Summary of Contents for Technika 42-2030
- Page 3 Please note that the maps are only indicative of the areas in which Freeview HD will be available as the transmission network upgrade progresses. For detailed coverage information associated with specifi c dates, the postcode checker database should be used. English - 1 - A01_MB38_[GB]_3902UK_IDTV-T2_GOLD7_42884W_10068537_50167165.indd 1 A01_MB38_[GB]_3902UK_IDTV-T2_GOLD7_42884W_10068537_50167165.indd 1...
- Page 4 English - 2 - A01_MB38_[GB]_3902UK_IDTV-T2_GOLD7_42884W_10068537_50167165.indd 2 A01_MB38_[GB]_3902UK_IDTV-T2_GOLD7_42884W_10068537_50167165.indd 2 17.06.2010 13:09:59 17.06.2010 13:09:59...
-
Page 5: Table Of Contents
Contents Features ..............4 Setting Favourites ..........18 Introduction ............. 4 Program Guide ..........18 Package Contents ..........4 Common Interface ........... 18 Preparation ............. 5 TV Setup ............18 Safety Precautions ..........5 Setup ..............19 Power Source ............. 5 Confi... -
Page 6: Features
recorder, VCR, PC etc.). This device is only suitable Features for the operation in dry interiors. This appliance is • Remote controlled colour LCD TV. intended solely for private domestic use and may not • Fully integrated digital TV (DVB-T DVB-T2 - MPEG2 be used for industrial and commercial purposes. -
Page 7: Preparation
Preparation Cleaning For ventilation, leave a free space of at least 10 cm Before cleaning, unplug the TV set all around the set. To prevent any fault and unsafe from the wall outlet. Do not use liquid or situations, please do not place any objects on top aerosol cleaners. -
Page 8: Information For Users In European Union Countries
Information for Users in European Electrical device not in the hands of children Union Countries Never let children use electrical device unsupervised. Children can´t always recognize properly the This symbol on the product or on its possible dangers. Batteries / accumulators can be packaging means that your electrical life threatening when swallowed. -
Page 9: Inserting Batteries In The Remote Control
Inserting Batteries in the Environmental Information Remote Control • This television is designed to consume less energy to save environment. • Remove the battery cover located on the back of You not only help to save the environment but also the remote control by gently pulling backwards from you can save money by reducing electricity bills the indicated part. -
Page 10: Overview Of The Remote Control
Overview of the Remote Control Standby / On Mono/Stereo - Dual I-II Expand (in TXT mode)/ Image size Green / Picture Menu / Subtitle on-off (in DTV mode) Red /Sound Menu Numeric buttons Teletext / Mix / PAT (in TXT mode) Cursor Left Menu AV / Source... -
Page 11: Lcd Tv And Operating Buttons
LCD TV and Operating Buttons FRONT and REAR VIEW SIDE VIEW Control Buttons Standby button TV/AV button Programme Up/Down buttons Standby LED Volume Up/Down buttons Note: Press buttons at the same time to view main menu. Viewing the Connections- Back Connectors 1. - Page 12 to AV mode. If both sockets are employed at the same time, EXT 1 will override EXT 2 unless manually selected. Note: You should connect the decoder to EXT-1, if you are planning to watch a scrambled channel. The decoder might not function properly if you do not connect the decoder to the EXT 1 socket. 5.
-
Page 13: Viewing The Connections - Side Connectors
Viewing the Connections - Side Connectors CI Slot is used for inserting a CI card. A CI card allows you to view all the channels that you subscribe to. For more information, see “Common Interface” section. Important Notice: Side USB Input 1 is for service use oniy. Note that this USB connector does not have any other functions such as playing audio or picture fi... -
Page 14: Using Usb Input
Using USB Input Connecting the LCD TV to a PC •You can connect USB devices to your TV by using For displaying your computer’s screen image on the USB input of the TV. This feature allows you to your LCD TV, you can connect your computer to the display/play JPG and MP3 fi... -
Page 15: Connecting To A Dvd Player
Connecting to a DVD Player Using Side AV Connectors If you want to connect a DVD player to your LCD You can connect a range of optional equipment TV, you can use connectors of the TV set. DVD to your LCD TV. Possible connections are shown players may have different connectors. -
Page 16: Input Selection
Operation with the Remote Control Input Selection • The remote control of your TV is designed to control Once you have connected external systems to your all the functions of the model you selected. The TV, you can switch to different input sources. functions will be described in accordance with the •... -
Page 17: General Operation
After Automatic Search is completed, the following General Operation message, asking for analogue channel search, Press the SOURCE button and select DTV from the appears on the screen. list. The TV then switches to digital TV mode. Information Screen • Whenever you change the channel using the P + or To search for analogue channels, select “Yes”. -
Page 18: Programme Options
Using this option, you can switch to the selected channel or exit. Over Air Download To ensure that your IDTV always has the most up- to-date information, please ensure that, after use, it is set to standby mode. At 3 A.M. each day, the IDTV automatically searches for any updates which may be broadcast and will download this to your IDTV automatically. -
Page 19: Idtv Menu System
Deleting the Channels in the Channel IDTV Menu System List • Press MENU button and DTV main menu will be • Press “ ” or “ ” buttons to select the channel that displayed. will be deleted. • Press “ ” or “ ” buttons to select the “Delete’’ item on Channel List OSD. -
Page 20: Setting Favourites
In order to lock a channel you should know the Common Interface Parental Lock password (default value is set to Press MENU button to display the main menu and 0000 in the factory and can only be changed from the use the “... -
Page 21: Setup
Setup AC3 Audio Highlight the AC3 Audio item by pressing “ ” or The adjustments in this menu are given as the “ ” buttons. Use the “ ” or “ ” buttons to set the following: AC3 Audio as On or Off. If the channel that you are watching supports AC3 Audio, turn this setting on. -
Page 22: Language Settings
Guidance When set, this option gets the maturity information from the broadcast and if this maturity level is disabled, the TV will not display the related video-audio. Set PIN Use “ ” or “ ” buttons to go to “Set PIN” option. Press OK to display the “Set PIN”... -
Page 23: Installation
Automatic Channel Scan Automatic channel scan is started by pressing OK button while Automatic channel scan item is highlighted. The following message appears on the screen: You can set the desired language options by using “ ” /“ Highlight Yes or No by using “ ” or “ ” buttons and ”... -
Page 24: Analogue Tv Menu System
the programme numbers and names assigned to the Mode programmes. For your viewing requirements, you can set the related Manual Search mode option. Press “ ” or “ ” button to select Mode . Press “ In Manual Search, the number of the multiplex is entered ”... -
Page 25: Sound Menu
Picture Zoom Press “ ” or “ ” button to change the preset. In equalizer menu, the preset can be changed to Flat, Select Picture Zoom by pressing “ ” or “ ” Classic, User, Music, Movie and Speech. button. Select the desired frequency by pressing “... -
Page 26: Feature Menu
Store information, the TV will then use this setting to adopt. Press “ ” or “ ” button to select Default Zoom . You Press “ ” or “ ” button to select Store. Press “ ” can set Default Zoom to 16:9, 4:3, Panoramic or or OK button to store the settings. -
Page 27: Install Menu
Full Mode (optional) Fine Tune If you connect a device via HDMI or YPbPr connectors Press “ ” or “ ” button to select Fine Tune. Press “ and set 1080i/1080P resolutions, Full Mode item will ” or “ ” button to adjust the tuning. be visible.You can set Full Mode as 1:1 or Normal Search by using “... -
Page 28: Source Menu
By moving the cursor in four directions you can reach 20 programmes in the same page. You can scroll the pages up or down by pressing the navigation buttons to see all the programmes in TV mode (except for the AV modes). -
Page 29: Playing .Mp3 Files
• If you enter the Media Browser menu without plugging a PC Mode Menu System USB device to the TV, “No USB Device” message will be displayed on the menu screen. See “Connecting the LCD TV to a PC” section for connecting a PC to the TV set. -
Page 30: Displaying Tv Information
picture on the screen. In such a case you can use this Zoom Modes item to get a clear picture by trial and error method. You can change the aspect ratio (image size) of the TV Select Phase item by using “ ” or “ ” buttons. Use for viewing the picture in different zoom modes. -
Page 31: Cinema
“OK” Hold Holds a text page when convenient. Press again to resume. “ ” Subcode Pages Cinema Selects subcode pages if available when the teletext This zooms up the wide picture (16:9 aspect ratio) to is activated. Press again to place the teletext screen the full screen. -
Page 32: Tips
Remote Control Tips Your TV no longer responds to the remote control. Screen Care Perhaps the batteries are exhausted. If so you can Clean the screen with a slightly damp, soft cloth. Do still use the local buttons of the TV. not use abrasive solvents as they may damage the Input Sources coating layer of the TV screen. -
Page 33: Appendix A: Pc Input Typical Display Modes
Appendix A: PC Input Typical Display Modes The display has a maximum resolution of 1920 x 1200 . The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen. -
Page 34: Appendix B: Av And Hdmi Signal Compatibility (Input Signal Types)
Appendix B: AV and HDMI Signal Compatibility (Input Signal Types) Source Supported Signals Available PAL 50/60 NTSC 60 EXT 1 RGB 50 RGB 60 PAL 50/60 NTSC 60 EXT 2 RGB 50 RGB 60 PAL 50/60 SIDE AV NTSC 60 PAL 50/60 S-VIDEO NTSC 60... -
Page 35: Appendix C: Supported File Formats For Usb Mode
Appendix C: Supported File Formats for USB Mode Format Remarks File Media Extension Video Audio (Maximum resolution/Bit rate etc.) MPEG 1/2 Sample Rate: 8K ~ 48KHz, Bit Rate: Music .mp3 Layer 1/ 2/ 32K~320Kbps 3 (MP3) Photo MAX. Width 7680 Height 4320, 16 Mega-pixel Baseline .jpg JPEG... -
Page 36: Specifi Cations
Specifi cations Digital Reception (DVB-T) TV BROADCASTING Transmission Standards: PAL/SECAM B/G D/K K’ I/I’ L/L’ MPEG2, MPEG4 HD DVB-T RECEIVING CHANNELS i. DEMODULATION VHF (BAND I/III) -Symbol rate: COFDM with 2K/8K FFT mode. -Modulation: 16-QAM - 64-QAM FEC for all DVB UHF (BAND U) modes (automatically found) HYPERBAND... -
Page 37: Important Instruction
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply. MAINS (AC) OPERATION The wires in the mains lead are coloured in accordance with the following code : GREEN FUSE &...
