Faytech Industrial Motherboard Series Manual

Industrial motherboard series
Hide thumbs
Table of Contents

Advertisement

Quick Links

faytech
Industrial
Motherboard
Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Industrial Motherboard Series and is the answer not in the manual?

Questions and answers

Related Manuals for Faytech Industrial Motherboard Series

Summary of Contents for Faytech Industrial Motherboard Series

  • Page 1 Industrial Motherboard Series...
  • Page 2 Acknowledgments All other products’...

  • Page 3: Table Of Contents

    Contents Chapter 1: Product overview Package contents ................. 1-1 Features ..................1-1 Specifications ................1-2 Chapter 2: Motherboard information Before you proceed ............... 2-1 Motherboard layout ............... 2-2 Screw size ..................2-4 2.3.1 Component side ............. 2-4 2.3.2 Solder side ..............2-5 Central Processing Unit (CPU) .............
  • Page 4 Contents Monitor menu ................. 3-9 3.5.1 CPU Temperature / MB Temperature [xxxºC/xxxºF] ..3-9 3.5.2 Chassis Fan Speed [xxxx RPM] or [N/A] ......3-9 3.5.3 Chassis Q-Fan Control [Enabled] ........3-10 3.5.4 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage ..3-10 Boot menu ..................

  • Page 5: Chapter 1: Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. Motherboard heatink/ cooler optional Cable Kit DVD-ROM for manual (in PDF format) and drivers NOTE: If any of the above items are damaged or missing, contact your distributor or sales representative immediately.

  • Page 6: Specifications

    Power compliance Compliant with Eup/ErP Operating F~131 F (-10 C~55 temperature Operating humidity 0%~90% relative humidity, non-condensing Form factor EPIC form factor: 4.53 in. x 6.5 in. (11.5 cm x 16.5 cm) CE, FCC (continued on the next page) faytech Motherboard...
  • Page 7 Storage 2 x SATA 3Gb/s ports 6 x USB 2.0 ports (2 ports at mid-board, 4 ports on rear I/O) Display I/O 1 x LVDS connector, 1 x VGA connector, 1 x HDMI port Audio I/O Mic-In, Line-Out, S/PDIF onboard headers Amplifier onboard header HDMI support audio LAN I/O...
  • Page 8 Windows 8 32-bit ® Windows 8 64-bit (only with AMD graphics) Linux Fedora Accessories 1 x SATA 3Gb/s cable 1 x SATA power cable 1 x Support DVD (Drivers, Manual) NOTE: Specifications are subject to change without notice. faytech Motherboard...

  • Page 9: Chapter 2: Motherboard Information

    Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.

  • Page 10: Motherboard Layout

    NM10 8111F USB2 USB1 USB3 LCD_POWER_SEL1L_B KBMS1 F_PANEL1 RIGHTNESS1 INV1 ® Intel Super N2600 LVDS_VDD_SEL1CLRTC COM1 BATTERY COM4 DIO1 SATA_PWR1 DDR3 DIMM_A1 COM3 COM2 DC_PWR EATX_PWR1 CHA_FAN1 17 16 Place this side towards the rear of the chassis faytech Motherboard...
  • Page 11 Connectors/Jumpers/Slots Page 1. Digital audio connector (4-1 pin SPDIF_OUT1) 2-13 2. Line-Out / Mic-In audio connector (10-1 pin AAFP1) 2-13 3. SPI programming connector (8-pin SPI1) 2-18 4. Audio amplifier connector (4-pin AMP_CON1) 2-20 5. Serial ATA 3Gb/s connectors (7-pin SATA3G_1/2) 2-17 6.

  • Page 12: Screw Size

    Screw size 2.3.1 Component side faytech Motherboard...

  • Page 13: Solder Side

    2.3.2 Solder side Chapter 2: Motherboard information...

  • Page 14: Central Processing Unit (Cpu)

    This motherboard comes with one Double Data Rate 3 (DDR3) Small Outline Dual Inline Memory Modules (SO-DIMM) socket. The figure illustrates the location of the DDR3 DIMM socket: DIMM_A1 faytech Industrial Motherboard Series DDR3 DIMM socket faytech Industrial Motherboard Series PCIxe1 Straddle faytech Motherboard...
  • Page 15 To install a DIMM To remove a DIMM Chapter 2: Motherboard information...

  • Page 16: Jumpers

    CLRTC1 Normal Clear (Default) faytech Industrial Motherboard Series Clear CMOS RAM To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2.
  • Page 17 COM1 Ring and voltage selection (6-pin J1) +12V Ring (Default) faytech Industrial Motherboard Series COM1 Ring and voltage selection Pins +12V Ring (Default) AT Mode selection (2-pin J2) PIN1 AT MODE faytech Industrial Motherboard Series AT Mode selection Pins AT Mode...
  • Page 18 LVDS backlight brightness control jumper (3-pin L_BRIGHTNESS1) L_BRIGHTNESS1 DC MODE PWM MODE (Default) faytech Industrial Motherboard Series LVDS backlight brightness control jumper Pins DC Mode (Default) PWM Mode LVDS panel VDD setting jumper (3-pin LVDS_VDD_SEL1) LVDS_VDD_SEL1 (Default) faytech Industrial Motherboard Series LVDS panel VDD setting jumper...
  • Page 19 LCD inverter power setting jumper (3-pin LCD_POWER_SEL1) LCD_POWER_SEL1 +12V (Default) faytech Industrial Motherboard Series LCD inverter power setting jumper Pins +12V (Default) Chapter 2: Motherboard information 2-11...

  • Page 20: Connectors

    COM port. This 9-pin COM1 port is for pointing devices or other serial devices. Lockable DC power port (+12V). This port connects to a DC power adapter. To select the correct power adapter, refer to the inner and outer dimensions of this power port. faytech Motherboard 2-12...

  • Page 21: Internal Connectors

    PIN 1 A_MIC1_LA_MIC1_RLINE-RA _JD_FRONTLINE-L faytech Industrial Motherboard Series Line-Out / Mic-In audio connector Digital audio connector (4-1 pin SPDIF_OUT1) This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this connector, then install the module to a slot opening at the back of the system chassis.
  • Page 22 Is designed to fit this connector in only one orientation. Find the proper Orientation and push down firmly until the connector completely fit. EATX_PWR1 faytech Industrial Motherboard Series EATX power connector Serial port connectors [WtoB CON 9P, 1.25mm, S/T, SMT / ACES / 50273- 00971-001] (9-pin COM2/3/4) These connectors are for serial (COM) ports.
  • Page 23 CHA_FAN1 PWMSENSEVCCGND faytech Industrial Motherboard Series Chassis fan connector CAUTION: Do not forget to connect the fan cable to the fan connector. Insufficient air flow inside the system may damage the motherboard components.
  • Page 24 PANSWH# HWRST# RESET (NC) faytech Industrial Motherboard Series System panel connector • System power LED (2-pin PWR LED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
  • Page 25 SATA3G_2 GNDRSATA_TXP2RSATA_TXN2GNDRSATA_RXN 2RSATA_RXP2GND SATA3G_1 GNDRSATA_RXP1RSATA_RXN1GNDRSATA_TXN 1RSATA_TXP1GND faytech Industrial Motherboard Series SATA 3.0Gb/s connectors NOTES: • These connectors are set to [IDE] by default. In IDE mode, you can connect Serial ATA boot/data hard disk drives to these connectors. • You must install Windows XP Service Pack 3 or later version before using ®...
  • Page 26 USB4-_R USB5+_R USB4+_R USB5-_R faytech Industrial Motherboard Series USB 2.0 connector CAUTION! Never connect a 1394 cable to the USB connector. Doing so will damage the motherboard! NOTE: The USB module cable is purchased separately. SPI programming connector (8-pin SPI1) Use this connector to flash BIOS SPI ROM.
  • Page 27 PINREX / 721-81-05TW00] (5-pin INV1) Connect the backlight inverter power cable to this connector. INV1 +VCC_LVDS1_BKLT L_BRIGHTNESS1 BKLT_EN faytech Industrial Motherboard Series Backlight inverter power connector NOTE: The backlight inverter power cable is purchased separately. Chapter 2: Motherboard information 2-19...
  • Page 28 Industrial Motherboard Series VGA connector 15. Audio amplifier connector [WtoB CON4P, 1.25mm, S/T, SMT // ACES / A 85025-04701] (4-pin AMP_CON1) This connector is for an external audio amplifier. AMP_CON1 LOUTPLOUTNROUTNROU PIN 1 faytech Industrial Motherboard Series Speaker out connector faytech Motherboard 2-20...
  • Page 29 LVDS_DN3 LVDSB_L3N_GPU LVDS_DP3 LVDSB_L3P_GPU +VDD_LVDS1 LVDS_CLKN LVDSB_LCLKN_GPU faytech Industrial Motherboard Series LVDS connector 17. Battery connector (2-pin BATTERY) This connector is for the lithium CMOS battery. BATTERY BATT1 PIN 1 faytech Industrial Motherboard Series Battery connector Chapter 2: Motherboard information...
  • Page 30 DIO_P#6 (GPIO85) DIO_P#7 (GPIO86) DIO_P#8 (GPIO87) faytech Industrial Motherboard Series Digital I/O connector NOTE: To configure the I/O pins in BIOS, go to the Advanced tab > DIO Function > GPIO 1~8. See section 3.4.6 DIO Function for details. faytech Motherboard...

  • Page 31: Chapter 3: Bios Setup

    Chapter 3 BIOS setup BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program. Entering BIOS Setup at startup To enter BIOS Setup at startup: •...

  • Page 32: Bios Menu Screen

    For changing the advanced system settings. Monitor For displaying the system temperature, power status, and changing the fan settings Boot For changing the system boot configuration. Tool For configuring options for special functions. Exit For selecting the exit options and loading default settings. faytech Motherboard...
  • Page 33 Menu items Thehighlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items. Back button This button appears when entering a submenu.

  • Page 34: Main Menu

    Clock (RTC) RAM to clear the BIOS password. See section 2.6 Jumpers for information on how to erase the RTC RAM. The Administrator or User Password items on top of the screen show • the default Not Installed. After you set a password, these items show Installed. faytech Motherboard...
  • Page 35 Administrator Password If you have set an administrator password, we recommend that you enter the administrator password for accessing the system. Otherwise, you might be able to see or change only selected fields in the BIOS setup program. To set an administrator password: Select the Administrator Password item and press <Enter>.

  • Page 36: Advanced Menu

    Two threads per activated core are enabled. [Disabled] Only one thread per activated core is enabled. Limit CPUID Maximum [Disabled] [Enabled] Allows legacy operating systems to boot even without support for CPUs with extended CPUID functions. [Disabled] Disables this function. faytech Motherboard...

  • Page 37: Ide Configuration

    3.4.2 IDE Configuration While entering Setup, the BIOS automatically detects the presence of SATA devices. The SATA Port items show Not Present if no SATA device is installed to the corresponding SATA port. SATA Controller(s) [Enabled] [Disabled] Disables the onboard SATA controllers. [Enabled] Enables the onboard SATA controllers.

  • Page 38: Panel Controller (Amd Gpu Only)

    [Disabled] Disables the controller. RS Mode [RS232] Allows you to configure the serial communications standard of serial port (COM) 1. Configuration options: [RS232] [RS422] [RS485] Onboard LAN [Enabled] [Enabled] Enables the Realtek LAN controller. [Disabled] Disables the controller. faytech Motherboard...

  • Page 39: Monitor Menu

    Onboard LAN Boot ROM [Disabled] This item appears only when you set the Onboard LAN item to [Enabled] and allows you to enable or disable the Boot ROM of the onboard LAN controller. Configuration options: [Enabled] [Disabled] Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings.

  • Page 40: Chassis Q-Fan Control [Enabled]

    The Boot menu items allow you to change the system boot options. 3.6.1 Bootup NumLock State [On] [On] Sets the power-on state of the NumLock to [On]. [Off] Sets the power-on state of the NumLock to [Off]. faytech Motherboard 3-10...

  • Page 41: Full Screen Logo [Disabled]

    3.6.2 Full Screen Logo [Disabled] [Enabled] Enables the full screen logo display feature. [Disabled] Disables the full screen logo display feature. 3.6.3 Wait for ‘F1’ If Error [Enabled] When this item is set to [Enabled], the system waits for the F1 key to be pressed When error occurs.

  • Page 42: Exit Menu

    Discard Changes & Exit This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit. faytech Motherboard 3-12...

  • Page 43: Appendix

    Appendix Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation.
  • Page 44 Anything received with postage due will be returned to you without any testing or resolution. Within the first 30 days after you buy a new faytech product, we will refund your shipping costs for returned products. For the rest of the warranty period,...
