S&C IntelliCom® Mesh Radio

Table of Contents

Section
Understanding Safety-Alert Messages . . . . . . . . . . . . . . 2
Following Safety Instructions . . . . . . . . . . . . . . . . . . . . . 2
Replacement Instructions . . . . . . . . . . . . . . . . . . . . . . . . 2
Power Line Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Radio Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setup and Configuration . . . . . . . . . . . . . . . . . . . . . . . . 4
Radio Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preparing for Installation . . . . . . . . . . . . . . . . . . . . . . . . . 5
Tools Needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preparing Earth Ground . . . . . . . . . . . . . . . . . . . . . . . . . 6
Antenna Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mounting Outdoor Antennas . . . . . . . . . . . . . . . . . . . . . . 6
November 26, 2012© S&C Electric Company
Installation
Page
Section
Mounting IntelliCom WAN Mesh Radio . . . . . . . . . . . . . . 7
Pole Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Mounting Straps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Mounting Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Powering Other Ethernet Devices . . . . . . . . . . . . . . . . . . 9
Connecting Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
AC Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DC Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . 16
Custom DC Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . 12
Instruction Sheet 1069-500
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntelliCom and is the answer not in the manual?

Questions and answers

Related Manuals for S&C IntelliCom

Summary of Contents for S&C IntelliCom

  • Page 1: Table Of Contents

    Safety Mounting IntelliCom WAN Mesh Radio . . . . . . . . . . . . . . 7 Pole Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Understanding Safety-Alert Messages .

  • Page 2: Safety

    Safety There are several types of safety-alert messages which may appear throughout this Understanding instruction sheet and on labels attached to the radio. Familiarize yourself with these Safety-Alert types of messages as explained below. Messages Ç DANGER “DANGER” identifies the most serious and immediate hazards which will likely result in serious personal injury or death if instructions, including recommended precautions, are not followed .

  • Page 3: Power Line Safety

    . • The IntelliCom WAN Mesh Radio has built-in lightning protection, but antennas still need their own lightning protection. Be sure that any other equipment connected to the IntelliCom Radio has the same level of protection.

  • Page 4: Setup And Installation

    Setup and Installation Radio Kit Contents The IntelliCom DA Mesh and WAN Mesh Radio kits contain the items shown in Table 1. Table 1—IntelliCom DA Mesh and WAN Mesh Radio Kit Contents Item Radio Radio Qty. Qty. Warranty and registration card CD with Software;...

  • Page 5: Preparing For Installation

    Setup and Installation Preparing for 1. Verify that all radios (nodes) are visible in the IntelliCom View Pro software. If not, Installation troubleshoot per directions in the IntelliCom View Pro Reference Guide. 2. Set the country code for your country of operation.

  • Page 6: Tools Needed

    Preparing Earth Ground The IntelliCom WAN Mesh Radio must be properly connected to earth ground. Failure to do so may result in equipment damage, injury, or death. The product warranty does not cover damages resulting in part or in whole from improper grounding. Consult your local building and electrical codes regarding antennas and follow them, or consult the National Electrical Code (NEC) guide.

  • Page 7: Mounting Intellicom Wan Mesh Radio

    Use appropriate anchors when attaching to masonry or other materials. Figure 1. IntelliCom WAN Mesh Radio universal mounting bracket. Figure 2. Attaching the IntelliCom WAN Mesh Radio mounting bracket. S&C Instruction Sheet 1069-500...

  • Page 8: Pole Mounting

    Now that you’ve attached the Universal Mounting Plate, you are ready to proceed to the next steps. If you are using separately mounted antennas, mount them now. If you are using the temporary staging antennas, slide the IntelliCom WAN Mesh Radio onto the mounting plate; secure it with four screws.

  • Page 9: Power Connection

    Figure 4. IntelliCom WAN Mesh Radio power and Ethernet connectors. Power Connection Connect the ac power cable to ac power and to the IntelliCom WAN Mesh Radio. Refer to Figure 4, from left to right: ac power, dc power, Ethernet Port 3 (PoE), Ethernet Port 2 (PoE), Ethernet Port 1 (no PoE), USB (not used).

  • Page 10: Specifications

    26 dBm 802 .11nn 26 dBm n 802 .11n is supported on the IntelliCom WAN Mesh Radio only . Supported Data Rates and Standards • 802.11a 6/9/12/18/24/36/48/54 Mbps • 802.11a 1⁄4 and 1⁄2 rates for 4.940–4.990 GHz Public Safety Band • 802.11b 1/2/5.5/11 Mbps...

  • Page 11: Environmental Specifications

    Power • IntelliCom DA Mesh Radio: 12 Vdc ±15%, 1.8 A • IntelliCom WAN Mesh Radio: 12 Vdc ±15%, 3 A; or 90-240 Vac 50-60 Hz, 0.9 A • IntelliCom DA Mesh Radio: PoE PD on Port 1 • IntelliCom WAN Mesh Radio: Ports 2 and 3: IEEE 802.3af compliant PoE (PSE), 13.5 W max...

  • Page 12: Regulatory Information

    Regulatory Information FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an office installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 13 Canadian units will not transmit in the 5600–5650 MHz band. DFS Notice IntelliCom WAN Mesh Radio devices are subject to Section 15.407 of FCC rules and are required to implement radar detection and DFS functions. They are DFS-certified, and will not transmit on channels which overlap the 5600–5650 MHz band (channels 120, 124, 128).
  • Page 14 Regulatory Information Table 3—U.S. Terminal Doppler Weather Radar Installations City Longitude Latitude Frequency Phoenix W 112 09 46 N 33 25 14 5610 MHz CO Denver W 104 31 35 N 39 43 39 5615 MHz Ft Lauderdale W 080 20 39 N 26 08 36 5645 MHz Miami...
  • Page 15 Regulatory Information Table 3—U.S. Terminal Doppler Weather Radar Installations— continued City Longitude Latitude Frequency OH Columbus W 082 42 55 N 40 00 20 5605 MHz Aero . Ctr TDWR #1 W 097 37 31 N 35 24 19 5610 MHz Aero .

  • Page 16: Connector Wiring-Intellicom Wan Mesh Radio

    Connector Wiring—IntelliCom WAN Mesh Radio AC Power Connection Figure 6 shows the pin out of the ac power connector for an IntelliCom WAN Mesh Radio. Views are shown for the connector on the unit, and the mating connector on the cable itself.
