Bosch DLE 70 Professional Original Instructions Manual
Hide thumbs
Also See for DLE 70 Professional:
- Original instructions manual (341 pages) ,
- Original instructions manual (45 pages) ,
- Original instructions manual (345 pages)
Table of Contents
Advertisement
OBJ_BUCH-703-002.book Page 1 Wednesday, July 23, 2008 7:21 PM
Robert Bosch GmbH
Geschäftsbereich Elektrowerkzeuge
D-70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
1 609 929 R53 (2008.07) T / 342 XXX
DLE 70 Professional
de Originalbetriebsanleitung
pl
Instrukcją oryginalną
en Original instructions
cs Původním návodem k používání
fr
Notice originale
sk Pôvodný návod na použitie
es Manual original
hu Eredeti használati utasítás
pt
Manual original
ru
Оригинальное руководство по
it
Istruzioni originali
эксплуатации
nl
Oorspronkelijke
uk Оригінальна інструкція з
gebruiksaanwijzing
експлуатації
da Original brugsanvisning
ro
Instrucţiuni de folosire originale
sv Bruksanvisning i original
bg Оригинално ръководство за
no Original driftsinstruks
експлоатация
fi
Alkuperäiset ohjeet
sr
Originalno uputstvo za rad
el
Πρωτότυπο οδηγιών χρήσης
sl
Izvirna navodila
tr
Orijinal işletme talimat
hr
Originalne upute za rad
et
Algupärane kasutusjuhend
lv
Oriģinālā lietošanas pamācība
lt
Originali instrukcija
cn 正本使用说明书
tw 正本使用說明書
ko 사용 설명서 원본
ar
fa
Advertisement
Table of Contents
Related Manuals for Bosch DLE 70 Professional
Summary of Contents for Bosch DLE 70 Professional
- Page 1 OBJ_BUCH-703-002.book Page 1 Wednesday, July 23, 2008 7:21 PM Robert Bosch GmbH Geschäftsbereich Elektrowerkzeuge D-70745 Leinfelden-Echterdingen DLE 70 Professional Germany www.bosch-pt.com 1 609 929 R53 (2008.07) T / 342 XXX de Originalbetriebsanleitung Instrukcją oryginalną Originalne upute za rad en Original instructions cs Původním návodem k používání...
- Page 2 ........vÝ—U 1 609 929 R53 | (23.7.08) Bosch Power Tools...
- Page 3 OBJ_BUCH-703-002.book Page 3 Wednesday, July 23, 2008 3:15 PM 1 609 929 R53 | (23.7.08) Bosch Power Tools...
- Page 4 OBJ_BUCH-703-002.book Page 4 Wednesday, July 23, 2008 3:15 PM 1 609 929 R53 | (23.7.08) Bosch Power Tools...
- Page 5 OBJ_BUCH-703-002.book Page 5 Wednesday, July 23, 2008 3:15 PM 1 609 929 R53 | (23.7.08) Bosch Power Tools...
- Page 6 OBJ_BUCH-703-002.book Page 6 Wednesday, July 23, 2008 3:15 PM 2 607 990 031 2 607 001 391 BS 150 0 601 096 974 1 609 203 R97 1 609 203 X26 1 609 203 X36 1 609 203 X48 1 609 929 R53 | (23.7.08) Bosch Power Tools...
-
Page 7: Safety Notes
This measuring tool produces laser class 2 laser radiation according to IEC 60825-1. This can lead to persons being blinded. 1 609 929 R53 | (23.7.08) Bosch Power Tools... -
Page 8: Technical Data
Please observe the article number on the type plate of your measuring tool. The trade names of the individual meas- uring tools may vary. The measuring tool can be clearly identified with the serial number 20 on the type plate. Bosch Power Tools 1 609 929 R53 | (23.7.08) -
Page 9: Product Features
Only use batteries from one brand and with the identical capacity. Remove the batteries from the measuring tool when not using it for extended periods. When storing for extended periods, the bat- teries can corrode and discharge themselves. 1 609 929 R53 | (23.7.08) Bosch Power Tools... -
Page 10: Initial Operation
Each time after switch- Briefly press the measuring button 10 to switch ing on, the rear edge of the measuring tool is on the laser beam. preset as the reference level. Bosch Power Tools 1 609 929 R53 | (23.7.08) -
Page 11: Measuring Functions
To end the minimum measurement, briefly press the bottom in the display, while the final result the measuring button 10. Pressing the measur- is shown at the top. ing button again starts a new measurement. 1 609 929 R53 | (23.7.08) Bosch Power Tools... - Page 12 Afterwards, measure the distance C. The laser In this manner, you can measure any number of beam remains switched on between both meas- further lengths B , which are added and multi- urements. plied with length A. Bosch Power Tools 1 609 929 R53 | (23.7.08)
-
Page 13: Memory Functions
3 or set to zero a second time deletes all lengths B by pushing the memory subtract button 12. 1 609 929 R53 | (23.7.08) Bosch Power Tools... -
Page 14: Working Advice
– Structured surfaces (e.g., roughcast, natural stone). If required, use the laser target plate 25 (acces- sory) on these surfaces. Also, air layers with varying temperatures or indirectly received reflections can affect the measured value. Bosch Power Tools 1 609 929 R53 | (23.7.08) -
Page 15: Troubleshooting - Causes And Corrective Measures
The target surface reflects Work with the after-sales service agent for Bosch power tools. too intensely (e.g. a mir- laser target plate ror) or insufficiently (e.g. 25 (accessory) -
Page 16: Maintenance And Service
North Orbital Road repair should be carried out by an authorized Denham after-sales service centre for Bosch power tools. Uxbridge In all correspondence and spare parts orders, UB 9 5HJ please always include the 10-digit article Tel. - Page 17 Tel.: +66 (2) 6 31 18 79 – 18 88 (10 lines) Indonesia Fax: +66 (2) 2 38 47 83 PT. Multi Tehaka Robert Bosch Ltd., P. O. Box 2054 Kawasan Industri Pulogadung Bangkok 10501, Thailand Jalan Rawa Gelam III No. 2 Bosch Service –...
- Page 18 OBJ_BUCH-703-002.book Page 29 Wednesday, July 23, 2008 3:15 PM English | 29 Vietnam Battery packs/batteries: Robert Bosch (SEA) Pte. Ltd – Vietnam Do not dispose of battery packs/batteries into Representative Office household waste, fire or water. Battery packs/ Saigon Trade Center, Suite 1206...
