to the power source. WARNING DO NOT adjust, inspect, or clean tool while the tool is connected to the power source. The tool could accidentally start up and cause serious injury.
-
Page 5: General Safety
Burn Hazard Saw body, blade, bar as well as other components will be hot during and after use. Use care when handling this tool. Hot surfaces may cause serious burns. Failure to observe this WARNING warning may result in serious personal injury. Electrical Shock Hazard Use only certified nonconductive hoses and fittings. - Page 6 Burn Hazard Do Not connect or disconnect tool, hoses or fittings while power source is running or while hydraulic fluid is hot. Hot hydraulic fluid may cause serious burns. WARNING Failure to observe this warning could result in serious injury. Safe Operation &...
- Page 7 TOOL SPECIFICATIONS Overall Length ..............32 in. (81.28 cm) Width ................... 10 in. (19.05 cm) Weight ................9.75 lbs. (4.22 kg) Pitch ................375 in. (8.26 mm) Chain Gauge ..............050 in. (1.47 mm) Chain Bar Length ............16 in. (40.64 cm) Flow Range ...............
-
Page 8: Connections And Hoses
HOSES AND FITTINGS There exists the potential for shock in using anything other than certified nonconductive hoses and hydraulic oil with dielectric properties, when using system components near WARNING energized electrical lines. Failure to recognize these conditions could cause electrocution. Hoses and fittings used with this tool must comply with S.A.E. -
Page 9: Pre-Operation
PRE-OPERATION OF SAW WARNING! DO NOT connect hoses or fittings to this chainsaw before completing all the following instructions. Before attempting to run or use the saw, check all connections, including hoses, couplings, chain tension, cleanliness, and ensure that safety trigger is moving freely. Wear all safety items required and make sure that the working area is clear of obstructions and non essential personnel. -
Page 10: Operation Of Saw
OPERATION Hold the chainsaw control handle in one hand and the forward handle in the other hand. After positioning the saw in the cutting area, engage the trigger actuator, allowing the trigger to be depressed. Depress the trigger slowly and allow the chain to start rotating. When at full speed, feed the saw into the material. -
Page 11: Maintenance
MAINTENANCE The service schedule should be followed as closely as possible. The life, reliability, and safety of the tool is dependent on maintenance and will help the tool to remain productive for a much longer period. DAILY MAINTENANCE CLEAN: All surfaces including handle, trigger, trigger actuator, fittings, hoses, motor and housing. -
Page 12: Chain Oiler
SERVICE Automatic Chain Oiler: The automatic chain oiler is designed to continuously lubricate the chain and the guide bar while the chainsaw is running. This lubrication is an important factor in minimizing wear and tear on components as is commonly found in chainsaws. By utilizing the fluid from the supply circuit and sending the fluid through a metering valve, the fluid is then directed to the chain and guide in the quantity required. -
Page 13: Chain Tension
Saw Chain Tension: Tension checking and adjusting must be done frequently before start and during cutting operations. The chain must be set to the proper tension in order for the saw to function properly. If the chain is too loose, the chain can jump the track of the guide bar, probably causing damage to the bar and associated components. -
Page 14: Troubleshooting
TROUBLE SHOOTING Determine the source (i.e. tool or hydraulic system) of the problem before trouble shooting. Will not run Improper power source ............ Verify power source meets specifications Low hydraulic fluid ............Check fluid level Incorrect viscosity ............Use recommended fluid Tool damaged .............. -
Page 15: Major Components
FIGURE 4 RELIABLE EQUIPMENT MAJOR COMPONENTS PARTS LIST DESCRIPTION 16” Bar (standard) Chain .058 in. gauge / .325 in. Pitch Spike Rack Safety Shroud Automatic Oiler Adjustment Front Handle Hydraulic Motor & Serial Number Hydraulic Circuit Selector Open-Center/Closed-Center Control Handle Safety Trigger Actuator Trigger Lower Hand Guard... -
Page 16: Saw Body, Chain Side
FIGURE 5 ASSEMBLE AS SHOWN SAW BODY (CHAIN SIDE) Item Qty. Part No. Description R29040 SCREW, BUTTON HEAD ¼-20 X 1.5 LG R29041 NUT ¼-20 NYLON LOCKING R29038 FRONT HANDLE R29061 SCREW, ¼-20 X .75 BHSC R29037 SHROUD R29025 MOUNTING PLATE R29043 SCREW, ¼-20 X .625 BHSC R13419... -
Page 17: Saw Body, Motor Side
FIGURE 6 SAW BODY (MOTOR SIDE) Item Qty. Part No. Description R29040 SCREW, BUTTON HEAD ¼-20 X 1.5 LG R29041 NUT ¼-20 NYLON LOCKING R29033 OILER PLUG R13413 O RING R29061 SCREW, ¼-20 X .75 BHSC R29024 SPIKE RACK R29063 SCREW, ¼-20 X .625 BHSC R29201 16”... -
Page 18: Sprocket Cover
FIGURE 7 SPROCKET COVER ASSEMBLY Item Qty. Part No. Description R29041 NUT ¼-20 NYLON LOCKING R29061 SCREW, ¼-20 X .75 BHSC R29065 STAND OFF R29020 COVER R29071 PLASTIC KNOB, ¼-20 THD R29023 CHAIN CATCHER... -
Page 19: Handle Assembly
FIGURE 8 HANDLE ASSEMBLY Item Qty. Part No. Description R29032 SAW HANDLE R29036 LOWER HANDLE R29042 SCREW 5/16-18 X .375 BUTTON HEAD CAP R13135 O-RING R29035 SLEEVE, SPOOL R29044 O RING R29045 SS SPRING PIN, .156 X 1-1/8 LG R29046 SS SPRING PIN, .156 X .5 LG R29029 SAFETY... -
Page 20: Motor Assembly
FIGURE 9 MOTOR ASSEMBLY PARTS SHOWN PG 21 WARNING NOTE: Keep decals clean and legible. Replace decals DO NOT TOUCH when necessary. 15.1 - 30.3 l/min (4 - 8 gpm) CHAIN AND BAR Label Set: Part # 29400 138 Bar (2000 psi) MAY CUT OR BURN EVEN WHEN STOPPED BEFORE USING THIS CHAINSAW... - Page 21 Item Qty. Part No. Description COMPLETE HANDLE ASSEMBLY R29041 NUT, 1/4-20 NYLON LOCKING R13135 O-RING R13128 SCREW, ¼-28 X 1-1/4” SHCS R13106 MOTOR CAP R13131 DOWEL .250 DIA X 1/2 LG R12736 NEEDLE BEARINGS R13107 PLASTIC GASKET R12875 11 TOOTH GEAR R12771 IDLER SHAFT R12795...
-
Page 22: Disassembly
READ BEFORE DISASSEMBLY Before any disassembly, disconnect hoses from the Chainsaw! Any residual pressure within the unit can and will spray at high velocity, injuring the person doing the disassembly. Hot or pressurized hydraulic fluid will cause serious injury to the body! Accidental movement of the chain can cause serious injury, WARNING dismemberment of a hand, finger or any other part of the body. - Page 24 92 Steamwhistle Drive Ivyland, PA 18974 Phone: 800-966-3530 Fax: 215-357-9193 Visit us on the web at www.Reliable-Equip.com...
