- Page 1 Sea-Connect Wideband 3G/4G/LTE Antenna Installation and user instructions Guida d’installazione e istruzioni utente www.scoutantenne.com rev. 12/2016...
- Page 2 Le prestazioni eccellenti sono confermate da valori VSWR inferiori a 1.5:1 per le bande 3G e 4G. Grazie a una copertura di banda completa da 698-2700 MHz l’antenna Sea-Connect è perfettamente adatta a tutte le seguenti applicazioni: 4G, 3G, AWS, LTE, CLR, DCS, IMT, ISM, PCS, WCDMA, WCS, WiFi, WiMax, Cellular.
- Page 3 Antenna installation - Installazione dell’antenna Install the antenna in accordance with the following procedures to insure maximum performance of the antenna. The antenna should be installed in the place where is an all round clear view of the horizon and ►...
- Page 4 Run the coax cable through the central hole and fit the N male connector on the termination that goes to the antenna. Fate scorrere il cavo coassiale attraverso il foro centrale e montate il connettore N maschio sulla estremità da colegare all’antenna. Tighten the screws for approx 1 cm, then insert the washers, the grower washers and the nuts.
- Page 5 Connect the N male that you fitted on the termination of the coax cable to the N female on the bottom of the antenna, then set the antenna on the surface in a way that both screws enter into the holes that you drilled earlier. Avvitate il connettore N maschio presente all’estremità...
- Page 6 Please keep these instructions safe for future reference. ► Recycle packaging where facilities exist. ► Sea-Connect è garantita per 2 anni da difetti di fabbricazione in termini di materiale e lavorazione ► dal momento dell’acquisto. La garanzia esclude ogni malfunzionamento derivante da uso improprio o accidentale dell’oggetto.
-
Page 8: Specifications
Designed for suitable for vehicles with a negative chassis earth indoor use only efore starting installation SAFETY WARNINGS Sea-Connect ys route cables or wiring carefully acturer’s operating and safety instructions before r vehicles with a negative chassis earth quipment ting installation...
