User Manual v 1.0
November 2013
ENGLISH
TRIUMPH BOARD PROJECTOR SERIES:
TRIUMPH BOARD PJ 2000 UST DLP
TRIUMPH BOARD PJ 2000i UST DLP
TRIUMPH BOARD PJ 3000 UST-W DLP
TRIUMPH BOARD PJ 3000i UST-W DLP
TRIUMPH BOARD a.s. , Neklanova 122/15, 128 00 Prague 2, Czech Republic, European Union,
www.triumphboard.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for TRIUMPH BOARD 2000

Summary of Contents for TRIUMPH BOARD 2000

  • Page 1 TRIUMPH BOARD PROJECTOR SERIES: TRIUMPH BOARD PJ 2000 UST DLP TRIUMPH BOARD PJ 2000i UST DLP TRIUMPH BOARD PJ 3000 UST-W DLP TRIUMPH BOARD PJ 3000i UST-W DLP TRIUMPH BOARD a.s. , Neklanova 122/15, 128 00 Prague 2, Czech Republic, European Union, www.triumphboard.com...

  • Page 2: Table Of Contents

    Table of Contents Safety ................2 Product specification ............6 Product description ............8 Installation ..............13 Settings ..............19 Troubleshooting ............44 Compatibility Modes ...........49 Replacing the lamp .............53 Replacing and cleaning the optional dust filter ...54...

  • Page 3: Safety

    Safety Safety Information Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt and damage your eyes. ▀■ Warning- To avoid the risk of fire or electric shock, do not ex- pose this projector to rain or moisture.
  • Page 4 Safety  Turn off and unplug the power plug from the AC outlet before cleaning the product.  Use a soft dry cloth with mild detergent to clean the display housing.  Disconnect the power plug from AC outlet if the product is not being used for a long period of time.

  • Page 5: Fcc Notice

    Safety Regulation & Safety Notices General notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Operation Conditions

    Safety Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 7: Product Specification

    Product Specifications Specifications Model PJ3000/PJ3000i PJ2000/ PJ2000i ® Projection system Resolution WXGA (1280x800) (1024x768) Computer compatibility IBM PC and compatibles, Apple Macintosh, iMac and VESA standards: SXGA, XGA, SVGA, VGA, WXGA, UXGA Video compatibility NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/ K/K1/L), HDTV (720p, 1080i, 1080p), SDTV (480i, 480p, 576i, 576p) Aspect ratio...
  • Page 8 Product Specifications I/O connectors Power socket x 1   RS232 x 1  Laser Curtain x 1  HDMI x 1 VGA input x 2  VGA output x 1  S-Video x 1  Composite x 1  ...

  • Page 9: Product Description

    Product Description Contents Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your supplier. CR2025 Optional Projector Remote Control Battery AC Power Cord x 3 VGA Cable Documentation: User’s Manual (CD)
  • Page 10 Product Description Product Overview (Front View) (Rear View) (Bottom View) 1. Focus Ring 6. Input / Output Connection Ports 2. Lens 7. Power Socket 3. IR Receiver 8. Elevator Feet 4. Control Panel 9. Elevator Feet 5. Lamp Cover 10. Elevator Feet Spacer...
  • Page 11 Product Description Control Panel POWER TEMP LAMP RESYNC SOURCE MENU 1. Power LED 2. Power 3. Menu / Exit 4. Lamp LED 5. Temp (Temperature) LED 6. Source 7. Resync 8. Four Directional Select Keys 9. IR Receiver...
  • Page 12 Product Description Input / Output Connections 1. Mini USB Connector 2. HDMI Connector 3. VGA Output Connector 4. LAN Connector 5. Audio In 1 Connector (For VGA In 1 Connector) 6. S-Video Connector 7. Left/Right RCA Audio Input Connector (For S-Video Connector) 8.

  • Page 13: Installation

    Product Description Remote Control 1. Source 2. ReSync 3. HDMI 4. Video 5. Menu 6. Enter 7. Four Directional Select Keys 8. Freeze 9. Blank 10. Aspect 11. Power 12. PC 13. Exit 14. Volume +/-  Before using the remote con- trol for the first time, remove the transpar-...
  • Page 14 Installation Installation Connecting to Computer/Notebook Notebook Monitor DC Out 12V RJ-45 Audio Output Power socket Computer 1. Power Cord 5. RS232 Cable * 2. Audio Cable * 6. HDMI Cable *  * Optional accessory 3. VGA to DVI-A Cable * 7.

  • Page 15: Connecting To Video Sources

    Installation Connecting to Video Sources DVD player, Set-top box, HDTV receiver Video output DC Out 12V Audio Output S-Video output DVD player, Set-top box, HDTV receiver Power socket 5. Audio Cable * 1. Power Cord 6. VGA to HDTV (RCA) Cable * 2.
  • Page 16 Installation Powering on/off the Projector Power On 1. Securely connect the power cord and signal cable. When con- nected, the Power LED will turn red. 2. Turn on the lamp by pressing “ ” button on the control panel or on the remote control.

  • Page 17: Power Off

    Installation Power Off 1. Press the “ ” button on the control panel or on the remote control to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm. Power Off? Press power key again.
  • Page 18 Installation Projected Image Setting Height Setting The projector is equipped with elevator feet for adjusting the image height. To raise the image:  Use screw in feet to raise the image to the desired height angle and fine-tune the display angle.  To lower the image: ...

  • Page 19: Adjusting Projection Image Size

    Installation Focus Setting To focus the image, rotate the focus ring until the image is clear. Focus Ring Adjusting Projection Image Size Refer to the graphics and table show as below to determine the screen size and projection distance. Adjusting the vertical image position ...

  • Page 20: Control Panel

    Settings Settings Control Panel POWER TEMP LAMP RESYNC SOURCE MENU Description Name Turn the projector on/off. Power Power LED Indicate the projector’s status. Menu / Exit Launch the on-screen display (OSD) / Exit a menu. Automatically synchronize the PC analog timing to its optimized ReSync condition.

  • Page 21: Settings

    Settings Using the Remote Control To ensure safe operation, please observe the following precautions :  Use CR2025 type bat- tery.  Avoid contact with water or liquid.  Do not expose the remote control to moisture or heat.  Do not drop the remote control.
  • Page 22 Settings Using the Remote Control Description Name Source Select an input signal. Automatically synchronize the PC analog timing to its opti- ReSync mized condition. HDMI Switch to HDMI source. Video Switch to Composite Video or S-Video source. Menu Launch or Exit the on-screen display(OSD) Enter Four Directional Press ▲▼◄►...

  • Page 23: How To Operate

    Settings On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate 1. To open the OSD menu, press the “Menu” button on the remote control or on the control panel.
  • Page 24 Settings Structure Main Menu Sub Menu Settings Picture Color Mode Bright / PC / Movie / Game / User Wall Color White / Light Yellow / Light Blue / Pink / Dark Green Brightness 0~100 Contrast 0~100 Sharpness 0~31 Saturation 0~100 0~100 Gamma...
  • Page 25 Settings Main Menu Sub Menu Settings Auto / Off / On 3D Invert Off / On 3D Format Frame Packing / Side-by-Side(Half) / Top and Bottom / Frame Sequential / Field Sequential 1080p @ 24 96Hz / 144Hz Interactive Interactive Settings Off / On LAN Settings DHCP...
  • Page 26 Settings Picture Color Mode There are many factory presets optimized for various types of images. Use the ◄ or ► button to select the item. Bright: For brightness optimization. PC: For meeting presentation. Movie: For playing video content. Game: For game content. User: Memorize user’s settings.
  • Page 27 Settings Sharpness Adjust the sharpness of the image. Press the ◄ button to decrease the sharpness. Press the ► button to increase the sharpness. Saturation Adjust a video image from black and white to fully saturated color. Press the ◄ button to decrease the amount of saturation in the image.
  • Page 28 Settings Screen Aspect Ratio Auto: Keep the image with original width-height ratio and maximize the image to fit native horizontal or vertical pixels. 4:3: The image will be scaled to fit the screen and displayed using a 4:3 ratio. 16:9: The image will be scaled to fit the width of the screen and the height adjusted to display the image using a 16:9 ratio.
  • Page 29 Settings Digital Zoom Press the ◄ button to reduce the size of an image. Press the ► button to magnify an image on the projection screen. Ceiling Mount Front: The image is projected straight on the screen. Front Ceiling: This is the default selection. When selected, the image will turn upside down.
  • Page 30 Settings Setting Language Choose the multilingual OSD menu. Press the ◄ or ► button into the sub menu and then use the ▲ or ▼ button to select your preferred language. Press ► on the remote control to finalize the selection. Menu Location Choose the menu location on the display screen.
  • Page 31 Settings VGA OUT (Standby) Choose “On” to enable VGA OUT connection. Test Pattern Display a test pattern. Reset Choose “Yes” to return the parameters on all menus to the factory default settings.
  • Page 32 Settings Volume Mute Choose “On” to turn mute on. Choose “Off” to turn mute off. Volume Press the ◄ button to decrease the volume. Press the ► button to increase the volume. Microphone Volume Press the ◄ button to decrease the microphone Volume. Press the ►...

  • Page 33: Logo Capture

    Settings Options Logo Use this function to set the desired startup screen. If changes are made they will take effect the next time the projector is powered on. Default: The default startup screen. User: Use stored picture from “Logo Capture” function. Logo Capture Press ►...

  • Page 34: Lamp Setting

    Settings Input HDMI VGA-1 VGA-2 S-Video Composite Select Enter Exit Auto Power Off (min) Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the projector. The projector will automatically power off when the countdown has finished (in minutes).
  • Page 35 Settings Options | Lamp Settings Lamp Settings Lamp hours used (Normal) Lamp hours used (ECO) Lamp life reminder Lamp Power Mode Normal Clear lamp hours Select Enter Exit Lamp Hours Used (Normal) Display the projection time of normal mode. Lamp Hours Used (ECO) Display the projection time of ECO mode.
  • Page 36 Settings Auto: When a HDMI1.4a 3D timing identification signal is detected, the 3D image is selected automatically. Choose “Off” to disable 3D function. Choose “On” to enable 3D function. 3D Invert If you see a discrete or overlapping image while wearing DLP 3D glasses, you may need to execute “Invert”...
  • Page 37 Settings Interactive Interactive Settings Use this feature to enable the Interactive function. Options are: “Off” and “On”.  The Interactive function is available You need to unplug the Mini USB cable that connects notebook/ when displaying graphic source from desktop with the projector before using the Interactive function. After HDMI/VGA input.
  • Page 38 Settings LAN Settings DHCP: If a DHCP server exists in the network to which the projector is connected, the IP address will automatically be acquired when you select DHCP On. If DHCP is Off, manually set the IP Address, Subnet Mask, and Gateway. Use ▲ or ▼ to select the number of IP address, Subnet Mask, and Gateway.

  • Page 39: Web Management

    Settings Web Management 1. Turn on DHCP to allow a DHCP server to automatically assign an IP, or manually enter the required network information. 2. Open your web browser and type in IP Address from the OSD LAN. 3. Based on network web-page for the input-string in [tools] tab, the limitation for Input-Length is in the below list (“space”...
  • Page 40 Settings When making a direct connection from your computer to the projector Step 1: Find an IP Address (192.168.10.100) from LAN function of projector. Step 2: To open Network Connections, click Start, click Control Panel, click Network and Internet Connections, and then click Network Connections.
  • Page 41 Settings Projector Information Page Projector Information page by entering the projector’s IP address at the web browser. See “LAN Settings” section. Language: Allows you to set the language for web management. LAN Settings Page Set up the Projector Name, Location and Administrator information (up to 21 characters for each field).
  • Page 42 Settings Projector Status and Control Page Projector Status: There are 4 status: Standby, Warning up, Lamp On, Power Saving and Cooling. Click the Refresh button to refresh the status and control settings. Auto Power Off: Auto Power Off can be set to Off(0) or 1~120 minutes.
  • Page 43 Settings E-mail Setting Page E-mail Alert: You can set whether to be notified by email (Enable) or not (Disable).  Click the Save button To/Cc/From: You can enter email address of sender (From) and to the save settings. recipients (To/Cc) to receive notification when an abnormality or warning occurs.
  • Page 44 Settings Login Page Administrator Password: Enter the Administrator Password and click Login button. Crestron For more information, please visit http://www.crestron.com & www.crestron.com/getroomview/...

  • Page 45: Troubleshooting

    Troubleshooting Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please con- tact your local reseller or service center. Image Problems No image appears on-screen ` Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”...
  • Page 46 Troubleshooting If the projector is still not projecting the whole image, you will also need to change the monitor display you are using. Refer to the following steps. 1. Select the “Change” under the “Monitor” tab. 2. Click on “Show all devices”. Next, select “Standard monitor types”...
  • Page 47 Troubleshooting Image has vertical flickering bar ` Use “Clock” to make an adjustment. Refer to the “Screen” section for more information. ` Check and reconfigure the display mode of your graphic card to make it compatible with the product. Image is out of focus ` Adjust the “Focus Ring”...

  • Page 48: Projector Problems

    Troubleshooting Projector Problems The projector stops responding to all controls ` If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Lamp burns out or makes a popping sound ` When the lamp reaches its end of life, it will burn out and may make a loud popping sound.

  • Page 49: On Screen Messages

    Troubleshooting Two images, Side-by-Side(Half) format ` Select “3D” --> “3D Format” from OSD and choose “Side-by- Side(Half)” for input signal is HDMI 1.4a 3D. 3D Format is only supported on 3D Timing on page 42. Image does not display in 3D ` Check if the battery of 3D glasses is drained.

  • Page 50: Compatibility Modes

    Compatibility Modes Compatibility Modes  VGA Analog PC signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 640x480 31.5 640x480 35.0 640x480 37.9 640x480 37.5 640x480 43.3 640x480 61.9 720x400 31.5 800x600 35.1 800x600 37.9 800x600 48.1 SVGA 800x600 46.9 800x600 53.7 800x600...
  • Page 51 Compatibility Modes Extended wide timing V. Frequency H. Frequency Modes Resolution [Hz] [Hz] 1280x720 44.8 1280x800 49.6 WXGA 1366x768 47.7 1440x900 59.9 WSXGA+ 1680x1050 65.3 Component signal V. Frequency H. Frequency Modes Resolution [Hz] [Hz] 480i 720x480(1440x480) 59.94(29.97) 15.7 576i 720x576(1440x576) 50(25) 15.6...
  • Page 52 Compatibility Modes HDMI Digital PC signal V. Frequency H. Frequency Modes Resolution [Hz] [Hz] 640x480 31.5 640x480 35.0 640x480 37.9 640x480 37.5 640x480 43.3 640x480 61.9 720x400 31.5 800x600 35.1 800x600 37.9 800x600 48.1 SVGA 800x600 46.9 800x600 53.7 800x600 77.4 Apple, MAC II 832x624...
  • Page 53 Compatibility Modes Extended wide timing Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 1280x720 44.8 1280x800 49.6 WXGA 1366x768 47.7 1440x900 59.9 WSXGA+ 1680x1050 65.3 Video signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 480p 640x480 59.94/60 31.5 480i 720x480(1440x480) 59.94(29.97) 15.7...

  • Page 54: Replacing The Lamp

    Replacing the lamp Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, you will receive a warning message. Warning! Lamp Lamp is approaching the end of its useful life Replacement suggested! When you see this message, please contact your local reseller or service center to change the lamp as soon as possible.

  • Page 55: Replacing And Cleaning The Optional Dust Filter

    Replacing and Cleaning Optional Dust Filter Replacing and cleaning the optional dust filter We recommend cleaning the dust filter after every 500 hours of use, clean it more often if the projector is used in a dusty environment. Warning! Dust Filters The usage time of the dust filter is reached.
  • Page 56 Notes...
  • Page 57 TRIUMPH BOARD a. s. , Neklanova 122/15, 128 00 Prague 2, Czech Republic, European Union, www.triumphboard.com © TRIUMPH BOARD 2013...
