- Page 1 Easy Installation Guide High Megapixel 360° Panomorph Mini Dome IP Network Camera MD-500Ap-360P Series MD-300Ap-360P Series MD-300Np-360P Series - 1 -...
-
Page 2: Package Contents
Package Contents a. Camera b. Product CD c. Allen Key for The Lens e. Warranty Card d. Allen Key for The Cover f. Screw Bags x 2 g. Dry Bag & Double-Sided Tape h. Alignment Sticker i. Easy Installation Guide j. -
Page 3: Hardware Installation
Hardware Installation Step 1. Check The Product Package Please make sure that the product package contains all the accessories listed above. Step 2. Hardware Installation Do not mount the camera on a soft material. The camera may fall and be damaged. When removing the cover, please be aware of the microphone line. - Page 4 3. Choose the location on the wall or ceiling to place the camera. Attach the location sticker to the desired spot. 4. Drill three holes through the center of the three location holes on the sticker. 5. Hammer the three plastic anchors which are provided in the product package into the three location holes.
- Page 5 a. If you don't use the Mounting Adapter, please use the three shorter screws which are included in the product package. Mount the camera on the wall or ceiling and position the three screw slots over the plastic anchors. Insert the screws into the holes and use the screwdriver to tighten the screws clockwise until they are secure.
- Page 6 Step 3. Camera Connection The camera is DC12V and PoE compliant, so there are two options for powering on the camera. The camera can either be connected to a PoE switch or a non-PoE switch. a. Powering on Camera with PoE Switch: Use an Ethernet cable to connect the camera to the PoE switch.
- Page 7 c. Powering on Camera with DC12V 1A Power Adapter. The Ethernet Cable Is Simply for Data. Step 4. Installation Completed Put the cover back on the camera and fix it by using the Allen Key. - 7 -...
-
Page 8: Software Installation
Insert the CD into the CD-ROM, and follow the instructions of the InstallShield Wizard. If you have problems with the CD, the EasyConfig software can also be downloaded at the Brickcom web site: http://www.brickcom.com/support/download.php. Step 2. Launch EasyConfig Launch the EasyConfig software, and select Simple Mode. Then, choose the desired camera from the survey list to connect. - Page 9 Step 4. Log in The Camera Key in the username and password on the log-in window. The default username and password are “admin” and “admin”. Step 5. Installing the Plug-In Please click to install the plug-in for Internet Explorer. - 9 -...
- Page 10 Image Dewarping This section is going to explain the image dewarping function. The image dewarping function is provided for these cameras on the Live View page with the Internet Explorer. Camera Position: Ceiling, Ground, Wall The Camera Position list box offers 3 modes which reflect where the camera is installed: Ceiling, Ground, and Wall.
- Page 11 Ground – When the camera is fixed on the ground or table, or is installed to shoot in the bottom-up direction, please choose this mode. Wall – When the camera is fixed on the wall, or is installed to shoot in the horizontal direction, please choose this mode.
- Page 12 Panorama: OFF, PTZ, Quad, Perimeter The Panorama list box offers 4 display modes: OFF, PTZ, Quad, and Perimeter. Please select the display mode that best meets your needs. OFF - This is the default display mode, and shows the original elliptical image of the camera. PTZ –...
- Page 13 Quad – This display mode shows four separate PTZ windows. Each window can operate the pan, tilt, and zoom functions. Quad is typically used when the camera is installed on the ceiling or ground. Perimeter – This display mode can dewarp the elliptical image and show the 180-degree view. Perimeter is typically used when the camera is installed on the wall.
-
Page 14: Lens Adjustment
The lens is fixed to have a clear view for the objects 3 meters (10 ft.) away in front of the camera. The Allen Key is provided for the user to adjust the lens. Brickcom is not responsible for any issues caused by the user's adjustment to the lens. - Page 15 Step 3. Focus Adjustment Please click “Real Size” on the control panel of the Internet Explorer Live View page before focusing the image. Then, rotate the Focusing ring to get the image in focus. Step 4. Shape Adjustment Please click “Full Screen” on the control panel of the Internet Explorer Live View page before adjusting the shape of the image.
