Page 1: Table Of Contents
TABLE OF CONTENTS Introduction Accuracy and precautions for use Water resistance “1000 Hours Control” test Compression keys Adjusting the bracelet International Guarantee Limited Warranty (United States of America and Canada) Guarantee for Australia... - Page 2 1 Universal time 2 Chronograph seconds hand 3 Minutes hand 4 Crown A 5 Minute counter 6 Compression key 7 Push-piece with compression wing-nut. 8 Date 9 Elapsed seconds 10 Hours hand 11 Hour counter 12 Crown B...
-
Page 3: Introduction
Quartz models Quartz models are accurate to within 2 to 3 minutes a year. Jaeger-LeCoultre quartz watches contain a battery and electronic elements. When performing maintenance, your offi cial Jaeger-LeCoultre Service Centre or your author- ised Jaeger-LeCoultre retailer will recover such components and ensure they are disposed of in accordance with the standards in force. -
Page 4: 1000 Hours Control" Test
Furthermore, it is vital to have the water resistance of your watch checked by an authorised Jaeger-LeCoultre retailer at least once every two years, and at any event before any period during which it is liable to undergo prolonged and/or regular immersions. -
Page 5: Compression Keys
The criteria of the “1000 Hours Control” programme considerably exceed the standards of offi cial timing tests, which deal only with part of the movement. Jaeger-LeCoultre tests not only the movement prior to its being cased up in the watch, but also the watch as a whole. -
Page 6: Adjusting The Bracelet
You can adjust your steel bracelet yourself. However, if you have a gold model, we advise you to entrust it to the nearest approved Jaeger-LeCoultre retailer, or to contact one of our offi cial Service Centres listed at the end of the guarantee or warranty document. - Page 7 Fig. 3 Fig. 4 Remove the row(s) of links (fig. 5). Place the two ends of the bracelet back together and insert a bar (fig. 6). Fig. 5 Fig. 6 Tip over the link, press on the end of the bar pivot and push your link down until it clicks (fig.
- Page 8 Adjusting the clasp The clasp on metal bracelets and articulated rubber straps is fi tted with an ad- justment system enabling you to lengthen or shorten your wristlet by 4 mm on either side, for greater wearer comfort. Using the fine adjustment system Transition from the long position to the short position: Remove your watch.
- Page 9 Lift up the clasp cover so as to release the tip-over part of the bracelet section from its groove (fi g. 2). Fig. 2 Long position Push the tip-over part of your bracelet section and place it in its groove, facing the opposite way to its initial position (fig.
-
Page 10: Use
Technical specifi cations - Manually wound mechanical movement, Jaeger-LeCoultre Calibre 752. - 28,800 vibrations/hour. - Power reserve: approximately 65 hours. - Crown with compression key. - Push-piece with compression wing. - Water-resistant to 10 bar. - Case shock-absorbing system. - Interchangeable strap system integrated into the case. -
Page 11: Setting The Time
Crown A is then in position 1. A few clockwise turns of the crown are enough to set the watch running. It will then automatically wind up when you wear it. Please note that the crown does not lock when winding, even when the watch is fully wound. -
Page 12: Operating The Chronograph
“closed” position in the direction of the arrows. Operating the chronograph The central seconds hand on the Master Compressor Extreme World Chronograph displays the chronograph seconds to the nearest eighth of a sec- ond. A counter located at 3 o’clock tallies the minutes up to 30 minutes (after one revolution it will start counting another 30 minutes). - Page 13 (for resetting). The non-compressed gasket position (“open”) will be indicated by an arrow (front view of watch). Compressed seal position Position of seal without compression (“closed”) (“open”) Timing - The chronograph is activated by pressing the push-piece at 2 o’clock once. The central seconds hand will turn, and the minute and hour counters will run.
- Page 14 If time is set at 5 o’clock, you will 2 hours later, at 7 o’clock, you will see that the 24-hour ring displays see that the 24-hour ring has moved ‘5’ opposite the city at 6 o’clock forward, indicating ‘7’ opposite the city at 6 o’clock.
- Page 15 Note: Regions where the offi cial time differs by a fraction of an hour (India, Nepal, Iran) are not included in the city disc. Case shock-absorbing system Your watch case is equipped with a mechanism that enables it to absorb ac- cidental impacts and thus protect the movement.
- Page 16 Interchangeable strap system The base of your watch case is fitted with an integrated interchangeability system allowing the strap to be changed easily. It consists of a push-button which shifts part of the space between the horns to release the strap’s spring bar from its housing in the lugs.
- Page 17 Fitting the strap sections onto the case - Hold the back of the watch case between the thumb and forefi nger of one hand. - Hold the strap section between the thumb and forefi nger of your other hand, and position its spring bar in the lug housings. - Keeping the strap parallel to the case, insert the spring bar fi rmly into the housings.
-
Page 18: International Guarantee
Any part found by our technical services to be defective as a result of a manu- facturing defect will, at the sole discretion of Jaeger-LeCoultre, be repaired or replaced free of charge. The Jaeger-LeCoultre International Guarantee is valid... - Page 19 Jaeger- LeCoultre retailer or by a Jaeger-LeCoultre Boutique or by an authorised Jaeger- LeCoultre Service Centre (for further information please see your User Manual).
-
Page 20: Limited Warranty
Any part found by our technical services to be defective as a result of a manu- facturing defect will, at the sole discretion of Jaeger-LeCoultre, be repaired or replaced free of charge. The Jaeger-LeCoultre Limited Warranty is valid only if... - Page 21 The liability of Jaeger-LeCoultre is limited solely and exclusively to repair or replacement under the terms and conditions stated herein. Jaeger-LeCoultre...
-
Page 22: Guarantee For Australia
LeCoultre Guarantee. In order to benefi t from this guarantee you will be re- quired to present this Jaeger-LeCoultre guarantee certifi cate duly completed, dated, stamped and signed by an authorised Jaeger-LeCoultre retailer or by a Jaeger-LeCoultre Boutique. This Jaeger-LeCoultre Guarantee covers defects of materials or workmanship of your Jaeger-LeCoultre product. - Page 23 Jaeger-LeCoultre water-resistant watches may be identifi ed by the symbol engraved on the back. Their water resistance is guaranteed for two years from the date of purchase, provided that the glass, the bezel, the back, the middle part and the crown have not been damaged. It is essential to have the...
- Page 24 LeCoultre Service Centre. The list of our points of sale and service centres is available on our website: www.jaeger-lecoultre.com. You will also fi nd this infor- mation at the end of this document, under the heading “Where to entrust my timepiece for maintenance?”...
