COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
TCHD30S4(3,4)S3
TCHD36S4(3,4)S3
TCHD48S4(3,4)S3
TCHD60S4(3,4)S3
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 8°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU's at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU's during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
— = Not applicable.
Johnson Controls Unitary Products
AIR HANDLER
MODEL W
13 SEER AC WITH AHP / SHP / AHX / F*FP
AHP36 21
AHX30 17
AHX36 21
AHX42 21
AHX48 24
F*FP030 17
F*FP036 21
F*FP040 21
F6FP030 17
F6FP036 21
F6FP042 21
F6FP048 24
AHP36 21
AHX36 21
AHX42 21
AHX48 24
AHX60 24
F*FP036 21
F*FP040 21
F*FP042 21
F5FP048 24
F6FP036 21
F6FP042 21
F6FP048 24
F6FP060 24
AHP/SHP60 24
AHX48 24
AHX60 24
F5FP048 24
F5FP060 24
F6FP048 24
F6FP060 24
AHX60 24
F6FP060 24
COIL
RATED
1
MODEL
CFM
– 1000
– 1025
– 1005
– 990
– 1090
– 1000
– 1000
– 1000
– 1035
– 980
– 1065
– 1055
– 1200
– 1225
– 1190
– 1255
– 1300
– 1200
– 1200
– 1200
– 1250
– 1210
– 1290
– 1125
– 1240
– 1600
– 1660
– 1680
– 1700
– 1700
– 1625
– 1710
– 1905
– 1710
556723-UTG-A-0210
COOLING
NET MBH
SEER
TOTAL SENS.
28.4 21.2 13.75
28.4 21.3 14.50
29.0 21.7 15.25
29.4 22.1 15.50
29.8 23.0 15.50
27.6 20.0 13.20
27.8 20.6 13.40
27.8 20.4 13.40
28.2 20.9 13.75
28.2 20.7 14.50
29.6 22.4 15.25
28.0 21.0 14.50
34.2 25.0 14.00
34.4 25.7 14.75
35.0 25.9 15.25
35.2 26.3 15.25
35.6 26.8 15.00
33.0 23.8 13.00
33.0 24.0 13.00
33.0 24.0 13.00
35.0 25.8 15.20
33.4 24.3 13.75
35.2 26.4 14.75
32.2 23.3 14.00
35.2 26.3 15.00
45.5 33.2 13.40
47.0 34.6 13.75
47.5 34.8 13.50
47.5 35.0 13.75
46.0 33.4 13.35
45.0 33.2 13.00
48.0 35.0 13.50
57.5 40.2 13.00
56.5 38.7 13.00
EER
12.20
12.50
13.25
13.75
13.75
11.85
12.00
12.00
12.00
12.75
13.50
12.50
12.15
12.50
12.75
12.75
12.75
11.35
11.40
11.40
13.00
11.75
12.50
11.75
12.75
11.50
11.75
11.75
12.00
11.55
11.00
11.50
11.00
11.00
5
