S&C SpeedNet
SDR Software Defined Radio

Table of Contents

Section
Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this Instruction Sheet . . . . . . . . . . . . . . . . . . . . . . 2
Retain this Instruction Sheet . . . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Interface Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Static Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
AODV Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
AODV Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
AODV Blacklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
AODV Apply Configuration . . . . . . . . . . . . . . . . . . . . . . 14
August 14, 2017
© S&C Electric Company 2015-2017, all rights reserved
Setup
Page
Section
RF Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Radio RF Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Radio Network Settings . . . . . . . . . . . . . . . . . . . . . . . . 17
Local Serial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Serial Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Radio Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Channel Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Neighbor List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Radio RF Ping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Instruction Sheet 1075-530
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpeedNet SDR and is the answer not in the manual?

Questions and answers

Summary of Contents for S&C SpeedNet SDR

  • Page 1: Table Of Contents

    S&C SpeedNet ™ SDR Software Defined Radio Setup Table of Contents Section Page Section Page Radio Introduction RF Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Qualified Persons .
  • Page 2: Introduction

    . Read this Thoroughly and carefully read this instruction sheet before installing or operating your S&C SpeedNet SDR Software Defined Radio. The latest version is available online in PDF Instruction Sheet format at sandc.com/en/Support/Product-Literature. These instructions apply to SpeedNet SDR Radio Firmware 1.37.X, and Ethernet Firm- ware version sc4(x4)-EBA.5.2.X.
  • Page 3: Warranty

    The standard warranty contained in the seller’s standard conditions of sale, as set forth in Price Sheets 150 and 155, applies to S&C SpeedNet SDR Software Defined Radios, except the first paragraph of said warranty is replaced by the following: (1) General: Seller warrants to purchaser for a period of two years from the date of ship-...
  • Page 4: Network Setup

    192.168.202.2. The wireless interface of the SpeedNet SDR Radio from Destination Node is assigned an address of 192.168.202.3. In this example, each SpeedNet SDR Radio host ID is 1 (as in 192.168.3.1), while the connected application device uses a host ID of 2 (as in 192.168.3.2). Following a numbering scheme such as this will make it easier to keep track of which IP addresses are assigned to each device.
  • Page 5: Configuration

    Web browser and entering the IP address of the radio. The default IP address of a SpeedNet SDR is set to 192.168.0.3 at the factory. Note that your PC IP address must be on the same LAN segment of the SpeedNet SDR radio.
  • Page 6: Network

    Ethernet port subnets and the wireless subnet. MAC Address —This read-only field displays the unique Media Access Control (MAC) address for each of the SpeedNet SDR Radio interfaces. No two network devices will use the same MAC address.
  • Page 7 Default IP Gateway —Enter the IP address of the next-hop gateway that will act as the default gateway for this SpeedNet SDR Radio. The gateway will be the IP address of the wireless interface of a SpeedNet SDR Radio. NOTE: This Gateway address is not typi- cally configured for when AODV routing is enabled.
  • Page 8: Static Routes

    — This is the next-hop gateway of the destination network for which the route is being created. The gateway will be the IP address of the wireless interface of a SpeedNet SDR Radio. • —After entering the details of the static route, click the button to add the route to the route table.
  • Page 9: Network-Aodv

    The Main screen provides a list of tabs that can be used to configure the routing performance of a SpeedNet SDR Radio. Selecting a tab will provide a list of configurable options. The AODV Settings tab, shown in Figure 8, is used to enable, disable, or configure the embedded ad hoc (mesh) routing protocol.
  • Page 10 Node Traversal Time —This value provides an estimate of the time required for a packet to traverse one wireless hop. The value affects how long a SpeedNet SDR Radio waits before resending a route-request packet. This value is measured in milliseconds and has a default value of 800 msec.
  • Page 11 Enable AODV Gateway check box enables this feature and provides the additional configuration options detailed below. The Enable AODV Gateway option should only be enabled on the SpeedNet SDR Radio that will act as the gateway for the rest of the wireless network.
  • Page 12: Aodv Network

    SpeedNet SDR AODV Gateway Radio as a gateway to other networks. See Figure 9. The table must be populated to include all of the Ethernet subnets of all SpeedNet SDR Radios. All wireless networks used by the radios must also be configured in this table. This list of...
  • Page 13: Aodv Blacklist

    Network—AODV AODV Blacklist The AODV Blacklist feature is used to prevent routing through SpeedNet SDR Radios that qualify as valid neighbors, but are neighbors that you do not want to use as next hop links for that particular radio address. See Figure 10. One reason to exclude a neighbor is that it may have a permanent or transient line-of-sight impediment, which results in poor packet delivery success over a given radio link.
  • Page 14: Aodv Apply Configuration

    Network—AODV AODV Apply Configuration Figure 11. The AODV Apply Configuration screen. AODV Apply Configuration —Clicking on the button will re-start the AODV Apply module and put into effect any changes made in the AODV Settings, Network, or Blacklist screens. See Figure 11. S&C Instruction Sheet 1075-530...
  • Page 15: Radio

    Radio RF Modules Figure 12. The Radio>RF Modules screen. The screen shown in Figure 12 graphically displays the present state of each installed radio. Click a radio-selection button to toggle power to that radio. A radio that is powered off will be automatically powered back on after a 2-minute interval to prevent inadvertently being disconnected from the radio.
  • Page 16: Radio Rf Settings

    Radio Radio RF Settings Figure 13. The Radio RF Settings screen. Figure Navigate to the Radio RF Settings screen. See Enter the master and slave frequencies to use. Note: On an AODV mesh system, these two frequencies will be the same. Master Tx Freq —The operating channel of the radio.
  • Page 17: Radio Network Settings

    Radio Radio Network Settings Figure 14. The Radio Network Settings screen. Navigate to the Radio Network Settings screen. See Figure 14. Description —Enter the alphanumeric name for the radio interface. Network Type —The options are Point to Point, Point to Multipoint, and CSMA Peer to Peer.
  • Page 18: Serial

    Serial Local Serial Settings The SpeedNet SDR Radio is equipped with two serial ports. Each serial port may be individually configured for RS232, RS422, or RS485. Select the Local Serial Settings menu from the menu to support the local serial ports on the radio. See Figure 15.
  • Page 19: Serial Services

    Serial Serial Services Figure 16. The Serial Services screen. This page displays the Serial Services, as shown in Figure 16. Serial Services may be added and configure here. Click on the Add button, and the dialog box will open. Note: The host serial application my target either the radio wire- less or Ethernet address for serial services.
  • Page 20: Diagnostics

    Diagnostics, Channel Utilization, Neighbor List, and Radio RF Ping. See Figure 17. Figure 17. The Radio Diagnostics screen. SpeedNet SDR Radios continuously monitor several important RF and radio-operating parameters for each frequency channel they use. These parameters are reported on this page.
  • Page 21: Channel Utilization

    SpeedNet SDR Radio. The Neighbor List provides a list of SpeedNet SDR Radios that are communicating wire- lessly with the local SpeedNet SDR Radio. The Neighbor List is updated each time messages are exchanged from another SpeedNet SDR Radio. IP Address—This field provides the IP address of the wireless interface of a Speed- Net SDR Radio whose Hello message has been received by the local SpeedNet SDR Radio.
  • Page 22: Radio Rf Ping

    The Radio RF Ping feature enables the direct testing of connectivity and link quality between two SpeedNet SDR Radios and can be initiated from either side of the link. To use this feature, enter the Radio ID for the radio on the far side of the link you wish to test and click on the Ping button.
  • Page 23: Management

    Management Administration Figure 21. The Administration screen. The Administration tab allows the user to change the password. After entering the new password and confirming, click on . See Figure 21. the Apply button Reboot Device eboots the radio. —This r Reset to Factory Defaults —This s ets the radio to factory defaults.
  • Page 24: Files

    Management Files Figure 22. The Files screen. New firmware and radio configuration files are loaded into the radio on this page. The OS section is for new operating system firmware for the Ethernet board within the radio. The Radio section is for new firmware for the radio RF module. The Configuration section is for support of the text editable radio configuration file.
