dCS Vivaldi Upsampler User Manual
STEP 4 – Using the USB1 interface with a computer
If you do not want to use a computer, you can miss out this step.
USB1
The interface can be connected to Windows™ Vista (SP2 or later) / Windows™ 7 or
Windows™ XP (SP3 or later) PC, Mac™ OSX (10.5.4 or later) computers or a sound server, running
streaming software to generate PCM data. The interface will work with Linux-based servers and
computers fitted with USB 2.0 interfaces that natively support USB Audio Class 1 or Class 2 operation.

Setting the USB Audio Class

There are two USB Audio classes, one of which must be set during system set-up. The Upsampler is
shipped set to USB Audio Class 2.
USB Audio Class 1: The interface operates without a special driver at up to 96kS/s.
To select Class 1, open the menu, navigate to the
button sequence is:
select the Class 1
USB Audio Class 2: The interface operates at up to 192kS/s.
For Mac OSX, version 10.6.3 or later is required.
For Windows XP, Vista or Windows 7, the driver files on the dCS USB Class 2 Driver disc
supplied must be installed onto the computer before use (see below).
At the time of writing, we have not tested the driver with Windows 8, but we are told it works
well if the driver is loaded in Windows 7 Compatibility Mode.
To select Class 2, open the menu, navigate to the
button sequence is:
select the Class 2

Loading the Windows driver for USB Class 2

• If ASIO4ALL or any other ASIO driver (e.g. for a sound card) is loaded on your computer, please
uninstall it - otherwise the dCS driver will not work correctly.
• Make sure the Upsampler is set to USB Class 2 - otherwise the driver installation will fail.
• Power up the Upsampler and the computer.
• Load the dCS USB Audio Class 2 driver disc for Windows into the computer's CD drive.
• If the installation does not start automatically, select "Run setup.exe".
• Follow the on-screen prompts.
• When prompted, connect the Upsampler's
• Wait until installation is complete, then remove the driver disc and re-start the computer.
If you connect a Vivaldi Upsampler set for USB Audio Class 2 to a Windows computer
!
without first loading the driver, the interface will not work and the computer will display
the warning message
Filename: Vivaldi Upsampler Manual v1_0x.docx
Menu, ►, Menu, ◄, ◄, ◄, ◄,
icon.
Menu, ►, Menu, ◄, ◄, ◄, ◄,
icon.
USB1
Device cannot
Page 14
Settings > USB Class
and then use the
Settings > USB Class
and then use the
port to the computer's USB port.
start.
Software Issue 1.0x
November 2013
menu page. The
Menu
button to
menu page. The
Menu
button to
