Setup Instructions:

Making Connections:
• Using the Profile speaker cables, or a set of your own, connect an end of each cable into the
speaker outputs of the mixer ( & ). Then connect the opposite end of each cable to the
appropriate speaker cabinet input ( ). Hint: For ease of use, connect the right output jack ( ) to the
speaker cabinet on the right side of the mixer front and connect the left output jack ( ) to the
speaker cabinet on the left side of the mixer front. Doing this will ensure that the pan control ( ) will
be in sync with the appropriate speaker.
• If you are using a powered monitor, connect the input of the powered monitor to the monitor output
jack ( ) on the back of the mixer.
• If you are using a powered subwoofer, connect the input of the powered subwoofer to the sub output
jack ( ) on the back of the mixer.
• Be sure that the power switch ( ) is set to the "off" position and then attach the AC cable to the AC
input jack ( ).
• Plug in the microphones and instruments you plan to use into the mic/line combination jacks ( & ).
Note: If you are using an instrument that has a stereo output connect that one to the mic/line
combination jack on channel 5 ( ) using a stereo (tip/ring/sleeve) cable. If you are using a passive
acoustic instrument, you should use the mic/line combination jack on channel 5 ( ) and set the
inst/line switch ( ) to the inst position.
• If you are using an audio source, such as a CD player or computer, connect the output of the source
to the RCA input jacks ( ) or the line input jack ( ).
• If you are using a microphone with a mini (1/8") plug, you can use the mic in jack ( ) to connect to
the mixer.
Master Section:
• Turn the master volume control ( ) and the monitor volume control ( ) counter-clockwise to the
lowest setting.
• Set the master equalizer controls ( ) to their center positions (0dB).
• If you are not using a subwoofer, set the sub volume to the center position. If you are using a
subwoofer, set the sub volume to its lowest position.
• Turn the effects volume control ( ) counter-clockwise to the lowest setting.
Input Section:
• Turn all volume controls ( ) counter-clockwise to their lowest positions.
• Set the pan controls ( ) to their 12 o'clock positions.
• Set the treble and bass controls ( & ) to their 12 o'clock positions.
• Turn the monitor controls ( & ) counter-clockwise to their lowest positions.
• Turn the effects controls ( ) counter-clockwise to their lowest positions.
Playing:
• Turn the power switch ( ) to the "on" position. Note: The power indicator ( ) on the front of the
mixer should now be lit.
• Turn the master volume control ( ) clockwise to the 9 o'clock position and begin adjusting the
volume controls ( ) of the individual channels (that you are using) clockwise to reach desired level.
After you are happy with the basic level, you then use the master volume control ( ) to increase or
decrease the overall amount of volume. Note: If you are using a powered subwoofer, adjust the sub
volume slider ( ) to the center position. After setting the basic level, you can then adjust this control
to increase or decrease the output of the powered subwoofer.
• Adjust the treble and bass controls ( & ) on the individual channels and the master equalizer
controls ( ) to achieve the desired sound.
• Turn the master effects volume control ( ) clockwise to the 9 o'clock position and begin adjusting the
effects controls ( ) on the individual channel to achieve the desired amount of digital effects for each
channel. Note: You should also turn the effects selector control ( ) to the desired effect selection
and press the effects active switch ( ) to the "on" position.
