About The Output Section - Kustom Profile System Two Owner's Manual

The output section (mixer back) is where you connect your speakers, recording equipment, and any other
external sound conditioning device.
Left Preamp Output ( )
This jack can be used to connect the left output to an external audio device such as a power amp.
This output is line level.
Right Preamp Output ( )
This jack can be used to connect the right output to an external audio device such as a power amp.
This output is line level.
Left Power Amp Input ( )
This jack can be used to connect an external line level audio device directly to the left power amp.
Note: When this jack is used, the signal from the mixer will no longer be going to the left power amp.
The Left Preamp Output ( ) and this jack can be used together to place a sound conditioning
device, such as an equalizer, directly in line with the left channel of the mixer. The preamp out
should be connected to the input of the device and the output of the device should be connected to
this jack.
Right Power Amp Input ( )
This jack can be used to connect an external line level audio device directly to the right power amp.
Note: When this jack is used, the signal from the mixer will no longer be going to the right power
amp. The Right Preamp Output ( ) and this jack can be used together to place a sound
conditioning device, such as an equalizer, directly in line with the right channel of the mixer. The
preamp out should be connected to the input of the device and the output of the device should be
connected to this jack.
Right Speaker Output ( )
This jack is used to connect the right speaker to the mixer. Note: This should be the speaker that is
on the right side of the mixer front. The right on the Pan Control ( ) will then correspond to the right
speaker.
Power Switch ( )
This switch is used to apply AC power to the mixer.
Monitor Output ( )
This jack is used to connect an external power amp or powered monitor to the mixer. The overall
output of this jack is controlled by the Monitor Volume Control ( ).
Sub Output ( )
This jack is used to connect a powered sub woofer to the mixer. When using this jack the Sub
Volume Control ( ) will adjust the level of output to the sub woofer.
RCA Record Out Jacks ( )
These output jacks are used to send a line level signal to any audio device that uses the RCA type
plugs for an input. These can be used to record directly from the mixer.
Left Speaker Output ( )
This jack is used to connect the left speaker to the mixer. Note: This should be the speaker that is
on the left side of the mixer front. The left on the Pan Control ( ) will then correspond to the left
speaker.
AC Input Jack ( )
This jack is used to connect AC power to the Profile System Two.

About the Output Section

14
