Rialto, California 92673
_________________________________________________________________________________________________________
ASSEMBLY & OPERATING INSTRUCTIONS
Model #54658
5 Burner Stainless Steel Built-In, L.P. (Propane) Gas
Model #54659
5 Burner Stainless Steel, Built-In, Natural Gas
TABLE OF CONTENTS
PAGE
SAFETY INSTRUCTIONS ..............................................................................................................
2
INSTALLATION INSTRUCTIONS .....................................................................................................
4
LIGHTING & OPERATING INSTRUCTIONS ........................................................................................ 9
CLEANING & MAINTENANCE .......................................................................................................... 12
TROUBLESHOOTING .................................................................................................................... 13
PARTS LIST ................................................................................................................................. 14
WARRANTY................................................................................................................................... 17
READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR GRILL IS PROPERLY INSTALLED,
ASSEMBLED AND CARED FOR. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS BODILY INJURY
AND/OR PROPERTY DAMAGE. IF YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION, CONSULT YOUR
DEALER, GAS APPLIANCE SERVICE REPRESENTATIVE OR YOUR GAS COMPANY
NOTE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH THE CONSUMER AFTER INSTALLATION.
NOTE TO THE CONSUMER
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS OUTDOOR COOKING GAS APPLIANCE IS NOT INTENDED TO BE INSTALLED IN OR ON RECREATIONAL VEHICLES
AND/OR BOATS.
1
Revision 6-2011
SAFETY INSTRUCTIONS
Read carefully before assembling and operating your gas grill
This gas grill must be installed in accordance with local codes or, if in an area without local codes, with the latest edition of the
National Fuel Gas Code ANSI Z223.1. In Canada, installation must conform to the standard CAN/ CGA 1-b149.1 and/or .2
(Installation Code for Gas Burning Appliances and Equipment) and any local codes.
Advertisement
Table of Contents
Related Manuals for Bull Outdoor 54658
Summary of Contents for Bull Outdoor 54658
-
Page 1: Table Of Contents
Rialto, California 92673 _________________________________________________________________________________________________________ ASSEMBLY & OPERATING INSTRUCTIONS Model #54658 5 Burner Stainless Steel Built-In, L.P. (Propane) Gas Model #54659 5 Burner Stainless Steel, Built-In, Natural Gas TABLE OF CONTENTS PAGE SAFETY INSTRUCTIONS ………………………………………………………………………………..……………… INSTALLATION INSTRUCTIONS ………………………………………………………………………….………..….. LIGHTING & OPERATING INSTRUCTIONS ……………………………………………………………………..…… 9 CLEANING &... -
Page 2: Safety Instructions
WARNING: Fuels used in gas or oil-fired appliances and the products of combustion of such fuels, contain chemicals known to the State of California to cause cancer, birth defects and/or reproductive harm. This warning is issued pursuant to California Health & Safety Code Sec. -
Page 3: Natural Gas Safety
NATURAL GAS SAFETY Your Natural Gas grill is designed to operate on natural gas ONLY, at a pressure of 4” water column (W.C.) regulated at the natural gas regulator attached at the back of the grill. Check with your gas utility for local gas pressure and with your local municipality for building code requirements. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING YOUR GAS GRILL Your Built-in Gas Grill comes to you fully assembled. We strongly recommend professional installation and hookup of the Gas BBQ grill. These instructions will provide you with the measurements necessary for you or your builder to construct a masonry structure to house your outdoor gas grill. - Page 5 OUTDOORS NATURAL GAS BBQ INSTALLATION SPECIFICATIONS NOTE: Vents must be provided for combustion air on both sides of built-in cabinet. When choosing a location for your gas grill keep in mind that it should never be located under any overhead combustible construction.
- Page 6 OUTDOORS PROPANE GAS BBQ INSTALLATION SPECIFICATIONS NOTE: Vents must be provided for combustion air on both sides of built-in cabinet. When choosing a location for your gas grill keep in mind that it should never be located under any overhead combustible construction.
- Page 7 INSPECTING I CLEANING BURNERS AND GAS VALVE ORIFICES By following these cleaning procedures on a timely basis, your grill will be kept clean and working properly with minimum effort. BURNER CLEANING 1. Remove burner from the grill bowl (See drawing on right). Bend a stiff wire (a light-weight coat hanger works well) into a small hook as shown below.
- Page 8 COOKING COMPONENT INSTALLATION IMPORTANT: Before first use wash flame tamers, cooking grids, and warming rack with warm, soapy water. Rinse and dry thoroughly. Season metal surfaces with cooking oil occasionally. (After cooking is completed, turn grill to high setting for NO MORE THAN five minutes to burn off excess grease or food residue) CAUTION: DO NOT LEAVE GRILL UNATTENDED.
-
Page 9: Lighting & Operating Instructions
LIGHTING & OPERATING INSTRUCTIONS LIGHTING PROCEDURES Lighting Main Burner(s): 1. Become familiar with safety guidelines at front of manual. DO NOT SMOKE WHILE LIGHTING GRILL OR CHECKING GAS SUPPLY CONNECTIONSI 2. If your grill fuel source is a LP gas cylinder, check to see that cylinder is filled. 3. - Page 10 To light Rotisserie Burner with a match, Follow steps 1 through 2 above. Insert lighted fireplace-type match or long-necked butane lighter placing flame near to the Ceramic Panel. Press in control knob and rotate left (counter clockwise) to “HI” or “ON” setting to release gas.
- Page 11 LIGHTING & OPERATING INSTRUCTIONS ROTISSERIE COOKING (sold separately) Rotisserie is mostly used to cook large pieces of meat and poultry to assure slow, even cooking. The constant turning provides a self-basting action, making food cooked on a rotisserie exceptionally moist and juicy. Rotisserie cooking generally requires 1 ½ to 4½...
-
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING THE COOKING GRIDS After cooking, turn control knobs to “OFF” and let grill cool before attempting to clean your cooking grids. Before first use and periodically it is suggested that you wash the cooking grids in a mild soap and warm water solution. You can use a washcloth or a vegetable brush to clean your cooking grids. -
Page 13: Troubleshooting
TROUBLESHOOTING If grill fails to operate properly 1. Turn off gas at source, turn control knobs to “OFF”, and wait five minutes before trying again 2. Check gas supply/connections. 3. Repeat lighting procedure and, if grill still fails to operate properly, TURN “OFF” GAS AT SOURCE, TURN CONTROL KNOBS TO “OFF”, wait for grill to cool, and check the following: a. -
Page 14: Parts List
PARTS LIST Model#21009 Model#21011 REF # DESCRIPTION Lid -Front Lid -Rear Cover-Rear Lid Bowl Assembly Control Panel Grease Tray Grease Tray Handle Heat Shield Burner Flame Tamer Cooking Grid Warming Rack Lid Handle Warming Rack Support Flame Tamer Support Bezel Control Knob Temperature Gauge Gas Valve With Ignition... - Page 15 HOW TO ORDER REPLACEMENT PARTS Please refer to the parts list on this page. To make sure you obtain the correct replacement parts for your gas grill, the following information is required to assure getting the correct part. 1. Gas grill model number (see data sticker on grill) and type of gas hook up. 2.
- Page 16 ILLUSTRATED PARTS LIST...
-
Page 17: Warranty
LIMITED WARRANTY Bull Outdoor Products, Inc. warrants to the original purchaser at the original site of delivery with proof of purchase of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below. This warranty excludes grills used in rental or commercial applications.
