S&C IntelliCom® Mesh Radio

Table of Contents

Section
MIMO Radio Technology . . . . . . . . . . . . . . . . . . . . . . . . . 2
Dual-Radio Performance . . . . . . . . . . . . . . . . . . . . . . . . 3
With MIMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Without MIMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
802 .11n MIMO Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
802 .11n Non-MIMO Mode . . . . . . . . . . . . . . . . . . . . . . . . 5
October 29, 2012© S&C Electric Company
Throughput Reference Guide
Page
Section
Only Non-MIMO Mode Is Supported . . . . . . . . . . . . . . . 6
802 .11n Non-MIMO Mode . . . . . . . . . . . . . . . . . . . . . . . . 7
Instruction Sheet 1069-570
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntelliCom and is the answer not in the manual?

Questions and answers

Related Manuals for S&C IntelliCom

Summary of Contents for S&C IntelliCom

  • Page 1 Dual-Radio Performance . . . . . . . . . . . . . . . . . . . . . . . . 3 IntelliCom DA Mesh Radio Throughput Summary...
  • Page 2 802.11n technology for throughput of up to 300 Mbps outdoors and 400 Mbps indoors. MIMO Radio MIMO (Multiple Input Multiple Output) technology is available only in the IntelliCom WAN Mesh Radio. MIMO radios use multiple antennas at both the transmitter and receiver to Technology improve performance.
  • Page 3 • Only one MIMO license is required per radio; the MIMO feature is enabled by default for both radios. Dual-Radio To maximize performance, dual-radio IntelliCom WAN Mesh Radios support two radio modes: bonded and linear (single). Performance • Bonded Mode—both radios are combined to operate as a single unit, that provides double the bandwidth of a single radio equivalent.
  • Page 4 IntelliCom WAN Mesh Radio Deployment Considerations Configuration selections establish the performance of an IntelliCom Mesh Radio network. The following information shows maximum capacity for the IntelliCom WAN Mesh Radio. System Parameters With MIMO A pair of mesh radios is installed outdoors, operating at a maximum modulation level of 64 QAM 5/6 in a Clear LOS PtP setup.
  • Page 5 IntelliCom WAN Mesh Radio Throughput Summary This information applies for all channel bandwidths, regardless of the operating frequency band. 802.11n MIMO Mode Linear Mode (single radio) • 5 MHz = 18 Mbps UDP • 10 MHz = 35 Mbps UDP •...
  • Page 6 IntelliCom DA Mesh Radio Deployment Considerations Configuration selections establish the performance of an IntelliCom Mesh Radio network. The following information shows maximum capacity for the IntelliCom DA Mesh Radio. Only Non-MIMO Mode System Parameters Is Supported A pair of mesh radios is installed outdoors, operating at a maximum modulation level of 64 QAM 5/6 in a Clear LOS PtP setup.
  • Page 7 IntelliCom DA Mesh Radio Throughput Summary This information applies for all channel bandwidths, regardless of the operating frequency band. 802.11 Non-MIMO Mode Linear Mode (single radio) • 5 MHz = 9 Mbps UDP • 10 MHz = 18 Mbps UDP •...
