Senlan SB40S0.75-1.5 Instruction Manual

Senlan sb40 series general purpose inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

SENLAN INVERTER

INSTRUCTION MANUAL

SB40 Series
General-purpose Inverter
Chengdu Hope SenLan Inverter Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for Senlan SB40S0.75-1.5

Summary of Contents for Senlan SB40S0.75-1.5

  • Page 1: Instruction Manual

    SENLAN INVERTER INSTRUCTION MANUAL SB40 Series General-purpose Inverter Chengdu Hope SenLan Inverter Co., Ltd.

  • Page 2: Table Of Contents

    Contents 1 General................. 1 1.1 Check upon delivery ............1 1.2 Type description..............1 1.3 Nameplate ................. 2 1.4 Warranty................2 1.5 Precautions................ 3 2 Installation and Wiring ............7 2.1 Installation ................ 7 2.2 Wiring of inverter ............10 2.3 Wiring diagram ...............
  • Page 3 5 Function Table..............26 6 Function Details ..............34 7 Maintenance & Troubleshooting ........61 7.1 Daily inspection and maintenance ........62 7.2 Periodical maintenance ........... 62 7.3 Replacement of parts ............63 7.4 Anti-interference measures ..........64 7.5 Troubleshooting .............. 65 8 Peripheral Devices ............

  • Page 4: General

    SENLAN SB40 GENERAL 1 General 1.1 Check upon delivery Check the following items after unpacking the inverter. If the inverter has got any damages during the shipment. If the inverter is exactly what you have ordered. If all necessary accessories have been shipped along with the inverter.

  • Page 5: Nameplate

    · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · CHENGDU HOPE SENLAN INVERTER CO., LTD.

  • Page 6: Precautions

    SENLAN SB40 GENERAL 1.5 Precautions Read the following items before installing, wiring, operating and maintaining the product, and always bear them in your mind. Precautions in this manual fall into two types： Danger indicates that errors in operation may lead to death or heavy injury to people or may destroy the inverter.
  • Page 7 SENLAN SB40 GENERAL Caution ‧ Install the inverter firmly on an object capable of bearing its weight. Otherwise, the falling of the inverter may cause injury or damage. ‧ Do not drop metallic material in the inverter. That may lead to accident.
  • Page 8 SENLAN SB40 GENERAL 1.5.3 Operation Danger ‧ Switch on the inverter power only after the wiring is completed and the cover board is attached. Otherwise, electric shock may occur. ‧ Do not touch inverter terminals when electrical power is going to the inverter even if the motor is stopped.
  • Page 9 SENLAN SB40 GENERAL 1.5.4 Maintenance Danger ‧ 10 minutes after power-off, measure the DC voltage between P and N terminals with a multimeter. Only when this voltage drops below 36V, can the inverter be inspected and repaired. Otherwise, electric shock or injury may occur.

  • Page 10: Installation And Wiring

    SENLAN SB40 INSTALLATION AND WIRING 2 Installation and Wiring 2.1 Installation 2.1.1 Ambient temperature -10℃~40℃, with humidity lower than 90%. If temperature>40℃, the inverter must be derated by 5% for every addition of 1℃. At an altitude above 1000m, the inverter must be derated by 3% for every addition of 500m.
  • Page 11 SENLAN SB40 INSTALLATION AND WIRING 120mm or more Inverter 50mm 50mm or more or more 120mm or more When two or more inverters are installed in one cabinet, horizontal arrangement is recommended to minimize the mutual thermal influence. If vertical arrangement is necessary, a separating board should be provided between them to prevent the heat of the lower inverter affecting the upper one.
  • Page 12 SENLAN SB40 INSTALLATION AND WIRING Multi-inverter installation methods are shown as the following diagrams. Outlet and cooling fan Outlet and cooling fan Inverter Inverter Inverter Separating board Inverter Inlet Air inlet (a) Horizontal arrangement (b) Vertical arrangement For the outflow and the surface(up & down) area of each SB40 type, refer to the following table.

  • Page 13: Wiring Of Inverter

    SENLAN SB40 INSTALLATION AND WIRING 2.2 Wiring of inverter 2.2.1 Main circuit terminals 0.75～7.5KW: PE R S T P DB U V W 11~15KW: PE R S T P1 P+ DB U V W 18.5~22KW: PE P+ P1 N R S T U V W...
  • Page 14 SENLAN SB40 INSTALLATION AND WIRING Description of main circuit terminals Symbol Function Power supply terminals. For connecting 3-phase 380V R, S, T power. U, V, W Inverter output terminals. For connecting a 3-phase motor. P1, P+ Connect a DC reactor P1, DB Connect an external braking resistor(0.75 ~ 7.5KW)
  • Page 15 SENLAN SB40 INSTALLATION AND WIRING of the inverter. ③ When the wiring length between the inverter and the motor are long, the large inter-wire capacitance may result in abnormal operation or even overcurrent trip. In this case, connect a filter or a magnetic ring(s) to the output side of the inverter and moderately decrease the carrier frequency.

  • Page 16: Control Circuit Terminals

    SENLAN SB40 INSTALLATION AND WIRING External braking resistor terminals [P1, DB]/[P+, DB] ① These terminals are used to connect an external braking resistor(option). See chapter 9 for specifications of the braking resistor. ② When connecting the external braking resistor, use a twist pair with its length less that 5 meters.
  • Page 17 SENLAN SB40 INSTALLATION AND WIRING Description of control circuit terminals Relay output terminals [30A, 30B, 30C] These programmable output terminals, withstand 220VAC/1A. Multi-function output terminals [Y1, Y2, Y3] These are open collector output terminals, can withstand 24VDC /50mA. Multi-function input terminals [X1 ~ X5] Refer to F69, Chapter 6.
  • Page 18 SENLAN SB40 INSTALLATION AND WIRING run forward. But if the operation is controlled by the keypad panel, FWD is just for reverting the inverter direction, that is, if short FWD and CM, inverter will run reverse, otherwise forward. REV: it is valid when F02=1 or 2. Short REV and CM, inverter will run reverse;...
  • Page 19 Separate the control circuit wires from the main circuit wires, power supply cables and other power lines, and run them across instead of in parallel. 2.2.3 Wiring specifications Main circuit wiring Control circuit wiring Inverter type (mm²) (mm²) SB40S0.75-1.5 ≥0.5 SB40S2.2-3.7 ≥0.5 SB40S5.5-7.5 ≥0.5 SB40S11-15 ≥0.5 SB40S18.5-22...

  • Page 20: Wiring Diagram

    SENLAN SB40 INSTALLATION AND WIRING 2.3 Wiring diagram The wiring of the inverter consists of the main circuit wiring and the control circuit wiring. External terminals can be used as required. DC reactor MCCB 3-phase 380V Relay output Analog input...

  • Page 21: Use Of Keypad Panel

    SENLAN SB40 USE OF KEYPAD PANEL 3 Use of Keypad Panel 3.1 Appearance of keypad panel LED Display frequency, output frequency/current/voltage, display Unit synchrous/line speed, load rate, fnction code/data, fault code Potentiometer Up & Down keys Program lamp lamp Program key...

  • Page 22: Fault Code Display

    SENLAN SB40 USE OF KEYPAD PANEL 3.3 Fault code display Fault code Description Fault code Description No fault Communication error corr Err1 Module failure Illegal operation Err4 Undervoltage Err5 Store failed Overvoltage Overheating External alarm Overload Overload pre-alarm 3.4 Frequency setting mode There are four frequency setting modes for SB40 Inverter: F01=0: set by F00 or ∧/∨...

  • Page 23: Keypad Panel Operation

    SENLAN SB40 USE OF KEYPAD PANEL 3.5.2 Running status LED monitor displays corresponding running parameter, run lamp is 3.5.3 Fault status When the inverter is in stop state, if there is any fault, the LED monitor will display corresponding fault code(see 3.3). After the fault is eliminated, press STOP/RESET key to reset the inverter.
  • Page 24 SENLAN SB40 USE OF KEYPAD PANEL 3.6.2 Changing parameters (change F09 to 10S) If overtime, return to original display (Display) 20.0 20.0 10.0 50.00 Press FUNC key Press Press ∧ / ∨ Press Press Press ∧ / ∨ saving changed...

  • Page 25: Specifications

    SENLAN SB40 SPECIFICATIONS 4 Specifications 4.1 Standard specifications 400V series 0.75 Type 18.5 0.75 Motor capacity 18.5 (KW) Rated capacity (KVA) Rated current Overload 150% 1 minute Voltage(V) 3-phase 0～380V Power 3-phase 380V, 50/60Hz Allowable Voltage: ＋10～－15%（temporary ±15%） fluctuation Frequency: ±2% Braking 0.75～15KW：braking resistor...

  • Page 26: Common Specifications

    SENLAN SB40 SPECIFICATIONS 4.2 Common specifications Item Specification V/F characteristics V/F curve control 0～50 Torque boost Accel/decel time 0.1～3600S，4 accel/decel time Pattern operation 7 multistep frequencies，4 pattern operation modes Upper-limit frequency, lower-limit frequency, jump frequency, Auxiliary function current limiting, bias frequency, frequency gain, stall control, auto-reset, S-curve accel/decel, jog run, AVR, auto energy-saving 50～400Hz...

  • Page 27: External Dimensions

    SENLAN SB40 SPECIFICATIONS 4.3 External dimensions 4.3.1 Outline drawing - 24 -...
  • Page 28 SENLAN SB40 SPECIFICATIONS 4.3.2 Mounting size 0.75~3.7KW 5.5~7.5KW 11~15KW 18.5~30KW 37~45KW 55KW 75KW 90~110KW 132KW 160~220KW 1000 280KW 1100 1075 1030 - 25 -...

  • Page 29: Function Table

    SENLAN SB40 FUNCTION TABLE 5 Function Table Code Name Setting range Change Default Frequency setting 0.10～400.0Hz 50.00 △ 0：Set by F00 or ∧/∨ keys 1：Set by panel potentiometer 2：Set by VRF terminal(0~5V or 0~10V) 3：Set by IRF terminal(DC4~20mA) Frequency setting 4：Set by F00(or ∧/∨) keys and X4, X5...
  • Page 30 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default Accel time 2 0.1～3600S 20.0 △ Decel time 2 0.1～3600S 20.0 △ Accel time 3 0.1～3600S 20.0 △ Decel time 3 0.1～3600S △ 20.0 Accel time 4 0.1～3600S 20.0 △...
  • Page 31 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default 0：Positive bias Bias polarity △ 1：Negative bias Starting frequency 0.10～50.00Hz △ 1.00 Starting frequency 0.0～20.0S △ duration Slip compensation 0.00 ~ 10.00Hz △ 0.00 braking 0.00 ~ 60.00Hz △ 5.00...
  • Page 32 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default Multi-step 0.10 ~ 400.0Hz 20.00 △ frequency 3 Multi-step 0.10 ~ 400.0Hz △ 30.00 frequency 4 Multi-step 0.10 ~ 400.0Hz △ 40.00 frequency 5 Multi-step 0.10 ~ 400.0Hz 50.00 △...
  • Page 33 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default Operation time 3 0.0 ~ 3600S △ Direction Same as F53 △ accel/decel 3 Operation time 4 0.0 ~ 3600S △ Direction Same as F53 △ accel/decel 4 Operation time 5 0.0 ~ 3600S...
  • Page 34 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default 0：Running 1：Stopping 2：Frequency reach 3：Random frequency reach 4：Overload pre-alarm Y1 output function ▲ 5：External alarm Y2 output function ▲ 6：Keypad panel operation Y3 output function ▲ 7：Undervoltage stopping 8：Pattern operation running 9：Pattern operation finished...
  • Page 35 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default Auto-reset interval 1.0 ~ 20.0S ▲ Auto 0：Disabled ▲ energy-saving run 1：Enabled Overvoltage stall 0：Invalid ▲ control 1：Valid 0：Invalid Overcurrent stall 1：Valid for acceleration ▲ control 2：Valid for constant-speed operation 3：Valid...
  • Page 36 SENLAN SB40 FUNCTION TABLE Code Name Setting range Change Default 2：Frequency reach 3：Random frequency reach 4：Overload pre-alarm 5：External alarm 6：Keypad panel control 7：Undervoltage stopping 8：Pattern operation running 9：Pattern operation finished 10：Pattern operation paused 11：Stage operation finished 12：Fault alarm 0：Disabled Error control △...

  • Page 37: Function Details

    SENLAN SB40 FUNCTION DETAILS 6 Function Details Default: 50.00 Frequency setting Setting range 0.10～400.0Hz Min. unit: 0.01 ● This function sets the inverter output frequency, which is restricted by the maximum, upper- & lower-limit, starting, DC braking starting and jumping frequencies.
  • Page 38 SENLAN SB40 FUNCTION DETAILS 0~5V or 0~10V depending on the SW2(a switch on the VRF) position. 3：Frequency is set by the IRF terminal. 4：F00 frequency is used as the set frequency. It can be changed by F00 (or ∧ / ∨ keys) or by X4(Down) & X5(Up) terminals. After power-off, the changed frequency is automatically stored.

  • Page 39: Maximum Frequency

    SENLAN SB40 FUNCTION DETAILS Set frequency Set frequency Motor slows down to a stop according to decel time Motor coasts to a stop Motor speed Motor speed (F9/F11/F13/F15) Time Decel time Decel time Time Run command Slowdown stop Coasting stop Fig.6-1...
  • Page 40 SENLAN SB40 FUNCTION DETAILS 0: Auto boost. The inverter automatically adjusts the output torque to the optimum value according to the load condition. 1~50: Manual boost. Voltage Frequency Fig.6-2 Accel time 1 Default: 20.0 Decel time 1 Default: 20.0 Accel time 2 Default: 20.0...
  • Page 41 SENLAN SB40 FUNCTION DETAILS ● These functions set the motor overload protection mode and the overload protection level. F16=0 All inactive Motor overload protection inactive, overload F16=1 pre-alarm active F16=2 All active F17=(motor rated current×100)/inverter rated current F16=0：Both motor overload protection and overload pre-alarm are inactive when the inverter output current reaches F17×Ie(inverter...
  • Page 42 SENLAN SB40 FUNCTION DETAILS Default: 5.00 Jog frequency Setting range 0.10～400.0Hz Min. unit: 0.01 Default: Jog accel/decel time Setting range 0.1～600S Min. unit: 0.1 ● These functions frequency acceleration/deceleration time. Short JOG & CM and then short FWD/REV & CM, the inverter will accelerate from the starting frequency to the jog frequency;...
  • Page 43 SENLAN SB40 FUNCTION DETAILS Jump frequency 1 Default: 0.00 Jump frequency 2 Default: 0.00 Jump frequency 3 Default: 0.00 Setting range 0.00～400.0Hz Min. unit: 0.01 Jumping width Default: 0.50 Setting range 0.00～10.00Hz Min. unit: 0.01 ● Jump frequency is the frequency at which the inverter is prohibited to run.
  • Page 44 SENLAN SB40 FUNCTION DETAILS Output frequency 200% 100% 5V(10V) Analog setting 20mA Fig.6-6 Bias frequency Default: 0.00 Setting range 0.00～400.0Hz Min. unit: 0.01 Bias polarity Default: Setting range 0 ~ 1 ● Bias frequency is the output frequency when the analog setting(from VRF or IRF terminal) is equal to zero.
  • Page 45 SENLAN SB40 FUNCTION DETAILS Starting frequency Default: 1.00 Setting range 0.10～50.00Hz Min.unit: 0.01 Starting frequency duration Default: Setting range 0.0～20.0S Min.unit: 0.1 ● These functions set the starting frequency and its duration. This duration is not included in the acceleration time.
  • Page 46 SENLAN SB40 FUNCTION DETAILS DC braking amount Default: Setting range 0～100 Min. unit: 1 ● This function adjusts the DC braking torque. When setting this parameter, please increase it gradually until the adequate braking torque is obtained. DC braking time...
  • Page 47 SENLAN SB40 FUNCTION DETAILS interference of external noise with the analog setting signals. Operation time multiplier Default: Setting range 0～1 Min. unit: 0.01 ● This function sets the multiplier for the pattern operation time. F38=0 ×10 F38=1 ×1 0: Actual operation time = operation time × 10 1: Actual operation time = operation time ×...
  • Page 48 SENLAN SB40 FUNCTION DETAILS should be set so that the synchronous speed of the motor will be displayed properly. Multistep frequency 1 Default：5.00 Multistep frequency 2 Default：10.00 Multistep frequency 3 Default：20.00 Multistep frequency 4 Default：30.00 Default：40.00 Multistep frequency 5 Multistep frequency 6 Default：50.00...
  • Page 49 SENLAN SB40 FUNCTION DETAILS 0：Pattern operation mode is disabled. 1：After a cycle of pattern operation(i.e. from multistep frequency 1 to 7), inverter stops. 2：After a cycle of pattern operation, inverter runs at the final frequency, i.e. the multistep frequency 7.
  • Page 50 SENLAN SB40 FUNCTION DETAILS Operation time 1 Default： 1.0 Default： 1.0 Operation time 2 Default： 2.0 Operation time 3 Default： 2.0 Operation time 4 Default： 3.0 Operation time 5 Default： 3.0 Operation time 6 Default： 4.0 Operation time 7 Setting range 0.0～3600S...
  • Page 51 SENLAN SB40 FUNCTION DETAILS Forward, accel/decel time 1 Forward, accel/decel time 2 Forward, accel/decel time 3 Forward, accel/decel time 4 Reverse, accel/decel time 1 Reverse, accel/decel time 2 Reverse, accel/decel time 3 Reverse, accel/decel time 4 Default: Data protection Setting range 0～1...
  • Page 52 SENLAN SB40 FUNCTION DETAILS ● This function sets the run direction of the inverter. F68=0 Both forward and reverse valid F68=1 Only forward valid F68=2 Only reverse valid F68=1, inverter runs forward even if the reverse command is input. F68=2, inverter runs reverse even if the forward command is input.
  • Page 53 SENLAN SB40 FUNCTION DETAILS Frequency Pattern operation Pattern operation stops Pattern operation is running Runs at the priority frequency(F00) Pattern operation pauses Default：0 Y1 output Default：1 Y2 output Y3 output Default：2 Setting range 0～11 Relay output default：12 Setting range 0～12 ●...
  • Page 54 SENLAN SB40 FUNCTION DETAILS Running Stopping Frequency reach Detection frequency reach Overload pre-alarm External alarm Keypad panel control Undervoltage stopping Pattern operation running Pattern operation finished Pattern operation pauses Stage operation finished Fault alarm Typical application of Y terminal External supply...
  • Page 55 SENLAN SB40 FUNCTION DETAILS 0：Running When the inverter is running, a signal is output. 1：Stopping When the inverter is in stop state, a signal is output. 2：Frequency reach When the inverter output frequency reaches the set frequency, a signal is output.
  • Page 56 SENLAN SB40 FUNCTION DETAILS signal is output. 11：Stage operation finished When any of the seven stages of the pattern operation is completed, a 0.5-second signal is output. 12：Fault alarm When any fault occurs, the relay normally-open contact is closed. FMA output...
  • Page 57 SENLAN SB40 FUNCTION DETAILS Set frequency O utput frequency Tim e Fig. 6-10 Detection frequency Default: 40.00 Setting range 0.10～400.0Hz Min. unit: 0.01 Default: 1.00 Detection frequency band Setting range 0.00～10.00Hz Min. unit: 0.01 ● When the output frequency reaches the detection frequency, the multi-function output terminal will output a control signal to control the external equipment.
  • Page 58 SENLAN SB40 FUNCTION DETAILS required. The SB40 series inverter uses IGBT as the power device. The carrier frequency can be set between 2 and 9KHz. When higher carrier frequency is adopted, the current waveform is good, the low-frequency torque is large and the noise is low, but increasing the carrier frequency will increase the power consumption of IGBT and lower the inverter efficiency and the motor torque.
  • Page 59 SENLAN SB40 FUNCTION DETAILS This function is not applicable to the load that is frequently changed or that has been near full-load operation. Default: 1 Overvoltage stall control Setting range 0 ~ 1 ● This function set the overvoltage stall control mode.
  • Page 60 SENLAN SB40 FUNCTION DETAILS During inverter acceleration, too fast acceleration or too large load will lead to sharp rise of the inverter output current which may exceed the overcurrent stall level. In this case, the inverter will increase the acceleration time or stop accelerating. And when the current drops to a certain value below the stall level, the inverter reaccelerates.
  • Page 61 SENLAN SB40 FUNCTION DETAILS ● This function sets the accel/decel pattern of the inverter. 0: Linear accel/decel 1~7: S-curve accel/decel Refer to the following figure, where t1 is the accel time and t2 the decel time. F r e q u e n c y...
  • Page 62 SENLAN SB40 FUNCTION DETAILS Data Display in running Display in stopping Output frequency Output current Set frequency Output voltage Synchro speed Set synchro speed Line speed Set line speed Overload rate Set frequency Current display correction Default: 30.0 Setting range 0.1～520.0A...
  • Page 63 SENLAN SB40 FUNCTION DETAILS Default: corr Fault record 1 Default: corr Fault record 2 Default: corr Fault record 3 Default: Fault record clear Setting range 0 ~ 1 ● Functions F90 ～ F92 reserve the last three fault information respectively, but only oH, dbr, oL, ouu and FL can be stored as faults in F90~F92.

  • Page 64: Maintenance & Troubleshooting

    SENLAN SB40 MAINTENANCE & TROUBLESHOOTING 7 Maintenance & Troubleshooting Danger • Only professionally trained person can disassemble and repair the inverter and change the parts. • After repairing the inverter, do not leave any conductor(such as metal) in it. That may damage the inverter.

  • Page 65: Daily Inspection And Maintenance

    SENLAN SB40 MAINTENANCE & TROUBLESHOOTING 7.1 Daily inspection and maintenance In order that the inverter may work reliably for a long period, you must install and operate it strictly in accordance with this manual. And conduct the daily inspection and maintenance as follows: ■...

  • Page 66: Replacement Of Parts

    SENLAN SB40 MAINTENANCE & TROUBLESHOOTING ■ Check to see if the insulation of the main circuit & control circuit terminals meets the requirements. ■ Check the power cables and control cables for damage, aging and discoloration. ■ Remove dirt with cloth immersed with a neutral chemical and remove dust from air vents and printed circuit boards with a vacuum cleaner.

  • Page 67: Anti-Interference Measures

    SENLAN SB40 MAINTENANCE & TROUBLESHOOTING Table 7-1 Parts replacement cycle Part name Standard replacement cycle Cooling fan 3 years DC filter capacitor 5 years Electrolytic capacitor on printed 7 years circuit board Other parts — 7.4 Anti-interference measures 7.4.1 Preventing external noise ■...

  • Page 68: Troubleshooting

    SENLAN SB40 MAINTENANCE & TROUBLESHOOTING through and wrap 3-4 circles on the ring in the same direction. The connecting wires between the inverter and motor, filter & reactor should be as short as possible. 7.5 Troubleshooting When faults occur, diagnose the inverter according to the following table and make a detailed record.
  • Page 69 SENLAN SB40 MAINTENANCE & TROUBLESHOOTING Fault Fault type Possible causes Remedies code Communication Err1 Failure inside inverter Call us error Store failed Failure inside inverter Call us Err5 (1) Input voltage abnormal (1) Check input power (2) Connector, cable or display...

  • Page 70: Peripheral Devices

    SENLAN SB40 PERIPHERAL DEVICES 8 Peripheral Devices 8.1 Connecting diagram of peripheral devices and options Peripheral devices Function and options Shuts inverter to prevent Air switch failure (non-fuse breaker) inverter and circuits leading power failure Shuts off the main power when inverter...

  • Page 71: Description Of Options

    SENLAN SB40 PERIPHERAL DEVICES 8.2 Description of options 8.2.1 AC reactor The input AC reactor can suppress the higher harmonics of the inverter input current and obviously improve the power factor. It is recommended to adopt it in following cases: ①...
  • Page 72 SENLAN SB40 PERIPHERAL DEVICES 8.2.2 Radio noise filter The radio noise filter is used for suppressing the electromagnetic interference generated by the inverter, the external radio interference, and the transient shock & surge interference with the inverter. The radio noise filter should be adopted in following cases: ■...
  • Page 73 SENLAN SB40 PERIPHERAL DEVICES Table 8-2 Braking resistor specifications Capacity Resistance Capacity Resistance (kW) (Ω) (kW) (Ω) 60Ω/2.5 kW 2×20Ω/20 kW 50Ω/4 kW 2×20Ω/20 kW 18.5 40Ω/4 kW 2×13.6Ω/27 kW 30Ω/5 kW 2×13.6Ω/27 kW 24Ω/8 kW 2×20Ω/33 kW 20Ω/8 kW 5×20Ω/40 kW...
  • Page 74 SENLAN SB40 PERIPHERAL DEVICES Braking unit Inverter Braking resistor AC0 AC1 DB P1 P2 N Wiring diagram of SZ10G11/22 braking unit Braking unit Inverter Braking P N DB S R P+ N resistor Wiring diagram of braking unit of over 22kW 8.2.4 DC reactor...
  • Page 75 SENLAN SB40 PERIPHERAL DEVICES Table 8-4 DC reactor specifications Voltage Capacity Current Reactance (kW) (uH) 37～55 75～90 110～132 160～200 8.2.5 Remote operation panel The keypad panel can be removed from SB40 Inverter and used as a remote operation panel by connecting an extended wire. The extended wire can be purchased from us.
  • Page 76 SENLAN SB40 PERIPHERAL DEVICES ■ The current-leak protector should be connected to the input side of the inverter and preferably located behind the air switch(non-fuse breaker) . ■ The action current of the current-leak protector should be ten times the total leakage current(circuit, radio noise filter and motor etc.) of the same circuit when supplied by commercial power with...
  • Page 77 Chengdu Hope SenLan Inverter Co., Ltd. 181 Airport road, Chengdu, China Tel: 86-028-85964751 85962579 Fax: 86-028-85965772 http: //www.chinavvvf.com ·The contents of this manual are subject to change without notice...
