S&C SpeedNet
™
Radio

Table of Contents

Section
Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this Instruction Sheet . . . . . . . . . . . . . . . . . . . . . . 2
Retain this Instruction Sheet . . . . . . . . . . . . . . . . . . . . . . 2
Proper Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warranty Qualifications . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Antenna Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Understanding Safety-Alert Messages . . . . . . . . . . . . . . 5
Following Safety Instructions . . . . . . . . . . . . . . . . . . . . . 5
Replacement Instructions and Labels . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Packing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
S p e e d N e t Ra d i o s o ft wa re a n d i n s t r u c t i o n s h e e t s c a n b e d ow n l o a d e d a t
sandc.com/support/automation-customer-support-portal.asp If you need assistance,
please contact customerportal@sandc .com or phone (800) 621-5546 .
April 25, 2016
© S&C Electric Company 2010-2016, all rights reserved
Installation and Operation
Page
NOTICE
Section
Before Starting Installation . . . . . . . . . . . . . . . . . . . . . . . .8
Network Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Cable Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
IP Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Subnet Masking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Private Subnets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Network Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Routing Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using Static Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Interface Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Instruction Sheet 1072-510
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpeedNet Radio and is the answer not in the manual?

Questions and answers

Related Manuals for S&C SpeedNet Radio

Summary of Contents for S&C SpeedNet Radio

  • Page 1: Table Of Contents

    S&C SpeedNet ™ Radio Installation and Operation Table of Contents Section Page Section Page Introduction Installation Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Before Starting Installation .

  • Page 2: Introduction

    . Retain this This instruction sheet should be available for reference wherever a SpeedNet Radio is to be used. Retain this instruction sheet in a location where you can easily retrieve and Instruction Sheet refer to it.

  • Page 3: Warranty

    Warranty Warranty of the SpeedNet Radio is contingent upon the installation, configuration, and use of the SpeedNet Radio and software in accordance with S&C’s applicable instruction Qualifications sheets. This warranty does not apply to major components not of S&C manufacture, such as batteries, and other communication devices not of S&C manufacture.

  • Page 4: Antenna Requirements

    Introduction Antenna SpeedNet Radios have been designed to operate with the antennas listed in these bulleted items having a maximum gain of 3 dBd (5.15 dBi) or 10 dBd (12.15 dBi), respectively, Requirements and an impedance of 50 ohms: • Omni-directional fiberglass antenna: Antenex FG9023 or equivalent, 3 dBd (5.15 dBi) •...

  • Page 5: Safety Information

    Safety Information Understanding Several types of safety-alert messages may appear throughout this instruction sheet as well as on labels attached to the SpeedNet Radio. Familiarize yourself with these types Safety-Alert Messages of messages and the importance of these various signal words: DANGER “DANGER”...

  • Page 6: Safety Precautions

    Some of these precautions may differ from your company’s operating procedures and rules . Where a discrepancy exists, follow your company’s operating procedures and rules . 1 . QUALIFIED PERSONS. Access to an SpeedNet Radio 5 . SAFE DISTANCE. must be restricted only to qualified persons . See “Qualified •...

  • Page 7: Shipping And Handling

    3. File a claim with the carrier. Also notify S&C Electric Company in all instances of loss and/or damage. Packing A SpeedNet Radio shipment includes the following items: 1. SpeedNet Radio 2. Power cord 3. Antennas and other accessories, as applicable...

  • Page 8: Installation

    SpeedNet Radios serve as a communication end point for SCADA devices. They can connect to a SpeedNet Radio mesh network, and they can be installed in a variety of network configurations. Plan your network in advance, and develop a logical IP addressing scheme for your particular application.

  • Page 9: Antenna/Cable Installation Requirements

    +38 dBm. In this situation, the antenna cable must provide at least 2 dB loss in order to bring the EIRP into compliance. SpeedNet Radios have configurable transmit power that can be selected using the SpeedNet Radio client tool or by using the IntelliTeam CNMS Communication Network Management System. Settings of +30 dBm (default), +25 dBm, and +10 dBm are available.
  • Page 10 170 feet/4 .3 dB loss +36 .0 dBm +12 .1 dBi 245 feet/6 .1 dB loss +36 .0 dBm Assuming 1-watt output power from the SpeedNet Radio . ① Table 4. Antenna Cable Loss Examples with LMR-900 Cable ① Antenna Gain Length/Loss +8 .2 dBi...

  • Page 11: Operation

    Operation IP Basics SpeedNet Radios use Internet Protocol (IP) version 4, and all references to IP addresses in these installation instructions refer to IPv4 addresses. An IP address is the unique identifier for a node (host connection) on an IP network. The IP address is a 32-bit binary number, usually shown as four decimal values separated by decimal points.

  • Page 12: Subnet Masking

    Operation Subnet Masking Applying a subnet mask to an IP address allows you to identify the network and node parts of the address. The network bits are represented by the “1”s in the mask, and the node bits are represented by the “0”s. Performing a bitwise logical AND operation between the IP address and the subnet mask results in the network address or number.

  • Page 13: Mac Address

    Radios have unique MAC addresses. Some devices have user-configurable MAC addresses, but the SpeedNet Radio MAC address is configured at the factory and cannot be changed. Most protocols use MAC addresses that are globally unique, but not all protocols use MAC addresses or require that they be unique.

  • Page 14: Network Example

    Once the individual data networks are established, plan the IP addressing scheme. In Figure 1, each SpeedNet Radio host ID is 1, and each automatic switch control host ID is 2. Following a numbering scheme such as this will make it easier to keep track of which IP addresses are used for each device.
  • Page 15 Operation SpeedNet 1 Wireless Interface: 192.168.4.1 Ethernet Interface: 192.168.1.1 SpeedNet 2 Wireless Interface: 192.168.4.2 Ethernet Interface: 192.168.2.1 IP Address: 192.168.1.2 Default Gateway: 192.168.1.1 IP Address: 192.168.2.2 Default Gateway: 192.168.2.1 SpeedNet 3 Wireless Interface: 192.168.4.3 Ethernet Interface: 192.168.3.1 Ethernet IP Address: 192.168.3.2 IP Address: 192.168.3.3 Default Gateway: 192.168.3.1 Default Gateway: 192.168.3.1...

  • Page 16: Routing Options

    Using Static Routes Figure 3 is an example of a point-to-point SpeedNet Radio network. In this example, Subnet 1 has been assigned the 192.168.1.0 Class C subnet, while Subnet 2 has been assigned the 192.168.2.0 Class C subnet. For the wireless network common between the two radios, the 192.168.3.0 Class C subnet has been assigned.
  • Page 17 SpeedNet Radio. The SpeedNet Radio from Subnet 1 must have a static route to Subnet 2, using the SpeedNet Radio from Subnet 2 as the gateway. The route should be set up like this: 192.168.2.0...

  • Page 18: Interface Pinouts

    The SpeedNet Radio Ethernet interface uses an RJ-45 connector with the pinout shown in Figure 5. The Ethernet port is on the rear panel of the SpeedNet Radio. It is auto-sensing for assignment of transmit and receive lines (no crossover cables required) and auto-negotiates for 10-Mbps or 100-Mbps data rate as required by the connected device.
