KHS-6640 INSTALLATION MANUAL
SMARTHOME.COM™
1-800-SMART-HOME
949-221-9200
http://www.smarthome.com
Order #8270C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KUSTOM KHS-6640 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kustom KUSTOM KHS-6640

  • Page 1 KHS-6640 INSTALLATION MANUAL SMARTHOME.COM™ 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #8270C...
  • Page 2 K U S T O M A.) Power Switch - Left on, the KHS6640, when not being used, will go into a “sleep” mode, ready to turn back on when an input signal is applied from any of the six sources. In the off position, the unit w ill not function.
  • Page 3 1.) Line Outputs (Left & Right) - these are dual RCA line outputs to go to additional amplifiers or to powered sub-woofers. The white one is for left channel and the red one is for right channel. These outputs will react to the volume controllers for each zone. Any changes made to these will follow through to these outputs.
  • Page 4 this connector allows the “ party” mode to apply to multiple units if additional 7.) Master IR Output - units are added. this is for the “party” mode controller. This controller should be located near 8.) Master IR Input - the unit and sources.
  • Page 5 this q/8” 2 conductor jack is from the 16.) Source Output #I - specific. This is useful in the instance, if you have 2 or more of the same brand CD player, since the same IR command will work on both, this ONLY sends the IR command to this particular source. Nearly any brand of emitter will work.
  • Page 6 Master In/Out: The master controller input will accept a seventh control for the entire system. If “ Source 1” is selected on this controller, all zones will switch to Source 1. If volume up is pressed, all zones will go up and visa versa volume down will lower all zones. If mute is pressed, any zones active will be muted.
  • Page 7 Recommended Cables: Category-5 or Category-3 (4 twisted pair stranded), shielded or unshielded. 164 or (2) 16-2 speaker cables. To keep the installation process as simple as possible for first time users, please follow these simple steps. These instructions are written assuming that you are using the involving teaching the controller ir commands.
  • Page 8 IR Sensor Source Selectors (1 - 6) Source LED Power Status LED Mute Button Volume Up 7.) Volume Down this is an Infrared Sensor window. We suggest you aim the external remote control 1.) IR Sensor - directly at this window to pass on commands back to and through the unit. Source Selector Buttons (1 - 6) -these Individual key caps (supplied with the unit) will allow you to “...
  • Page 9 The left side of this controller is identical to the KHS-6S consult last page. Reset Clear 14.) Learn Button ‘ x”.+‘ 15.) IR Sensor LED 8.) Reset - t h is r e s e t s t h e lo c a l z o n e c o n t r o lle r i f a n I R c o m m a n d “lo c k s u p ” t h e z o n e . I t w ill n o t e r a s t h e lo c a l z o n e m e m o r y .
  • Page 10 I This pacle is for information onlv - Consult Your Installer for Application 1 .-.” .“~~, ._“““______~~ _ l i x - _ - .., - . _ sa:: “ 4’ :‘ :5 ;a.$, _...” __.. _l”-_”...
  • Page 11 16.) Numeric Entry Keys (0 - 9) - depending on the mode you are in these keys will allow direct track access on a CD, an individual station on the macro mode, these will allow direct access to your stored macros. 17.) Enter button - working in conjunction with the numeric keys above, this button will allow you to address larger numbers quicker.
  • Page 12 The KHSGD controller is designed to learn and store This enables the individual programming and use of multiple functions for all of your source components. 1) Press the “learn” button on the controller. The left, red “Clone/Learn” LED will begin flashing. 2) Press the source device button to be programmed.
  • Page 13 The KHS-6D has 16 programmable macro memories. It will automatically transmit a series of 20 commands deep. To enter the macro mode - press macro and the either the 0 through 9 buttons OR the device source keys (l-6). You can insert a delay time from 1 to 99 seconds between steps (the default is suit their specialized needs.
  • Page 14 Programming a wireless remote using the KHS6S Wall Controller R e m o v e t h e D e c o r a cover plate, and controller face plate. Place your wireless remote in learn mode. (learn LED should begin flashing on the K H S L R C m o d e l l e a r n i n g r e m o t e c o n t r o l ) Select the device bank button to program (i.e.
