Summary of Contents for Ozito OZSS2400WA
-
Page 1: Operating Instructions
SILENT SHREDDER 2400W MODEL NO. OZSS2400WA OPERATING INSTRUCTIONS w w w. o z i t o . c o m . a u Always Wear Eye, Face & Ear Protection... -
Page 2: Specifications - Model No. Ozss2400Wa
SPECIFICATIONS - MODEL NO. OZSS2400WA Motor: S6(40%):2400W, S1:2000W Duty type: S1: continuous running duty; S6: continuous-operation periodic duty. (4min. full load, 6min. no load) Voltage: 230-240V ~ 50Hz No load speed: 46/min Max. cutting diameter: 40mm Net weight: 24kg Noise level:... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS - MODEL NO. OZSS2400WA ……. Page 1 TABLE OF CONTENTS………………………………….. Page 2 INTRODUCTION………………………………………... Page 3 SAFETY INSTRUCTIONS……………………………….. Page 6 OPERATION …………………………………………….. Page 8 MAINTENANCE …………….………………………….. Page 10 CONTENTS ……………………………………………... Page 12 WARRANTY……………………………………………… Page 13... -
Page 4: Introduction
The electric motor has been designed for one voltage only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. - Page 5 GENERAL 1. Keep work areas clean. Cluttered work areas and benches can cause accidents. 2. Consider work area environment. Do not expose your tool to high humidity or rain. Do not use your tool in damp and wet conditions. Keep the work area well lit.
- Page 6 GENERAL (cont.) 13. Check for damaged parts. Before use, carefully check the tool and power lead for damage. Check for misalignment and seizure of moving parts, breakage of parts, damage to guards and switches and any other conditions that may affect its operation.
-
Page 7: Safety Instructions
SAFETY INSTRUCTIONS FOR SILENT SHREDDERS • Only use the shredder in dry conditions and never outdoors when it is raining. • Do not allow children or any person who has not read this instruction manual or who is not familiar with the shredder, to operate it. •... - Page 8 ASSEMBLY Remove the silent shredder and its contents from within the carton. Fg.2 Fg.1 1. Carefully place the machine upside down resting on the feeding hopper. Position the legs ensuring they are assembled so that they are angled outwards (fig.1). 2.
-
Page 9: Operation
OPERATION Direction Control Knob Prior to operation, the direction control knob has to be turned to either feeding or reverse feeding mode. When the control knob is in the centre, it is in the ‘’off ‘’ position (‘O’). When turned counter-clockwise, the shredder is in the feeding mode (as indicated by ). - Page 10 OPERATION (cont.) Motor Protection The shredder is equipped with a built-in motor protection system which prevents the motor being overloaded. In the event of overloading, the shredder will switch off automatically. If this occurs allow the motor to cool for 5 minutes and then proceed to shred your material.
-
Page 11: Maintenance
• Store the shredder upright in a dry position. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the shredder by an unauthorised person or by mishandling of the tool. - Page 12 LABELS ON YOUR TOOL...
-
Page 13: Contents
CONTENTS 1 x Silent Shredder OZSS2400WA 2 x Wheel Caps 4 x Hex-screws and Washers 1 x 6mm allen key 2 x Stabilising Legs/Stands 1 x 8mm allen key 1 x Assembled Axle 1 x Instruction Manual 2 x Wheels... -
Page 14: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 2 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 24 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
