Vehicles equipped with a REF Radio will require a Premium Radio upgrade so that the vehicle
speakers will function when a DVD is playing.
TOOLS REQUIRED:
• 8mm, 10mm Sockets
• Small metal scale
• Air wrench
• Serrated grinding bit
CONTENTS:
4
8
5
K6859438
CHRYSLER 300, DODGE MAGNUM, DODGE CHARGER
• Socket wrench
• Sharp metallic pencil
• Diagnostic STAR SCAN tool
3
DVD REAR SEAT VIDEO SYSTEM
INSTALLATION INSTRUCTIONS
• Long extension
• Phillips driver
• Utility knife
• Air saw
Item
9
10
11
1
2
7
07/22/2005
• Non-metal trim stick
• Drill motor
Qty. Description
1
1
Rear Mounting Bracket
2
1
Front Mounting Bracket
3
1
VES Assembly
4
4
Screws
5
1
Power Harness
6
6
Batteries
7
2
Headphones
8
1
Bin Mat
9
1
DVD Remote
1
Mercury Warning Label
1
Operating Instructions
6
• 6mm Drill bit
10
Page 1 of 9
