Bluetooth interface for select 2006-up acura/honda vehicles

Advertisement

Quick Links

HANDS-FREE BLUETOOTH INTERFACE FOR
SELECT 2006-UP ACURA/HONDA VEHICLES
ACURA
2006-09 MDX
2006-09 RDX
2006-09 RL
2006-08 TSX
2006-08 TL
HONDA
2006-09 ACCORD
2006-09 CIVIC
2006-09 CRV
2006-09 ELEMENT
2006-09 FIT
2006-09 ODYSSEY
2006-09 PILOT
2006-09 RIDGELINE
2006-09 S2000

QUICK START

INSTALL

Using the BFHAHB harness, install the BFHA interface into your vehicle.
Contact Scosche Tech Support for your specific vehicle disassembly.

POWER THE MODULE

With the unit installed, turn the ignition key to the on position to place the
Bluefusion module into pairing mode. Press your radios designated XM
button to enter the XM (Bluefusion) source. From the XM source press the
preset number 6 button, the screen displays "Bluefusion" when ready.

PAIR YOUR CELLULAR PHONE

Set your cellular phone into pairing mode and search for a new Bluetooth
device (See your phone's owners manual for instructions). Once your
cellular phone has searched for a new device, select "BLUEFUSION" from
the list of devices found. If prompted for a pass code enter "0000".
4

NAVIGATE AND ENJOY

Once the two devices have connected and paired, you will be able to scroll
through the menu functions of the BFHA. (See page 2-4 for Bluefusion
operation).
©2009 SCOSCHE INDUSTRIES, INC.
APPLICATION GUIDE
BFHA
SI 06/09 BFHA (3000000)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BFHA and is the answer not in the manual?

Questions and answers

Summary of Contents for Scosche BFHA

  • Page 1: Quick Start

    If prompted for a pass code enter “0000”. NAVIGATE AND ENJOY Once the two devices have connected and paired, you will be able to scroll through the menu functions of the BFHA. (See page 2-4 for Bluefusion operation). ©2009 SCOSCHE INDUSTRIES, INC.
  • Page 2 INSTALLATION OVERVIEW 3-PIN RADIO MICROPHONE HARNESS HARNESS 24-Pin PAIRING YOUR MOBILE PHONE 1. Turn the key to the on position (II) to place Bluefusion into pairing mode. 2. Press the appropriate button to get to your XM source, then press and hold the preset number 6 to enter Bluefusion, screen displays “BLUEFUSION”.
  • Page 3 RADIO OPERATION RADIO CONTROLS MAY VARY. There are different buttons used for each of the individual radios. Please read and understand this entire manual before operating the interface. P = PRESET NUMBER THIS CHART IS TO BE USED FOR P FUNCTION ALL RADIO STYLES BELOW.
  • Page 4: Limited Warranty

    LIMITED WARRANTY Scosche Industries Inc. warrants this product to be free from defects in material and workmanship for a period of 90 days from purchase. This Scosche product is sold with the understanding that the purchaser has independently determined the suitability of this product.
