Operating instructions LITTY 4you Preface CE Declaration of Conformity / other information Dear Customer, Classification Congratulations on purchasing your new PRO ACTIV product. You have bought a quality The LITTY (referred to as a "product" below) is product which has been especially customised classified as a class I product. -
Page 5: Introduction
Operating instructions LITTY 4you Introduction Product description / purpose Using the product as intended is essentially Before starting your journey, familiarise based on replacing the walking ability of a yourself with these operating instructions pay- person who has difficulty walking or cannot... -
Page 6: Technical Specifications
Operating instructions LITTY 4you how to use the product safely after a short Technical specifications time. Product weight The total weight depends on the dimensions 10 Hand-over and accessories and starts from 6.7 kg. The hand-over must be done by your dealer or a field representative from PRO ACTIV. -
Page 7: Safety Instructions - While Driving / Using
Operating instructions LITTY 4you 12 Safety instructions - while driv- Before using the product, ensure that the ing / using anti-tippers are in good working order. In this case, it must not be possible to swivel the anti- tippers to the side when in operating position Please note that some parts of your prod- without having to unlock them first. -
Page 8: Safety Instructions Regarding Obstacles
Operating instructions LITTY 4you If you encounter new driving situations Make sure that the passive illumination which are unknown to you, approach them with (reflectors) are always on your product, are in great care. If you consider that the risk is too perfect condition and are clearly visible. -
Page 9: Safety Instructions Regarding Dangerous Locations And Dangerous Situations
Operating instructions LITTY 4you To overcome obstacles such as curbs or When crossing main roads, intersections steps, the wheelchair needs to be actively and level crossings, extreme caution is tipped as otherwise the caster wheel could jam needed. Crossing rails in the road or at level at right angles to the obstacle and could block. -
Page 10: Back Shell Position
Operating instructions LITTY 4you Every time the seat heights and angles are adjusted, the position of the footrest needs M6 fixing screws adjusting as well. Make sure the clearance under the footrest is sufficient. Experience shows that this should not be less than 4 cm. -
Page 11: Adjusting Seat Width
Operating instructions LITTY 4you Once the position of the back shell has been M6 fixing screws set, tighten the M5 fixing screws (AF 3 mm) using 4 Nm torque again. The associated nuts (AF 5mm) must be tightened for this. - Page 12 Operating instructions LITTY 4you If the angle of the support tubes is to be changed, then the M6 fixing screws (AF 5 mm) need to be loosened further so that the positive Foot bracket locking on the interlocking serration is re- clamps leased.
-
Page 13: Adjusting The Tipping Point
Operating instructions LITTY 4you 17 Drive wheels As an option it is also possible to choose a foot plate which can be folded up towards the 17.1 Removing and attaching the drive back. If this angle is to be adjusted, then the... -
Page 14: Checking And Adjusting The Wheel Tracking Of The Drive Wheel
Operating instructions LITTY 4you To adjust the track proceed as follows: 17.2 Checking and adjusting the wheel tracking of the drive wheel 1. Loosen the aluminium locking nuts on both sides (AF 41 mm). Well adjusted wheel tracking significantly im- proves the easy running characteristics of the product. -
Page 15: Air Pressure
Operating instructions LITTY 4you may not be more than 5 mm larger that at 18 Caster wheels the front. 18.1 Replacing the caster wheels To remove a caster wheel, unscrew the M6 axle fixing screw (AF 4 mm) out on one side. -
Page 16: Caster Wheels Flapping
Operating instructions LITTY 4you tary axle is then no longer completely at 18.2 Caster wheels flapping right angles to the ground). Uncontrolled swivelling backwards and for- wards of the caster wheels around their axes on the caster fork (while moving) is called "flut- Rotary axle for tering". -
Page 17: Anti-Tippers
Operating instructions LITTY 4you Wrench Locking knob in inside of fork Caster wheel bearing block Figure 26: Caster wheel fork with quick release axle and locking knob Figure 24: Loosening the protective cap on the caster wheel bearing block with a wrench... - Page 18 Operating instructions LITTY 4you Cylindrical pin in pull groove Anti-tipper Pull out anti- sleeve tippers and turn them upwards to left or right Figure 28: Cylindrical pin in groove A spring system on the anti-tippers can be used for example to overcome obstacles to...
-
Page 19: Brake
Operating instructions LITTY 4you Before using the wheelchair, after every load on the anti-tippers and after every adjust- ment to the product, make sure that the anti- tippers are fully functional. In this case the anti- tipper in operating position must not allow itself... - Page 20 Operating instructions LITTY 4you It can become necessary to adjust the brake for various reasons: You have changed the tyre or the tyre pressure. You have changed the wheel tracking of the drive wheels. The brake is pulling unevenly or insuffi- ciently after extended use.
-
Page 21: Push Handles
Operating instructions LITTY 4you Please note that the knee lever wheel lock which your product is fitted with is a parking brake which may only be applied when the product is at a standstill. This is not a service brake which is suitable for reducing speed. -
Page 22: Push Handles Offset To The Back
Operating instructions LITTY 4you M4 End stop screws Figure 45: End stop screws mounted at the bottom of the push handles offset to the back Figure 43: Central single hand push handle with After every adjustment or after reattach- folding handle end completely folded away ment following removal, check that the push handles are firmly attached in position. -
Page 23: Malfunctions
Operating instructions LITTY 4you Regular cleaning of the product is prescribed The waist belt which may be fitted is not to prevent the components becoming clogged designed as a safety belt in a motor vehicle up due to dirt. In particular, the product should and may not be used for this purpose. -
Page 24: Service Schedules
of www.proactiv-gmbh.com. In any event, keep Clean and oil all pivot points. all receipts / service reports as a means of If you should discover any problems dur-... -
Page 25: Disposal
Operating instructions LITTY 4you 27 Disposal 30 Liability At the end of the service life, the product can As the manufacturer of the product, PRO AC- be disposed of by PRO ACTIV or your dealer TIV is not responsible for its safety if: in a proper, environmentally-friendly manner. -
Page 26: Appendix: Tightening Torques And Securing Details
Operating instructions LITTY 4you 31 Appendix: Tightening torques and securing details The following table shows the torques for shaft screws with a metric control thread (valid if the drawing or assembly instructions do not state different values!): Torque MA in Nm depending on how tight the screws are Dimension Stability 8.8... -
Page 27: Appendix: Medical Product Passport / Record Of Training
Operating instructions LITTY 4you 32 Appendix: Medical product passport / record of training Product specifications: Serial number: Customer data: Surname, forename: Street: Postcode, city: Phone: Paying organisation: Training carried out by: Medical supplies dealer PRO ACTIV field representative Stamp / Date / Dealer's signature... -
Page 28: Appendix: Hand-Over Certificate
Operating instructions LITTY 4you 33 Appendix: Hand-over certificate 33.1 Required compliance criteria to authorise use completed / Topics Remarks fulfilled The product is suitable for the customer based on their own judgement and the customer informa- tion received regarding the disability-related re- strictions. -
Page 29: Check List For Training The User
Operating instructions LITTY 4you 33.2 Check list for training the user com- Topics pleted / fulfilled All mechanical function controls were explained and their function demonstrated. How the brakes work was demonstrated and then performed by the user themselves and / or their assistant. -
Page 30: Appendix: Inspection Lists
Operating instructions LITTY 4you 34 Appendix: Inspection lists Initial inspection: After 6 weeks OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Functional/safety check of brakes, push handles and anti- tippers resolved = the fault was corrected... - Page 31 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 32 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 33 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 34 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 35 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 36 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 37 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 38 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 39 Operating instructions LITTY 4you Subsequent inspection: One year later after the last inspection or earlier following particu- lar loading OK / not OK resolved carried out Check all screws / fastening elements are firmly seated Clean and oil / grease all pivot points, quick release axles...
- Page 40 Operating instructions LITTY 4you Your dealer: PRO ACTIV Reha-Technik GmbH Im Hofstätt 11 72359 Dotternhausen - Germany Tel. +49 7427 9480-0 Fax +49 7427 9480-7025 E-Mail: info@proactiv-gmbh.de www.proactiv-gmbh.com...
