NAV-6 is an active GPS and GLONASS antenna especially designed for the
marine environment. It combines the high performance GPS patch antenna
and a 27 dB low noise amplifier (at 5V DC) into a compact waterproof
antenna with exclusive design.
NAV-6 enables the required GPS function for AIS systems, chartplotters, and
other navigational devices, and helps boost the reception signal to the GPS
unit, especially when the GPS receiver doesn't have a good view of the sky.
NAV-6 minimizes temporary loss of signal during navigation and maintains
the best possible accuracy by having a lock on the greatest number of
satellites.
NAV-6 is supplied with deck mount, mounting set and a 15 m RG58 cable
with TNC male connectors. Standard 1" x 14 threads for pole mounting.
Electrical specifications
Frequencies
Impedance
Polarization
LNA Gain
VSWR
Voltage supply
Current
Power (max.)
Operating temperature
GPS/GLONASS (1572 - 1610 MHz)
50 Ohm
RHCP
26dB at 3V, 27 dB at 5V
<1.2:1
2,7V - 5,5V
15 mA to 25 mA
138mW
-40°C to +85°C
NAV-6 GPS Marine Antenna
Operator's manual
ed. 1.2013
1
Advertisement
Table of Contents
Related Manuals for Scout NAV-6
Summary of Contents for Scout NAV-6
- Page 1 NAV-6 is supplied with deck mount, mounting set and a 15 m RG58 cable with TNC male connectors. Standard 1” x 14 threads for pole mounting.
- Page 2 Russian Aerospace Defence Forces. It both complements and provides an alternative to the United States’ Global Positioning System (GPS) and is the only alternative navigational system in operation with global coverage and of comparable precision. NAV-6 is capable of receiving and processing GLONASS signals.
- Page 3 • GPS antennas should NOT be mounted high up a mast, due to the effects of the boat ‘heeling’ on signal reception. • The NAV-6 should be mounted at least 1 m (3 ft) away from devices that may cause interference, such as motors, generators, VHF radio unitsand other transmitters/receivers.
- Page 4 GPS Receiver Module will interfere each other and lower the Position Accuracy. www.scoutantenne.com SCOUT Telecomunicazioni | Via Toscanini 148, 41019 Soliera, Italy tel. +39 059 566650 | fax +39 059 565949 | e-mail: scout@scoutantenne.com SCOUT is a registered trademark. Reg. n. 009799602 Professional Marine Antennas Made In Italy Technical specifications here included may change without prior notice.
