- Page 1 User Manual LED MOVING HEAD MH LED 60D Please Read over this Manual before Operating the Light Fixture...
-
Page 2: Table Of Contents
Tableof Contents 1.BeforeyouBegin ..................1 What is Included ........................1 Unpacking Instructions ......................1 Text Conventions ........................1 Icons ...........................1 Safety Notes .........................2 Expected LED Lifespan ......................2 2. Introduction ....................3 Feature Description ........................3 Features............................3 Additional Features........................3 DMX Channel Summary ........................3 Product Overview .........................4 3.Setup ......................5 AC Power..........................5 AC Plug ..........................5... - Page 3 Parts List ..........................18 Photometrics ........................18 Returns Procedure .......................19 Claims ..........................19 Technical Specifications......................20 6. Appendix....................21 DMX Primer ......................... 21 The Physical Medium......................21 The Signals ......................... 21 The Functions ........................21 DMX Configuration ........................21 Personalities ........................21 Starting Address ........................21 Assigning Addresses ......................22 DMX Universes ........................22 DMX Connectivity .........................22...
-
Page 4: 1. Before You Begin
1. Before you Begin What is • One LED Moving head Light Included • One power cord with plug • Two mounting brackets • Quick Reference Guide Unpacking Immediately upon receiving a fixture, carefully unpack the box. Check the box contents to ensure that all parts are present and that they are in good condition. -
Page 5: Safety Notes
Safety Please read the following notes carefully because they include important safety information about the installation, usage and maintenance of this product. Notes It is important to read all these notes before starting to work with this product. There are no user serviceable parts inside the light. Any reference to servicing this unit you may find from now on in this User Manual will only apply to properly C we certified technicians. -
Page 6: Dmx Channel Summary
DMX Channel Summary Function Pan Fine Tilt Tilt Color Wheel Tilt Fine Fixed Gobo Wheel (#1) Pan / Tilt Speed Rotating Gobo Wheel (#2) Color Wheel Gobo Rotation Fixed Gobo Wheel (#1) Rotating Prism Rotating Gobo Wheel (#2) Focus Gobo Rotation Dimmer Rotating Prism Strobe... - Page 7 Product Dimensions Drawing Here Control Panel Base Fan Power Input On/Off Switch DMX Out Base Fan DMX In Fuse Holder --4--...
-
Page 8: Setup
3. Setup AC Power The light has an auto-ranging power supply that can work with an input voltage range of 100~240 VAC, 50/60 Hz. Make sure that you are connecting this product to the proper voltage, as per the specifications in this guide, the product's user manual or on the product's sticker. Always connect the light to a protected circuit with an appropriate electrical ground to avoid the risk of electrocution or fire. -
Page 9: Gobo Replacement
Gobo 1) Unlock the gobo cover and slide it away. 2) Take the target gobo out of the gobo wheel. Replacement 3) Install the new rotating gobo. 4) Slide and lock the gobo cover. Make sure to disconnect the fixture's power cord before replacing the gobo. 1) Remove the head cover by loosening its screws. -
Page 10: Mounting
Mounting Read the safety notes at the beginning of this guide and follow their recommendations before mounting this product. Orientation Always mount this fixture in any safe position while making sure that there is adequate room around it for ventilation. Make sure to mount this fixture away from any flammable material as indicated in the Safety Notes. -
Page 11: Operation
Exits from the current menu or function Enables the currently displayed menu or sets the currently selected value in to the current function Navigates upwards through the menu list and increases the numeric value when in a function Navigates downwards through the menu list and decreases the numeric value when in a function You can set the light start address in the 001~512 DMX range. -
Page 12: Keylock
Keylock 1) Go to MENU > INTRO > KEYLOCK 2) Select YES or NO When i n t he " YES" set ting, the u ser will h ave to en ter t he password after 30 seconds of control panel inactivity or each time he/she turns the fixture on. The default (non-modifiable) password is <... -
Page 13: Range Limitation
Range Limitation 1)Go to MENU > RANGE > P/START 2)Select the starting point for the limited pan (000~255) 3)Go to MENU > RANGE > P/FINISH 4)Select the finishing point for the limited pan (000~255) 5)Go to MENU > RANGE > T/START 6)Select the starting point for the limited tilt (000~255) 7)Go to MENU >... - Page 14 --11--...
-
Page 15: Advanced
ADVANCED Channel Function ..255 0~540° ..255 Fine movement control ..255 0~270° ..255 Fine movement control ..255 Fast~Slow ..White ..Yellow ..Magenta ..Green ..Orange ..Blue ..Light blue ..Light green .. - Page 16 ADVANCED ADVANCED 000-----031 Close 032-----063 Open 064-----095 Strobe ( Slow~Fast 096-----127 Open 128-----159 Pulse strobe effect ( Slow~Fast 160-----191 Open 192-----223 Random strobe effect ( Slow~Fast ----- Open 000----- 019 No function 020-----039 Pan/tilt black activation (3 s delay) 040-----059 Pan/tilt black deactivation (3 s delay) 060-----079 Auto 1 (3 s delay)
- Page 17 000----- 009 No gobo 010-----019 Gobo 1 020-----029 Gobo 2 030-----039 Gobo 3 040-----049 Gobo 4 050-----059 Gobo 5 060-----069 Gobo 6 070-----079 Gobo 7 080-----099 Shaking gobo 7 100-----119 Shaking gobo 6 120-----139 Shaking gobo 5 140-----159 Shaking gobo 4 160-----179 Shaking gobo 3 180-----199...
-
Page 18: General Maintenance
General To maintain optimum performance and minimize wear, the user should clean the light fixtures frequently. Usage and environment are contributing factors in determining the Maintenance cleaning frequency. As a rule, the user should clean the fixtures at least twice a month. -
Page 19: Troubleshooting Guide
Troubleshooting Guide LED connection problems Reconnect LED Fixture is on Faulty LED Replace LED LED is off Faulty LED driver Replace LED driver Faulty head fan Replace head fan Fixture is on Head fan is off Faulty LED driver Replace LED driver Faulty base fan Replace base fan Fixture is on... -
Page 20: Exploded View
Exploded View --17--... - Page 21 Front lens cover P114-Q260LFL Prism P114-Q260PRSM Prism motor P113-Q260LP Motor driver board P188-Q260LED Rotating gobo wheel P169-Q260LED LED board P222-Q260LED Heat sink P222-Q260LHS Moving head fan P131-MVNHD Arm cover P300-Q260LA Tilt motor P113-Q260LEDT Display/main board P173-Q260LED Base fan P131-24V15A Mounting bracket P125-Q260LED X/Y control board P175-Q260LED...
-
Page 22: Returns Procedure
The user must send the merchandise prepaid, in the original box, and with its original Returns packing and accessories. We will not issue call tags. Procedure Call us and request a Return Merchandise Authorization Number (RMA #) before shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 23: Appendix
6. Appendix The DMX protocol (USITT DMX512-A) is a networking protocol that enables a universal DMX Primer DMX controller device to control the features of multiple DMX compatible fixtures, whether par cans, wash lights, moving heads, follow spots, foggers , proprietary fixture controllers, etc. -
Page 24: Dmx Configuration
DMX Configuration (Cont.) Assigning The user must carefully assign the starting addresses for each individual fixture to avoid DMX channel overlapping. If the DMX channels do overlap, the affected Addresses fixtures could operate erratically. However, the user may decide to configure two or more similar fixtures with the same personality and starting address. -
Page 25: Dmx Cable Connectors
DMX Connectivity (Cont.) DMX Cable Each DMX cable must have a male, 3-pin XLR connector on one end and a female, 3- pin XLR connector on the other end. Connectors DMX Connector Configuration To DMX Input To DMX Output (Female) (Male) To avoid signal transmission problems and interference, it is always advisable to connect a DMX signal terminator, as seen below. -
Page 26: Master/Slave Linking
DMX Connectivity (Cont.) Controlle Other DMX Compatible Fixtures Third Second First Generic Cable Cable Cable DMX Data Connection Diagram Master/Slave The Master/Slave mode allows one fixture (the master) to run a preconfigured program to control several other fixtures of the same model (the slaves) without Linking requiring a DMX controller. -
Page 27: Id Addressing
ID Addressing ID Addressing is a sub-addressing method by which each fixture, apart from its starting address, can also have an "ID" address in the 1~66 range. This allows users to multiply the number of fixtures they can control with a single DMX controller. Many fixtures have at least one DMX personality or mode that enables ID addressing. -
Page 28: Sizing The Circuit Breakers
Sizing the Calculating the total current drawn by the fixtures connected to a particular circuit is not complicated if the installer has the right information at hand and knows how Circuit to interpret it. Breakers With the fixture's current draw information, the installer can calculate and select the right circuit breaker size (rating) to which they can connect a group of fixtures.
